Diesel Smoke Meter Dealers

Our advanced packaging system assists us in meeting the bulk and customized packaging requirements of the clients. In addition, our packing experts ensure safe packaging of the products. Our team makes it possible to carry out online transactions, keeping the details confidential. Our payment procedures and the transactions we make are completely transparent and thus, clients can trust on us.

Diesel Smoke MeterThis is for all diesel powered vehicle and machinery. All data are fully controlled and processed by built-in microprocessor. Large LCD dot matrix indicator is installed for high accuracy test and easy reading. Test data can be printed-out with the equipped printer.

Future Electronic & System Is A Customer-Oriented Business Unit That Works With A Positive Attitude Towards The Clients. We Pay Prime Importance To The Requirements Of The Clients And Make Our Best To Meet Them Successfully. We Offer Varied Facilities To The Clients Such As Customization Facility, Easy Payment Modes, Timely Deliveries, Cost Efficient Range And Many More.

Diesel Smoke Meter is distributor sample type. It equips gas temperature pressure and dis-tributary control cell in order to ensure metrical stability and repeat. It can measure the whole bur then opacity smoke degree continuously and free speedup opacity smoke degree.

V-Smoke is a smoke (opacity) module suitable for use in repair shop, inspection centre and road-side tests for Diesel vehicle of any kind. The V-Smoke performs all measurements required by the typical Diesel emission test procedure: opacity, engine speed, oil temperature, etc. Data are available for remote sending for display, storage, printing-out, etc. The available battery and radio link make the V-Smoke very handy and comfortable of use.

Conforms to IS : 4553 – derived from ISO 6 4 : 999. Measures smoke opacity of diesel vehicles in % opacity and K value. Measurement principle : Partial flow, optics based on folded geometry. Suitable for free acceleration test. Engine RPM measurement – vibration sensor based and Battery based. Engine oil temperature measurement. Operates on 230V AC (or) 2V DC power supply. Portable, Compact & light weight design, suitable for “Road tests” using vehicle battery. Low & High voltage indication for battery operation. Automatic Zero and Span calibration. Automatic Pressure regulation and moisture separation. Handheld, Menu driven LCD remote control unit. Pass / Fail indication and emission limit in printout. Vehicle no., vehicle specification, operator name and test data in printout. RS232C serial port for PC interface.

Main Characteristics : Opacity measurement with partial flow continuous gas sampling Heated and temperature-controlled smoke chamber Easy and quick cleaning with no need of disassembling parts Any kind of test procedure available to be implemented on external device Automatic zeroing Software-supported calibration Measurement of gas pressure Measurement of engine speed (optional) Measurement of oil temperature (optional) 12 - 24Vdc power supply Standard RS-232 serial interfaces   Wireless Smoke (Opacity) Meter Module THE ONLY REAL WIRELESS SMOKE METER ON THE MARKET!For Diesel engine smoke (opacity) check both on cars and light and heavy commercial vehiclesRELIABLE: complies with most important standards worldwide like ISO 3173, ISO 11614 and SAE J 1667.PRECISE AND ACCURATE: the new smoke measurement chamber has the capability to compensate measurements with temperature and pressure.HANDY AND COMFORTABLE: battery power supply and radio communication with a PC or the V-pex console make the machine comfortable and harmless to operate on any vehicle even for roadside operations   General Description V-Smoke is a smoke (opacity) module suitable for use in repair shop, inspection centre and road-side tests for Diesel vehicle of any kind. The V-Smoke performs all measurements required by the typical Diesel emission test procedure: opacity, engine speed, oil temperature, etc. Data are available for remote sending for display, storage, printing-out, etc. The available battery and radio link make the V-Smoke very handy and comfortable of use.   Optional Accessories   12Vdc 24 A/h battery   Radio interface   Universal Diesel RPM 8500 measurement unit   Oil temperature measurement unit   Hand held terminal   Windows-compatible software   Hand held terminal   Windows-compatible software   Blue tooth

High quality microprocessor based machine which combines optical precision with robust design to give long & trouble free service Can be easily mounted on a free moving trolley for easy mobility. Option of adding non Thermal paper printing a record of the test result 220V AC or 12V DC vehical battery operation. Easy to operate front panel Meet all the requirments and norms as specified by Central MV Acts. Smoke sampling : Partial Flow, Zeroing: Automatic, Temperature:GAs Chamber Temp Display, Range:0-100% with 1% Resolution standard Acc. : Exhaust pipe, piezo sensor, RS232 cable, Electric cable, battery cable, Measuring probe (1nos)

The Smokemeter modules are designed to be used with the customer’s choice of PC or Laptop both of which can be easily integrated with existing trolley Fixed PC work stations The Smokemeter Module caters for all diesel vehicles, cars, vans, trucks, buses, plus light and heavy plant machinery - with sampling pipe options to suit different exhaust types. Bluetooth or cable communication between Smokehead and PCLaptop allows total freedom whilst performing an emission test. The robust smokehead is easy to handle, well balanced, and weatherproof and has a low warm-up time with accurate measurement down to at least -15 deg C. Wet or cold conditions present no problems to this emission analyser. The Smoke head has a Patented automatic self-calibration

We are reckoned as one of the reputed Manufacturers and Exporters of Diesel Smoke Meter in India. The Electronic Diesel Smoke Meter is light weight, portable enabling easy mobility. Nearly 1000 installations are working well across in India and abroad. Portable Diesel Smoke Meter is certified by the ARAI in India Battery based RPM measurement Suitable for road test using vehicle battery RS232C serial port for PC interface Portable light weight Model Eco Smoke Salient Features Measures smoke opacity of diesel vehicles in % opacity and K value Measurement principle : Partial flow, optics based on folded geometry Suitable for free acceleration test RPM and Engine oil temperature measurement Battery Based RPM measurement suitable for all vehicles Portable, Compact and light weight design DC operation suitable for "Road Tests" using vehicle battery Low voltage indication for battery operation Automatic Zero and Span calibration Automatic Pressure Regulation Handheld, Menu driven LCD remote control unit Pass / Fail indication and emission limit in printout Vehicle no., vehicle specification, Operator name and test data in printout RS232C serial port for PC interface Technical Specifications Measurement ParametersRangeResolutionOpacity0 - 99.9 %0.10%K-value0 - 99.9 %0.01 m-1Linearity± 0.1 m-10.1 m-1Repeatability± 0.1 m-1Zero & Span drift± 0.1 m-1Response time - Physical< 0.4 secondsResponse time - Electrical< 1 milli secondWarm up time< 8 minutesEngine RPM200 - 9990 RPM10 RPMEngine Oil Temperature0 - 1500 C10 CSmoke measuring cell length215 mmPrinter24 Column Dot matrix Power Supply12V DC (or) 230V AC ± 10%, Single phase, 50HzPower Consumption300 Watts in AC / 100 Watts in DCOperating Temperature+50 C to +500 C Standard Accessories : Smoke sampling hose : 1 No. Smoke sampling probe - ID 16 mm : 1 No. Oil Temperature probe : 1 No. Battery cable : 1 No. Optional Accessories : RPM sensor clamp assembly : 1 Set Smoke sampling probe - ID 22.5 mm & ID 10 mm : 1 No. Smoke test software : 1 No. RS232 PC Interface cable : 1 No. 24 Column Dot matrix Printer : 1 No.
