A. V. Ibrahim Machine Tools Pvt Ltd Town Hall, Coimbatore, Tamil Nadu

AVI Filtration Offers special micro-porous fiber media for air oil separation in compressor application.Air oil separator is also used in layers for coalescing application. AVI Filtration Offered a wide range of woven filter media for filtration of liquids, solid liquid separation and powder material classification.Woven filter media is available in Polyester, Polypropylene, Nylon and acrylic fibers.Woven filter media are available in two varieties.   Multifilament Woven filter media: Multifilament Woven filter medias are mainly used in Filter press, Fluidized bed drier, Disc filters, Rotary drum filter, Vacuum drum filters, Pan filters, Centrifuges and Decanters.Monofilament Woven filter media: Monofilament Woven filter medias are mainly used in De-dusting filters, classifiers and flour milling shifters

Linear Guide Way Wipers Wipers for Telescopic Steel Way Covers Sealing Joints for Hydrostatic Guide Ways Long Run Production Wipers    Most of our way wipers have Stainless-Steel-Cases which give them high stability and mechanical loading capacity. The sealing on the backside avoids penetration of coolants. There are no parting lines and glueing problems. The wipers lip material is normally high-quality polyurethane material, for the FBA-V and FBA-E wiper types we use synthetic rubber.   Most types come in standard lengths of 500mm / 19.7 Inch and 1.000 mm /39.4 Inch. All wipers can be made customized to your specification, they are ready to be mounted. No mounting holes are necessary for the readjustement, all screw heads are sinkable The wiper lips are easy to replace.   The wiper lip is made of high-quality material with following features: - Excellent mechanical properties  - High resistance to abrasion  - Resistance to permanently elevated temperature 90°C /220°F  - Resistance to short-term elevated temperature 130°C/290°F  - Restricted resistance to acids, alkaline solutions, benzine  - Restricted resistance to mineral oil and coolants  - Excellent resistance against hydrolyze and microorganisms

Standard telescopic spring covers are made from high-quality blue spring steel strip (55-58 Rockwell) with rounded edges. Strength up to 1800 Nm2. If regularly used with coolants of high water content, we recommend spring covers be made of stainless strip steel. However, due to the properties of this material, the spring force of these springs is less so that they cannot be made in all sizes. Please contact us for details.Telescopic spring covers can be installed either horizontally or vertically. To avoid "sagging", telescopic springs designed for horizontal use have a larger overlap of coils than those designed for vertical use, and their larger diameter should be located where the majority of chips will be encountered. Due to their high initial torque, telescopic spring covers designed for vertical mounting always require a longer extension than horizontal spring steel covers, and their larger diameter should be at the top.

Size : 20-120

Number Of Flower : conical

Brand Name : avi

Material : blue steel

Storage Condition : mold

Certification : iso 9001

Feature : 5 years

Application : screw rod

Surface Treatment : yes

Driving Type : heat

Mop Head Material : ss

Pole Material : en 42 j

use for : screw rod

Country of Origin : India

Our Telescopic Spring Covers are leading products for almost twenty years if you are looking for protection of your ball screws, columns, spindles and shafts you can consider using our Telescopic spring covers. They reduce the accident risk and increase the precision of your machines and their life. Spiral springs can be used in connection with all cutting and non-cutting machines. Telescopic Spring Covers are made of high quality hardened steel band with special hard wearing features due to our specialized method of finishing. Standard types and dimensions Abbreviations: dmax - Maximal Inner Diameter of covered part Di - Inner diameter of spring Da - Outer diameter of spring Lmax horizontal - Maximal extension for horizontal application Lmax vertical - Maximal extension for vertical application Lmin - Minimal compression (=steel band width) na - not available, ask for a customized solution   Telescopic Spring Covers - Technical Specifications They are spirally wound and produced in the diameters and lengths shown in the tables. Varying band widths ensure a perfect functioning for the various stroke paths,Telescopic spring covers achieve extremely good seal between the single coils in any position. The coils are attached as shown by means of simple centering flanges which allow the coil turning movement. The flanges are not included in delivery. If requested, please give us detailed information about the intended mounting situation. In the case of vertical installation it is recommended that the greatest diameter is at the upper end, and when used horizontally in the direction shavings occur. No maintenance is required. Cleaning is recommended depending on the amount of soiling due to the application of a light film of oil.   For technical reasons, when ordering or inquiring it should be stated whether the flat Telescopic Spring Covers are to be installed vertically or horizontally. Please note the different extension lengths for vertical or horizontal types. We guarantee through our long-term experience of more than twenty years, our exclusive and specially developed machines and highest material requirements, you will receive reliable, affordable and perfectly performing spiral springs. We offer a wide range of sizes and different materials. Most telescopic spring covers can be also delivered in stainless steel quality (non-rusting), perfect for applications with water and humidity influence. All our spiral springs are customized. Some types are available from stock. We have decided not to have an extensive stock in order to give you better prices. We can still offer you excellent delivery times. After receiving your order, it will be leaving our factory within two weeks

We are offering telescopic covers. Our telescopic steel way covers have been developed over many years of close cooperation with the machine tool industry. The steel way covers will protect machine tool bed ways against damage by swarf and coolant. They reduce sideways wear, thus maintaining the accuracy of the machine and keeping maintenance cost to a minimum. We offer types that are best for easy replacement as well as ones for heavy duty operating conditions.our telescopic covers are manufactured of best quality cold reduced mild steel sheet and are produced to a high degree of accuracy. They have a polished finish that will enhance the appearance of your machine. We also offer all types in stainless steel or with black anodized finish. Each box section of the cover is tightened against the adjoining one by a polyurethane wiper, which is protected from hot chips by a stainless steel outer case. You can choose from various solutions for the wiper system depending on your requirements.

