Product Code: EKE 831 to EKE 836 Operating Principle The vibrating wire load cell comprises a set of three or six vibratingwire gauges, mounted parallel to each other equally spaced in a ring inan alloy steel cylindrical housing. The method of construction resultsin a very robust instrument suitable for use where high performance,longevity and mechanical strength are important. A heavy gauge,multicore, sheathed cable connects the cell to the readout unit. Themode of operation is by electrical plucking of the vibrating wire.The change in load acting on the load cell is proportional to thedifference of the squared frequency of vibration for the correspondingload. The readings are taken on EKE 871, EKE 875 or EKE 878DataloggersAdvantages?Accurate, robust and very good long term stability?Negligible temperature effects compared with oil filled load cell?Fast response time?Accuracy unaffected by cable length?Suitable for remote readings?Capable of reading eccentric loads?Common readout for all vibrating wire type instrumentsInstallationTensile loads in rockbolts and cables are measured by installing CentreHole load Cells between the rock/concrete face and the tensioning nutof the bolt or anchor. For the most reliable results, a concrete bearingpad should be cast, with its upper face flat and perpendicular to thebolt or cable. A bearing plate is placed beneath the cell to spread theload and to take up any residual nonalignment. A further bearing plateis placed between the cell and anchor. The assembly is centralisedand held in place by applying a small tension to the bolt or cable. Faultin centralisation or alignment will be apparent from differences in loadreadings at each of the vibrating wire gauges in the cell. In situationswhere speed of installation is important, the bearing pad may beformed using high alumina cement or resin grout. Readings of thevibrating wires are averaged to obtain the bolt or cable tension. Inmulti-strand cable anchors, it is possible to tension the strandsuniformly, by monitoring and balancing the load reading for each of thevibrating wire gauges.   EKE 831 to EKE 836   Comprising alloy steel cylinder with three gauges at 120º in the cylinder walls. Each gauge is fixed with non-slip cylindrical end clamps. Electromagnetic pulsing and sensing units with, over voltage surge arrestors are mounted adjacent to each wire on the outer face of the cylinder. The entire unit is then protected by an outer zinc plated steel sleeve with ‘O’ ring seals.   Same as EKE 831 to EKE 836, but with six parallel Vibrating Wire Gauges, located 60º apart in cylinder wall. Centre Hole Bearing PlatesCentre Hole Bearing Plates comprising epoxy painted steel discs with central hole for use with EKE 831 to EKE 839 load cells for monitoring tension in rockbolt or cable anchors. The plates incorporate three location dowels to assist concentric mounting of the load cell. Details of dimensions as tabulated :   Installation Accessories EKE 83131 Connecting CableFor use with EKE 831 to EKE 836 Vibrating Wire load Cells. Six Conductor Copper Wire, insulated colour coded and screened with sheathingEKE 83731 Connecting Cable for use with EKE 837 to EKE 839 Vibrating Wire load Cells, twelve Conductors, copper wire insulated, colour coded and screened with sheathingEKE 83125 Splicing Set To be used with EKE 83131connecting cableEKE 83725 Splicing Set To be used with EKE 83731 connecting cable

Digital Load Cell Product Overview Digital load cells, created using the basis of strain gage technology, provide a new impetus for the areas of dynamic weighing, sorting, filling and dosing. The Digital load cell: Reliable, durable, highly precise. Through their robust design Digital load cell provides a long service life and high reliability.Digital load cells have been developed specifically for dynamic weighing applications. These digital load cell meets your demanding requirements on weighing in modern manufacturing lines. Maximum throughput and, at the same time, extremely high accuracy.

Our prime concern is to fulfill variegated requirements of the clients, all the time. And, to achieve this objective, we have installed a capacious warehouse. We are recognized as a trustworthy Supplier presenting an extensive assortment of Encoder.

We have gained expertise in delivering a quality assured range of Single Ended Shear Beam Load Cell. All our products are manufactured using excellent quality raw material, which we source from authorized vendors. Widely used for accurate weighing purposes, these products are widely acclaimed for their rustproof construction, excellent working speed, easy handling and low maintenance cost. Further, patrons can avail these modules from us at the most reasonable prices.

Technical Specification 20kg 30kg 50kg 75kg 100kg 200kg 300kg 500kg 750kg
