Glass Level Gauge Dealers

Bliss Anand Level Gauge standard construction includes a solid one-piece chamber machined from carbon steel with covers, toughened glass and chrome molybdenum bolds and nuts. All metal parts are rust proofed. Recessed gasket seat prevent movement and insure leak-free service. Sturdy Construction For clear liquids. High Pressure 4000 PSIG @ 100 Deg.F. Clear line of seperation visible from a distance. Variety of materials and Configuration. Visible length from 200 mm to 3000 mm.

Avail from us precision-engineered Flat Glass Level Gauge. The Reflex/Transparent Flat Glass Level Gauge series that we offer is manufactured using the finest metal. Our Flat Glass Level Gauges are most suitable for marine application, ship tanks. All valves are of Gun Metal flange type and feature heavy precession casting and framework stainless steel. The Flat Glass Level Gauge can easily be installed on tank body.

Gauge is fitted between two end blocks through gland packing. The Gauge is mounted parallel to tank so as to form a close loop causing tank liquid to seek its level in gauge. Guards are provided in the form of tie-rods C-channels around the gauges to protect it from accidental blows. End blocks have built-in isolating valve, Drain Valve & vent plug.

SIGMA’s Flat Glass Level Gauges are reliable means for accurate measurement and direct observation of process fluids. These are designed to match industry requirements of ruggedness and material mix to widen the scope of application in process tank, pressure vessels and other containers with fluids varying from ordinary water to highly corrosive chemicals.THE SYSTEM: The Flat Gauges are inevitable means for process fluid measurement when it comes to severity of conditions. The medium to be measured iamber of the level gauge as that of the vessel and is viewed through a glass window. SIGMA Gauge Valves form a major component of the flat glass gauges. Two gauge valves at the ends of the gauge chamber are connected to the tank. Under normal operations, the valves are kept wide open causing the pressure to equalize in the system thus permitting the liquid to seek its true level for observation along the visible length. SIGMA offers Reflex and Transparent type Flat Level Gauges as required by the industry.

Bliss Anand Level Gauge standard construction includes a solid one-piece chamber machined from carbon steel with covers, toughened glass and chrome molybdenum bolds and nuts. All metal parts are rust proofed. Recessed gasket seat prevent movement and insure leak-free service.

Technical Specification Tubular Level gauge for visual liquid level observation is very common in process industry. It is a simple and reliable device for direct reading in atmospheric or pressurized tank applications. It is mounted parallel, along the side of tank. As the process level fluctuates, the level in the transparent glass tube changes accordingly and gives local liquid indication. Technical Specification : New Bolted Gland with teflon packing ensures positive leak tightness for full vacuum as well as 10kg/cm2 pressure service.

Side mounted heavy duty tank level indicators are suitable for storage tanks, Batch tank, Day Tank, Receiver Tank. It is simple & reliable devices for direct reading in atmospheric or pressurised tank application. Glass Tube is fully protected by box section made out of M.S. channel 2 mm thick light weight & economical design. Heavy wall borosilicate glass tube 19 mm OD available in single length 3 meters. Extended length by coupling through a coupler.

Glass Level Gauges, Gauge Valve, Sight Flow Indicato

Glass Level Gauge, Gauge Valve, Magnetic Level Gauge, Level Switc

Application: - can be used in most of application - offer great advantages such as low initial cost, low operating cost, easy level reading - cannot be used when the separation level between two liquids has to be read (interface) - cannot be used when besides the level indication, the observation of the liquid colour is required - cannot be used when the process fluid is high pressure water steam - cannot be used when the process fluid can corrode the glass features: - the liquid level is distinguished by the different brightness of the reflex glass in water or in steam space - “right-handed” or “left-handed” according to.

Transparent Glass Tube Level Gauges, Volume Booste

Glass Level Gauge, Chemical Injection Ski

Reflex Glass Level Gauge, Brine Agitato

Weld Pad Flat Glass Level Gauge, Magnetic Oil Level Gaug

Flat Glass Level Gauges, Conductivity Instruments, Steam Desuperheater

Reflex & Transparent Flat Glass Level Gauge
