Key features:
1.configurable pressure display units
2. 2 independent limit switches with many configuration options
3.analog signal output with possibility of characteristic curve spread, curve reversal and offset setting
4.characteristic curve implementation via table with max. 30 measuring points
5.complete configurable parameters and measuring point protocol possible through optional transmitter pc interface
key specifications:
1.relative pressure
measuring range: 0 ~ + 1.6 bar to 0 ~ +60 bar
overpressure: 4 bar ~ 200 bar
burst pressure: 7 bar ~ 250 bar
characteristics curve deviation: 0.5% fs or 1.0% fs
2.vacuum and ± measuring ranges:
measuring range: 0 ~ (-) 1.0 bar to (-) 1 ~ +24 bar
overpressure: 4 bar ~ 100 bar
burst pressure: 7 bar ~ 150 bar
characteristics curve deviation: 1.0% full scale
3.permissible ambient temperature: -10° c ~ +70° c
4.permissible media temperature: -10° c ~ + 70° c
5.protection class: ip65 per din en 60529
6.non-linearity: < 1.0% full scale
7.hysteresis: < 0.5% full scale
8.power supply: 24 v acdc
9.analog output signal: (0) 4-20ma 0-10v
10.output contacts: 2 potential free relay contact (32v acdc , 2a) or semiconductor switches (3~32 v acdc, 0.25a), configurable
11.emc: en 61326-1:2013, en 61326-2:2013
12.material (housing): stainless steel 1.4301
13.process connection (media contact): stainless steel 1.4404
14. Measuring diaphragm: ceramic
15display: 4.6 digit lcd, full graphic, color changing
16.configurable: attenuation, switching output, measuring range unit, output signal, zero point stability, implementation of characteristic curve, password