Fabric expansion joints are among the material options for systems that need to be able to accommodate changes in temperature and mechanical force. Fabrics can be manufactured out of a variety of materials that provide the right characteristics for the process in question. Fabric expansion joints are used in a variety of industrial processes, from the petrochemical industry to power generation plants.

Brand Name : avi

Certification : ejma

Power : 200

Body Material : glass fabric

Country of Origin : India

Our special design guarantees maintenance free operations. Round bellows joints with flange andor sleeve are possible. Please indicate the working application position (horizontal, vertical) and the spindle diameter. The inner diameter of the concertina shall be 10 mm larger than the diameter of the protected spindle (shaft). Standard material is GN 807 (high tensile strength chemical fiber tissue with PU-coating). Temperature resistant from -40oC14oF to +120oC274oF. For use at high temperatures and in an welding application, aluminized fiberglass tissue resistant up to +450oC870oF is used.

As metal removal rates on machine tools continue to increase, the removal of swarf becomes a significant consideration. To meet these increasing demands we continue to be at the forefront of swarf removal by offering a comprehensive range of swarf conveyors to suit most applications. Machine design should be such that all swarf and coolant flow can be easily directed without obstruction into the swarf conveyor and sufficient space be allowed for a conveyor case that is compatible with the machine performance (recommended case sizes are listed for various types). Rollaway Introduction, Flexible Aprons with Roll Over, Basic Operating Situation, Basic Dimensions Our rollaway covers are a valid alternative for bellow type applications. Whenever you have limitations regarding space, you should think of a roller cover or apron type protection. We have developed the roller cover line to a remarkable product with many features and options. In the last twenty years we have gained experience by manufacturing over 5.000 roller covers and aprons.

They are very popular in the measuring and medical industry and for spindles, columns and shafts. The Plastic Bellows are an inexpensive solution, their main advantage is the great variety in shapes, designs and colors.

Non Woven filter medias are also known as filter paper and mainly useful for coolant filtration in metal working industries for several machining, rolling, grinding, honing, drawing operations, DM water chips cutting plant - Yarn industries etc…Non Woven filter papers are mainly used in gravity band, compact band, Vacuum band, Hydrostatic head filtration systems.Non Woven filter media offers effective filtration from 50 - 1 micron.Non Woven filter pads are also used in sparkler filters.Non Woven filter medias are available in different GSM as under.

Laminated Bellows are produced to meet the requirements of the machine tool industry (and many other industries), and offer protection against machine swarf, dust and cutting fluids.  Laminated bellows are designed for use on horizontal, vertical and cross slide ways as well as horizontal and vertical feed shafts

High-Temperature Bellows Aluminium Bellows TheseBellows are made from Alluminium coated fiber glass material and are used inharsh chemical environments   And High Temperatures and resistance up to 880degree centigrade’s. We are known as a prominent SiliconeBellows Manufacturer and Exporters of India. The SiliconeBellows offered by us, exhibit great temperature range capabilities. SiliconeBellows also have good resistance to ozone and weather. The Silicone Bellows can be availed from us at the mostcompetitive prices.  High Temp. Fabric Bellows/High Temperature Glass / Ceramic FabricBellows are used where thereis continues high temp. Application i.e. near furnaces. This materials with Standtemp up to 1200 °C to 2000°C & totally fireproof Standard materials are polyesterwoven with polyurethane coating. A wide range of different fabrics areavailable for special applications, for example - Preotex. Kevlar/Aramid fabricfor high temperature applications up to 600 º C e.g. laser, plasma or weldingmachines and Teflon coated for grinding applications. Welding blankets Welding Machines Laser Cutting Machines Piping insulation covering For insulation, clothing, expansion joints, pipe wrap, gaskets, wire-inserted insulation Neoprene coated, silicone coated, rope, cloth, glass, pure glass, tubing, blankets, plied and laminated curtains, mat, tapes, belts Expansion joint fabrics, bellows Fireproof - 2400°F, pure silica, ceramics, paper fabrics Chemical resistant - flexible, strong, fireproof Special release surface, high temp, pressure sensitive adhesive Electrical heat sealing strip Trusted brands - Teflon®, Kevlar®, Nomex®, Teflon® glass belts, Teflon® glass tape Your high temperature fabrics bellows needs will be dealtwith professionally and quickly. Remember, we have over 40 years ofmanufacturing experience resolving application needs just like yours

Fabric expansion joints are among the material options for systems that need to be able to accommodate changes in temperature and mechanical force. Fabrics can be manufactured out of a variety of materials that provide the right characteristics for the process in question. Fabric expansion joints are used in a variety of industrial processes, from the petrochemical industry to power generation plants.

