Self Priming Pump Dealers in Delhi

We are offering wide variety of Jet Pumps. These pump are made with supreme grade raw fabric, known for its smooth association and low power use with noiseless operations.These are accessible at market foremost price

Lyxar Jet swim Copper Jet swim is the perfect accessory for exercise, fitness and fun. With a Jet Swim installed in the pool the training effect is that of a much larger pool. By swimming" on the spot" in the pool you can train and practice your swimming technique at the same time building up your strength and endurance.Jet Swim also functions as a massage and rehabilitating muscle trainer. Of course, the children also love to bathe in the invigorating, bubbling current of water which can be varied in strength. Lyxar Jet swim(Copper) Technical characteristics: Material - JET: bronze,PIPE:PVC,Motor:plastic&bronze&stainless steel Superior performance to both high and medium head installation in commercial spa pools.Materials used are bronzeExtremely quiet runningEasy maintenance and repairsvoltage is 220V/50HZAsynchronous,Two polesClass insulation:130IPX5 Waterprood StandardOverload ProtectorBuilt in thermal protection

Buyers can trust us to make delivery of consignments since; we have collaborated with reckoned transportation service providers. We provide customized as well as standard packaging of the products. With the assistance of our streamlined packing system, we are able to provide damage-free products to the clients.Application Hotels, Hospitals, Domestic and Municipal Water Supply F0ur1ltE|ins, Gardening, Lawn Sprlnklar and Automobile washlflg Residential, Bangolclw and Muld·SLained buildings Solar Heating and Pressure boosting system Industries and Edible Oil Processes Structural Characteristics Motor Body Extruded Aluminium Shaft-Carbon SUEEI chi’¤·l‘l‘lE Plotéd Impeller High Tensile Forged Brass High Velocity Cooling Fan Design Totally Enclosed Fan Coolod Motor Héovy Motor En Higher Cure length Dynamically Balanced Rotating Parts Double Séaled Precision Ball Bearings Cast iron Motor Body for Longer Life Class B Insulation in Winding Wire In-built, thermal Overload Protector Mechanical Seal-graphite Vs Ceramic

Duplex II Series Pumps The Duplex II series of pumps incorporate the best technology and features developed by Xylem Flojet. Everything from the flow preventer, check valves, bearings and diaphragm assembly to the motor have been designed to make this truly the most advanced and reliable diaphragm pump available. Higher efficiency of the pump is evident in the longer life of the motor pump unit. The new diaphragm design combined with the new valves, makes the pump capable of pulling higher dry vacuum. Duplex II is available in various performance ranges, voltages and with a choice of elastomers, making it easily adaptable to a diverse range of applications.

Technical Data RPM: n=2850r/min(50Hz); n=3450r/min(60Hz) Model   Single-Phase Power   KW HP Inlet(inch) Outlet(inch) Max.Flow(m3/h) Max.Head(m) Max.Suction(m) Dim.(mm) G.W.(kg) 20Loading Qty (pcs) QB60 0.37 0.5 1 1 1.6 33 8 280*140*170 5.3 3600 QB70 0.55 0.75 1 1 2.4 48 8 335*190*210 9 2100 QB80 0.75 1 1 1 3 60 8 340*190*210 9.5 2100 SQm60 0.37 0.5 1 1 1.6 33 8 280*140*170 5.3 3800 SGJW37 0.37 0.5 1 1 2.5 32 8 390*190*230 9.5 1700 SGJW55 0.55 0.75 1 1 3 41 9 475*195*240 17 1200 SGJW75 0.75 1 1 1 5.4 46 9 475*195*240 18 1150 SGJW110 1.1 1.5 1 1 6 52 9 475*195*240 18.5 1100 JET80L 0.55 0.75 1 1 2.5 42 9 475*190*220 17.5 1200 JET100P 0.75 1 1 1 3.5 46 9 475*190*220 18 1150 JET100L 0.75 1 1 1 3.5 46 9 475*190*220 18.5 1100

We are offering jet pumps. Connected to the high pressure jetting hose from the jetting pump, the jet fitting makes set-up for 'jetting in' the wellpoints a simple operation. The "o" ring equipped jet fitting just pushes into the complete welltop on the welpointriser assembly and a spring-secured bracket slips under the welltop to provide a leak free pressure connection of the wellpoint and riser pipe to the jet pump. When the wellpoint is jetted in, the bracket is swung clear and the jet fitting pulled from the welltop, for use on the next wellpoint. No tools are required.

