Conductivity Controller Dealers

We are offering conductivity controller. This instrument is a panel instrument for on-line monitoring of industrial process conductivity. Range switch over and constant check can both be freely set and adjusted through the operation component on the rear panel; unique signal collecting and processing technology and special thick film circuit are adopted to make measurement accurate and operation stable; there are also other features such as linearized data, automatic temperature compensation, not subject to the length change of cable and maintenance-free. It has control function, including setting of over limit of conductivity, and the outputs are control contacts. It’s an ideal auxiliary instrument of various types of small pure water equipment sepicification: measurement range: 0~20, 0~200, 0~2000 (μscm) optional accuracy 1.5% (fs) stability ±2 × 10-3 (fs) 24h display mode back light 3.5 lcd digital display auxiliary electrode 1.0cm-1 plastic electrode thread dimension 12″pipe thread control output mode single relay contact (normally open) contact capacity 5a250v ac ( with resistive load) environment conditions temperature: 0~50; relative humidity: ≤85% temperature compensation automatic compensation with 25 as the reference temperature. Cable length 5m or on other agreement (5~30m) temperature compensation automatic compensation with 25 as the reference temperature power supply ac 220v ±10% 50hz cable composition rvp+coaxial 75-2 double shielding operation pressure of conductance cell 00.5mpa cable length 5m or on other agreement dimensions 48 × 96 × 100mm (height × width × depth) slot dimensions for installation 45 × 91mm (height × width)

Our company is widely acclaimed as one of the prominent Exporters and Suppliers of Digital Conductivity Controller. We procure this Conductivity Controller from authorized vendors who have adopted latest technology and make use of only optimum quality metal components. Buyers are free to place bulk orders and we ensure its on-time delivery in high-grade packaging material ensuring safe delivery. It is available with us at the best market price.Conductivity Controller 110 - Cond : Precision Indication of Conductivity Automatic Temperature Compensation 4 Step Range Selection 0.1 µs to 199.9 ms Two set Point Independent High / Low Limits for on-Line Control Front Panel 'Touch Type' Membrane Switch to read the Limits set Voltage corresponding to conductivity available for External Recorder 'Cell Adjust' on Front Panel for calibration Specifications : Display Sensor 3.5 Digit LCD Display 'Contact type' With cell constant 1.0 (0.1 cell constant available on request) Range : (a) 199.9 µs (b) 1999 µs (c) 19.99 ms (d) 199.9 ms. The range is selectable from rear & can be calibrated by 'Cell Adj.' at the front for individual range.  Accuracy Resolution Temperature Compensation : +0.5% of full scale + 1 Least Significant Digit 0.1µs to 0.1 ms depending on range selected. Uses PT 100, Precision temperature sensor (external) The Compensation is internally set at 2% per degree Celsius Note : If PT 100 is not available, then fix a simulated resistance of PT 100 @ 25 degree Celsius approx. 110Ω. Instrument will not work otherwise.   Limit Setting Control Output : Using 2 Nos. 10 turn precision trimpots on front panel to set the high / Low limits. Two set of No-P-NC, 5 Amps potential free realy contacts. Relay 1 (High) On, for conductivity > High Limit Relay 2 (Low) On, for conductivity < Low Limit  Recorder Output Supply Dimensions Cabinet : 0-2 V for selected range, Max. Current output capability 2MA 110 V AC / 220 V AC + 15% internally Selectable Front facia : 96 mm x 96mm Cut out : 92 mm x 92mm Flame Retardant grade Plastic Enclosure

Range :10 m mho to 999 m mho in 5 ranges.Display : 3 ½ digit LED .Input Frequency:1000 Hz.Accessories :Conductivity cel , Temperature Probe, Manual, Dust Cover.Dimension :215x190x25 mm.

The VATS mhoCounter is yet another step forward to deliver convenience & to the point technology in a compact package. With our experience of a wide range of installations, we came out with easy to fit conductivity TDS meters. The mhoCounter CT-10 is a conductivity indicator & mhoCounter CT-11 is the meter with relay output option, which is programmable. Microprocessor based electronics allow wide operating range and long term signal stability. Optional relays provide control for adjustment or alarms. Also the meter comes with saddle mounting option or standard fittings to adopt to any process flow solution.

