Submersible Pumps Dealers in Vellanaipatti, Coimbatore

We offer our clients high quality Open Well Submersible pump. Sp. Hi-Flo & Hi-Head models. Long durability due to non- corrosive S.S. body. High discharge & Low power consumption. Excellent performance even at low voltage. Sp. motor design to prevent winding burn out   Stainless steel / Noryl Impeller. Flatter efficiency curve for wide operation range. Trouble free operation. Wide voltage design 180V-240V. Corrosion Resistant SS motor body. Low friction bearings. Easy maintained and rewindable. Compact and safe.

Pump contracted by C.I. Casting, Stainless steel Impeller, LTB4 Bushes, Stainless steel sleeve and SS410 shaft. Stator body contracted Stainless steel and ERW pipe. Stator made by laminated stamping winding with electric grad copper wire and high quality insulated materials. Dynamically balanced Rotor made by laminated stamping, copper/aluminum and SS410 shaft. Bush made by LTB4. Trust pad set made by C.I. Casting, carbon and Stainless steel.

These motors are made of stainless stell material, total ss 304 construction with SS 316 material as option. Point submersible motors designed in 4" configuration, water filled and rewindable and easy to maintain. Product Features 4" Submersible water filled and rewindable motor with insulated windings. Complete SS 304 construction with optional SS 316 Radial, Axial thrust bearing and water thrust bearings are lubricated. Shafts are induction hardened SS 431 material Special winding design for high torque, low temperature rise, high efficiency Motors are pre-filled with water and glycol mixture for longer life. Diaphragm cup with suitable protection for pressure and volume variation inside motor. 4" Specification Ratings: Single Phase - 0.37 to 4 KWThree Phase - 0.37 to 5.5 KW Supply Voltages (Tolerance +6%/-10%)50HZ, 1 Phase, 220 V, 230 V50HZ, 3 Phase, 380 V, 400 V, 415 V60HZ, 1 Phase, 115 V, 230 V60HZ, 3 Phase, 230 V, 380 V, 460 V Degree of Protection: IP 68 Continuous duty Ambient temperature: 45 C Rotation: Single Phase - CCWThree Phase - CCW and CW Maximum nos. of starts/hour:0.37 to 2.2 KW - 203 to 5.5 KW - 10 Water pH: 6.5 - 8 Minimum cooling flow along the motor: 8cm/sec Motor Protection: Select thermal overloadProtection with trip time Maximum submerged depth: 350 meters 4" On Request AISI 316 stainless steel construction.Special Voltages.   Technology   Point Submersible Motors are developed and manufactured user-freindly wet type Rewindable. Motor is Pre-filled with clear, cold, filtered water. Motors can also be customised if the requirements are not covered by the overview. Point 4" Submersible Motors are available from 0.37kW to 7.5kW with NEMA Standards. Point 6" Submersible Motors are available from 2.2kW to 37kW with NEMA Standards. Material Options The submersible motors are available in stainless steel AISI 304 grade in 4" and 6" submersible motors. Motor shaft - AISI 431 Stator Shell - AISI 304 / AISI 316 Diaphgram - Nitrle Rubber Stator The stator windings are water proof poly wrapped copper winding wires. Housing Shell The Housing shells are made with AISI 304 Grade Stainless steel. Thrust Bearing / Pad Thrust Bearing and Pad made with SS 420 and graphite Carbon material is long life and increase the efficiency of the pump. Diaphgram Diaphgram is provided to guard the pressure and volume variations of the water inside the motor. Diaphgram is made with Nitrle Rubber Motor Base Motor base is made with AISI 304 grade stainless steel.

Applications Domestic Water Supply High Raise Buildings Gardening and sprinkler Industries, for clean water handling Storage tank handling Storage tank filling

Located in Tamil Nadu (India), we are a reliable Supplier of Openwell Submersible Pumps to a number of buyers. The Submersible Pumps that we offer are ideal for lifting water from smaller wells, tanks & sumps. They are highly durable, robust in construction and reliable. They have the capability to work for a long period of time. Our Openwell Submersible Pumps are energy efficient and light in weight. Besides, we use quality tested packaging materials, which are tamper-proof so as to ensure easy handling during storage and transit. Salient Features : Dynamically balanced copper stripped rotors with epoxy coated rust proof paint Rewindable, water cooled motor with stainless steel body Higher operating efficiency over wide range of voltage fluctuations and consumes minimum power Trouble free operation and require less maintenance due to water lubricated bearings Less weight and hence easy for installation

Salient Features Carbon bushes on both sides for less friction and better motor efficiency Carbon thrust bearings at both driving and rear end for high efficiency and performance Shaft and all fasteners are stainless steel 410 Grade Superior quality Nitrile pressure adjusting diaphragm for motor safety Vertical Open well pumps for high head requirements Withstand wide voltage Fluctuations High graded oil seals to prevent sand entry into the motor Epoxy coated machined component Application Hotels, Hospitals and Apartments Gardening & Fountain Domestic and Minor irrigation

We are offering 80 mm (3") borewell submersible pumpsets cri 3r series.