Fabric expansion joints function in the same way as do expansion joints made of metal but are better choices for some purposes. They are constructed with a bellows that allows them to expand or contract to accommodate changes in pressure. The bellow is constructed with convolutions that allow for this expansion. The flexibility of these fabric expansion joints allows them to accommodate deflection from any angle. They also provide vibration absorption and noise absorption for the system.

Fabric expansion joints are manufactured out of several different materials. Some of them, particularly those that are used in systems where gas seals need to be provided, include Fluoroa Elastomer and Fluro plastic. Fabric expansion joints are also constructed out of rubberized materials, in some cases. There are a host of different materials used in manufacture, which expands the range of uses for which these devices can be employed.

ELASTIC bellows are produced to meet the requirements of the machine tool industry (and many other industries), and offer protection against machine swarf, dust and cutting fluids. Elastic bellows are designed for use on horizontal, vertical and cross slide ways as well as horizontal and vertical feed shafts. Excellent extension to compression ratios offer little resistance to machine capacity, and their clean lines and smart finish will compliment the appearance of your machine tools. Typical linear guide application for elastic bellows: All ELASTIC-Bellows are available for most types of linear guides, we have standard types for the following manufacturers: NSK, THK, STAR, INA, IKO, SKF, Schneeberger and others. As all elastic bellows are manufactured to suit customers` individual requirements, we would need details of any external influences, such as cutting fluid used, temperature range, mounting position and maximum traverse speed. A wide range of materials is available to cater for most applications and conditions of operation. External influences such as hot shavings, heavy volumes of water and special cooling agents are to be taken into account.

Size : 300

Brand Name : avi

Material : pu

Shape : rectangular

Packaging Type : block

Technics : welded

Application : lm guide

Hardness : 80

Connection : steel

Country of Origin : India

The Sword-F bellows are designed especially for horizontal application. The fixed mount stainless steel plates offer an excellent protection against all types of swarfs and chips. The front edge of the plates which prevents chip and swarf from getting inside. We are using different styles of mounting the plates onto the bellows. We are designing the right solution to your specification regarding size, travel speed and available space.

Our customers for Elevating platform bellows come mainly from the automobile, machine tool and medical industry. This allows you to open the cover for maintenance and cleaning purposes. Basically all other types of end-plates are possible. The mounting and installation of these elevating platform bellows is very easy. As standard equipment we offer a Velcro tape on each side. Our Velcro tapes are tested and approved for 10.000 opening and closing cycles. Elevating platform bellows has become very popular and today is widely used in different industry branches. We are manufacturing it according to the requirement of the customer.We often use metal end-plates on one or both sides. As for the increased safety requirements, we recommend a bellow protection for most types of elevating platforms. Due to to our long-term experience we can also offer a design with plates.   Stabilizing PVC frame in every fold because of the incorporation of PVC frames, ELASTIC bellows have extremely high dimensional stability. When elevating platform bellows are distorted, a return to the original shape is guaranteed.

Our customers for Elevating platform bellows come mainly from the automobile, machine tool and medical industry. This allows you to open the cover for maintenance and cleaning purposes. Basically all other types of end-plates are possible. The mounting and installation of these elevating platform bellows is very easy. As standard equipment we offer a Velcro tape on each side. - See more at: http:www.avbellows.combellows-elevatingplatform.php#sthash.0bYCcwNR.dpuf

Material : pu

Power : 200

Country of Origin : India

We manufacture the Apron Covers with anodized aluminum lamellas joined by flexible and wear-resistant polyurethane joints. In the event of the deterioration of any element of this Apron Cover, this type of manufacturing allows for the quick replacement of the spoiled pieces, avoiding the unnecessary shutdown of the production line.These types of protections are specially suitable for the protection of installation components when we have space limitations, As well as for the protection against oil drops, and more importantly against sharp or hot shavings. If you are interested, please Contact us for formats and measurements The Apron Roll up Guard Covers are ideal for the following applications:o Milling Machineso Boring Machineso CNC Machineso Roll-Away Coverso Robotics & AutomationThe rolls up apron covers are designed per your specifications and needs. They are constructed with aluminum strips that are hinged together to allow the roll up guard to be flexible.A.V.Ibrahim Aprons are an economically priced solution for protecting machinery from swarf and coolants. A.V.Ibrahim Flexible Aprons have the following benefits:  Extremely flexible Lightweight Tough Long wear life Available in most lengths to suit requirements Easy to installFlexible aprons can be attached at either one or both ends, and can be supplied with pre-drilled end fixings. An Alu Guard apron comprises Aluminium slats linked with a polyurethane \`hinge\` allowing the apron flexible movement. The materials have good resistance to most of the commonly used lubricants and coolants.