CCI 100 series conductivity meters are extremely versatile conductivity meters that can be used for a wide variety of applications. These meters offer extreme reliability and low cost for conductivity measurement CCI 100 series conductivity meters can be used for water and water like liquids including acids and alkalis. These meters can also be used for any line size. Microprocessor based instrumentation ensures accurate readings for Conductivity, TDS and Temperature. A number of programmable features including Inline calibration are standard features. All models offer relay outputs with user programmable set points. Industry standard 4-20mA output is also available on select models. All models offer comprehensive equalizations for temperature variations. CCI 100 includes a built-in electronic temperature sensor with an accuracy of +-1 C. This temperature can be viewed on the display whenever needed. The user can also program the equalization factor which is in the following format CT = C25 (1 + TC (T – 25)) CT – Actual conductivity of the liquid at measured temperature C25 – Conductivity at 25 C TC – Temperature coefficient of the liquid T – Temperature in Deg C

MicroSet Series MSCD -912 is Conductivity Indicator specially designed for various industrial applications. These can be used for monitoring Conductivity of a solution. The measuring range and control points are settable through the keypad on front fascia and control output is available at the rear terminals. Retransmission output, communication port are additive features of MSCD -912.   Technical Specifications Type of Input : From Conductivity Electrode Cell Constant : 1 / 0.1 / 0.01 Display : 2 x 16 Characters Backlit Calibration Range : 0 to 100 μS/cm for cell constant 0.01 0 to 1000 μS/cm for cell constant 0.1 0 to 10000 μS/cm for cell constant 1 Accuracy : Better than + 0.25% F. S. Power Supply : 1) 24 V DC, External 2) 90 - 250 V AC, 50 Hz +/- 10% Power Consumption : < 10 VA Temperature Drift : < 0.01% of F. S. per 0C change Response Time : < 500 mSec Isolation : 1.4 KV between Input, Output & Power Supply Enclosure : 1) DIN Std. 2) Weather-proof, IP-65 3) Flame-proof, IP -65, IIA, IIB CMRI Certified Mounting : WP enclosure Field Mounted Weight : 1.5 kg (Approx.) Operating Conditions : Temperature 0 to 55 0C / Humidity 5 to 95% non condensing Retransmission Output : 4 to 20 mA Isolated Temp Compensation : Pt -100 Alarm : 02 Nos.

Direct Input Accept PH electrode, TDS/Conductivity cell TDS Ranges 0-9999ppm or 0-99.99ppt PH Range 0.00 to 14.00 PH, Pressure -1 to1000 Bar/PSI Resolution 0.001/0.01/0.1/1 selectable Display Range -1999 to 9999 Selectable 100-240 VAC mains operated with 24VDC Transmitter supply Offset, Hysteresis, Range selectable, Dual output Retransmission out put 4 -20mA optional Auto/Manual Temperature compensation

The Conductivity Indicator which we supply is ideal for agricultural, horticultural and hydroponics applications where pH and TDS levels need to be continuously monitored for optimal plant growth. This Conductivity Indicator continuously monitors and displays the values of a solution on an easy to read set of LCD's. Avail the Conductivity Indicator from us at market leading prices. Conductivity Indicator Features : Two parameters with a single instrumentAdvanced electrode technologySimple operation and maintenanceSupplied complete and ready to use About Conductivity Indicator : The HI 1286 gel filled pH electrode is replaceable and the BNC connector is protected behind a waterproof sleeve. The unique design of the electrode guarantees greater clogging resistance in fertilizer solutions with high concentrations of phosphate, nitrate, etc. TDS measurements are performed using the 4-4-2 conversion factor of 0.7 so you do not need to convert the readings.This model is equipped with a grounding bar to ensure highly accurate pH readings and longer electrode life.The HI 981404N is compact and easy to install and use making it ideal for all continuous monitoring applications. Order Information : HI 981404N-01 (115V) and HI 981404N-02 (230V) are supplied complete with HI 1286 pH electrode, HI 7634 TDS probe, HI 1283 grounding bar, calibration solutions, screwdriver for calibration, 12 VDC adapter and instructions. » Specifications RangepH0.0 to 14.0 pHTDS0 to 1990 mg/L (ppm)ResolutionpH0.1 pHTDS10 mg/L (ppm)Accuracy @ 20oCpH±0.2 pHTDS±2% F.S.CalibrationpHmanual at one or two pointsTDSmanual at one pointOther DetailsTemperature Compensationautomatic from 5 to 50oC (41 to 122oF) (TDS only)TDS Conversion Factor0.7 ppm = 1 µS/cmProbesHI 1286 interchangeable pH electrode (included), HI 7634 TDS probe (fixed), HI 1283 grounding bar with 2 m (6.6’) cable (included)Power Supply12 VDC adapter (included)Environment0 to 50oC (32 to 122oF), RH 95%Dimensions165 x 110 x 35 mm (6.5 x 4.3 x 1.3”)Weight300 g (10.6 oz.) »Accessories ElectrodesHI 1286Spare pH Electrode for pH IndicatorsSolutionsHI 70000PRinsing Solution 25 x 20 mL sachetsHI 70004P4.01 pH Buffer Solution, (25) 20 mLHI 70007P7.01 pH Buffer Solution(25) 20 mL sachetsHI 70442P1500 mg/L (ppm) TDS Solution, (25) 20 mL SachetsHI 70039P5000 µS/cm EC Solution (25) 20 mL SachetsHI 70300MElectrode Storage Solution1 x 230 mL bottleHI 7061MGeneral Purpose Cleaning Solution1 x 230 mL bottleAccessoriesHI 710005Power Adapter, 115 Vac to 12 VDC, US PlugHI 710006Power Adapter, 230 Vac to 12 VDC, European Plug