 Suitable for 3 to 5 mtr. negative suction lift. Fabricated from PPH for higher strength. Top cover makes maintenance easy.  Fabricated with in-buift strainer to arrest coarse impurities. Inlet & Outlet size to match pump suction flange size. SPECIAL SIZE AND HIGH CAPACITY POT ON REQUEST.

Vertical In-line Self Priming pumps are used for handling solvents from tank farms and barrels. Available in 3 sizes 25 mm NB. 40 mm NB. 65 mm NB. Advantages & Features: 1. Low NPSH required. 2. Life lubricating bearing covered from both the ends so minor leakage from side does not affect bearings. 3 .Being a low speed (1450 RPM) pump, less Maintenance in needed. 4. Installation is easier since motor required is vertical flange type and is directly 5.coupled to the pump, coupling alignment is simpler. 6. Low overhang shaft arrangement giving minimum deflection at he seal faces. 7. Floating type impeller reduces noise and vibration. 8. Available only with mechanical seal (internal mounted), rotary faces of Carbon and 9.Glass Filled Teflon (GFT) are optional. 10. Seal cooled and flushed by process fluid itself. 11. Minor leakage at suction side does not affect pump performance. 12. Biggest advantage from installation point of view is that since it is an " in line type pump, it can be fitted as a valve and hence it will not require any suction or delivery piping efforts. 13. High head low capacity pump. 14. Available in S. S -316 Investment Casting and Cast Iron with all wetted parts of S.S � 316 15. Excellent for Handling solvents from barrels and from tank farms to the charging vessels. 16. Seal leakage can easily be detected from window in priming chamber. 17. Pump can take negative lift from 3 to 5 meters. 18. Maintenance is easier, Drain arrangement is standard. 19. Compact design � requires less space, No grouting required.

We manufacture and export high precision self priming bare pumps available in various models and technical specifications. Made from corrosion resistant material, these pumps are high performing and last longer. The self priming bare pumps can withstand the voltage fluctuations and give a satisfactory output

Connected to the high pressure jetting hose from the jetting pump, the jet fitting makes set-up for 'jetting in' the wellpoints a simple operation. The "O" Ring equipped jet fitting just pushes into the Complete Welltop on the welpoint/riser assembly and a spring-secured bracket slips under the welltop to provide a leak free pressure connection of the wellpoint and riser pipe to the jet pump. When the wellpoint is jetted in, the bracket is swung clear and the jet fitting pulled from the welltop, for use on the next wellpoint. No tools are required.

The characteristics of the peripheral pump make them suitable for use in a wide range of industrial sectors where small volumes are to be pumped against high pressures. They can also be installed in applications at a low intake head without creating cavitation problems. A peripheral pump is a niche product in-between a displacement pump and a centrifugal pump, in which the medium is pumped into a peripheral channel Peripheral pumps have the following characteristics: The ability to transport gas without interrupting the fluid flow or damaging the bearings due to dry running. Maximum power consumption at their highest head and lowest flow rate. Steep capacity-head (Q-H) curves ideal for pressure-dependent system regulation. Insensitive to reverse rotation. Very low suction head (NPSH) required. Narrow columns (peripheral channels) not suitable for abrasive particles in the fluids.   Application Domestic Water Supply Home Pressure Boosting Garden / Fountains Over Head Tanks Construction Site  Features Cast Iron Casing and Bracket with Brass Inserts Brass Impeller Stainless Steel Shaft Super Enamelled Winding Wires Insulation Class F / B Flow Max 50 lpm Head Max 55 m Suction lift Max 7 m Liquid Temp upto 50° C Motor 2 pole Induction motor, 50 Hz, 2900 rpm, single phase 230 v +5% -15% Ball bearings