Advanced embedded micro controller based design Available in panel type, field type, and Flame proof and IP version Automatic Or Manuals Temperature Compensation Multi parameter display by a key press.

The water is such an element which needs to be pure for using it in our various daily activities. But by seeing the water we cannot decide whether it is perfect for use. To keep away this type of confusion Conductivity Meter are used in great range. This electric device is used for checking the purity of the water.The salt that is present in land or water can be checked by this high performance meter. It has been designed in many specimens to make it compatible with numerous machines and tools.

The Conductivity Indicator offered by us is essential in ensuring accurate readings for conductivity and temperature. Our Conductivity Indicator comprises of built-in electronic temperature sensor for timely readings of temperature & conductivity. Conductivity Indicator offered by us, has rugged design & corrosion resistant ensuring high performance and long service life. Why Our Conductivity Indicator? Excellent durabilityHigh qualityRugged designExcellent performanceResistance to corrosionSturdy constructionEasy & safe to use

Chemocon obtains an extract from the squeezed online material after exiting the wash bath. The extract is derived in such a manner as to include not only the surface water adhering to the material but also water from the inner fibres. Threshold range regulation of the washing process is facilitated using the information regarding the internal condition of the material. pH and conductivity measurements are carried out on this extract. Acid/base and salt content of the material can be determined from these two values using mathematical models. This results in material of a constant standard accompanied by reduced costs incurred for water, energy and chemicals Keeps a continuous record of pH and conductivity values for online material

Display visualization options: large digits, bar graph, or trend display,Integrated calibration routines: 1, 2, and 3 points,Setup program features easy-to-use programming and system documentation,Meets all the requirements for ultra-pure water applications in Pharma+Food USP .

Direct Input Accept PH electrode, TDS/Conductivity cell TDS Ranges 0-9999ppm or 0-99.99ppt PH Range 0.00 to 14.00 PH, Pressure -1 to1000 Bar/PSI Resolution 0.001/0.01/0.1/1 selectable Display Range -1999 to 9999 Selectable 100-240 VAC mains operated with 24VDC Transmitter supply Offset, Hysteresis, Range selectable, Dual output Retransmission out put 4 -20mA optional Auto/Manual Temperature compensation

Owing to the sound industry experience, we have been successful in catering to the requirements of our esteemed clients by offering quality Conductivity Products. We offer our customers a wide assortment of Digital Conductivity Indicator and Digital Conductivity Controller under this category. These are widely used for measurement of conductivity of aqueous solutions. The offered devices are appreciated in the market for their features such as reliability & high performance.

Manufacturer of a wide range of products which include Conductivity Indicating Controller - ATN CD 09, Conductivity Indicating Controllers Model: ATN CD 912, Conductivity Indicating Transmitter - Field - ATN CD..

Advanced embedded micro controller based design Available in panel type, field type, and Flame proof and IP version Automatic Or Manuals Temperature Compensation Multi parameter display by a key press Check facility for quick analysis Two Programmable isolated relay outputs

Conductivity Controller, Phosphate Analyzer, Analyzer
