Magnetic Level Gauge Dealers

Process Control Devices offers a series of magnetic level gauge designed to measures the level of liquid in storage tanks. The magnetic level Indicator installed outside of a vessel or tank. The liquid level in the tank can easily be observed from the change of the bi-color capsule or roller type. Optional devices of magnetic switch and level transducer can be installing for electrical signal output and 4-20 mA level transmitting. The By-Pass indicator utilizes hydrostatic principle to indicate the liquid level in the tank. A float with a magnet inside rises and drops according to the liquid level change. Magnetic flags / Follower capsule will flip as the float passes through to indicate liquid level based on magnetic attraction method. The position of the follower capsule/magnetic ball can be read against the engraved scale. We are the reputed manufacturer in Mumbai India for Side mounted Magnetic Level Gauge.   Features  ► A Simple magnetic principle used to get unique, absolutely safe and most reliable level indicator for dangerous liquids even under high pressures ► As the liquid level rises in the tank, the float is lifted up due to buoyancy. ► The magnetic float gauge is designed so that fluid begin measured is enclosed within the sealed chamber. ► A float fitted with permanent magnet moves freely inside the chamber w.r.t. liquid level.   ► And activates the flapper/ capsule/ ball to move outside the chamber.   Specifications  ► Liquids : Acids, Alkalies, Solvents, Oils, Lubricants, Condensate Water ► Sp. Gravity: Minimum 0.7 ► Viscosity: Up to 250 cp ► Design Temperature: -20 –  400°c ► Design Pressure: Up to 25 Kg/cm² ► C/C Distance: 300 to 4000 mm ► Material of wetted Parts: SS 304, SS 304L, SS 316, SS 316L PTFE Lined ► Connection: Flanged to ASA, BS, DIN, Triclover

SIGMA's Magnetic Level Gauge provides level indication in a range of operating conditions. It offers maintenance- free, preventive security against leakage, environmental safety, sure and trouble free application against chemically aggressive, harmful or poisonous, inflammable or explosive, pollutants or optically similar fluid interface.Sigma magnetic level gauge consists of a float chamber, a float, and an external indication device. An engineered float travels inside the gauge and follows the vessel level. The float carries an internal magnet that simply "flips" the flags thus indicating the level. The flags remain flipped until the float returns in the other direction. The magnetic level gauge is unique in that if the flag display is hit nothing will leak as they are magnetically coupled to the float. The float type is determined by the process fluid specific gravity, pressure and temperature. The materials of construction must be compatible with the process fluid. Each float is engineered for proper buoyancy for each particular application for level or interface measurement.

Magnetic Level Gauges is for use in various industries. May it be Oil and Gas, Refineries, Chemical and Petro-chemicals, Fertilizer or Utilities, we have comprehensive and application specific solutions for measurement

MAGNET EMBEDDED INSIDE THE FLOAT WILL MOVE UP AND DOWN ACCORDING TO THE LIQUID LEVEL IN THE MAIN VESSEL. A LIGHT WEIGHT MAGNETIC FOLLOWER INSIDE THE GLASS TUBE WITH ADJACENT PLASTIC SCALE COUPLED TO THE CHAMBER INDICATES FLOAT POSITION AND THEREFORE TANK LEVEL.

Telelin Magnetic level Indicators (gauges )or capsule type level indicator have very simple design using simple magnetic principle .Level being indicated by follower capsule type float which is inside the glass tube which is in turn moved by magnetic float in the main pipeline . Our Model TL-125 is demanded for is durable use in critical applications like flammable toxics , Acids , Chemicals , fluids having high temperature and high pressure thus making us the leading exporter, supplier of magnetic level indictors from india .

Second unit fixed on mounting flange. The magnet assembly moves up & down in the main S.S. pipe chamber. The float magnet is operated by magnetically coupled to the follower red magnet outside chamber which is mounted on front side of the main S.S. pipe, Simple principles of mechanics and magnetism harnessed to offer an absolutely safe, reliable and trustworthy level indicator for dangerous and toxic liquids under high pressure and Temperatures.

We make available Magnetic Level Gauges which are known for their make and long service life. Our strong association with the renowned vendors in the market helps us in fetching the outstanding array of raw materials and that too after complete inspection. We keep our standards high to maintain quality throughout. We make available a huge product basket that our quality auditors check closely to maintain the set standards.

Our range of Magnetic Oil Level Gauge is ideal for power transformers. Primarily used in Power Generation sector, our range of Magnetic Oil Level Gauge is designed, using quality materials and components to assure outstanding performance at client’s end. Dial marking of these Magnetic Oil Level Gauge is available in standard as well as in customized form.Features Generally suitable for power transformers Model available-conventional or aircell Gauge can be supplied with one mercury switch for low oil level or two mercury switch for low and very low oil level Mounting can be vertical or inclined at 15° / 20° / 30° Housing and body is pressure die casted and assembly is power coated Dial markings are standard or as per customer requirement Assembly tested at ERDA-BARODA for IP-55 as per IS-2147 Suitable for transformer oil or silicone oil, temp 0o to 100 oC

Backed by an efficient network and trustworthy resources, we have emerged as a dominant supplier of Level Gauge in the market. The complete assortment of raw material sourced undergoes stern examinations by the professionals to keep the quality standards high. Owing to this, we are capable of bringing forth exceptional quality products. Features Corrosion resistant Sturdy metal built Mechanical application

We are the leading manufacturer, exporter and suppliers of Magnetic Liquid Level Gauges in Maharashtra, India. This Glandless gauge comes a with magnetic coupling for visual level indication of Inflammable, Hazardous or Toxic Liquids, where glass is unsafe and dilute caustics where glass is unsuitable. The offered range of level gauges find applications in textile dyeing, Sewage Water Processing, Power Generation, Chemical Processing, Heat Transfer Petrochemical and Pharmaceuticals. We are capable of handling bulk orders as per specifications of the client.   Details : Glandless gauge with magnetic coupling for visual level indication of Inflammable, Hazardous or Toxic Liquids, where glass is unsafe and dilute caustics where glass is unsuitable. Range - 300 to 5000mm Density - ≥0.5 g/cm3 Wetted Parts - SS304/316,PP, PTFE or PVDF Indication - Bicolored Flappers or Follower Capsule Max Temp - 400oC Max Pressure - 20 Kg/cm2 Options - Alarm Switches, X’mitters , HART, Steam Jktg, Electrical Heat Tracing, High Temp. Insulation Applications : Textile Dyeing, Sewage Water Processing, Power Generation, Chemical Processing, Heat Transfer Petrochemical & Pharmaceuticals.

Telelin Magnetic level Indicators (gauges )or capsule type level indicator have very simple design using simple magnetic principle .Level being indicated by follower capsule type float which is inside the glass tube which is in turn moved by magnetic float in the main pipeline . Our Model TL-125 is demanded for is durable use in critical applications like flammable toxics , Acids , Chemicals , fluids having high temperature and high pressure thus making us the leading exporter, supplier of magnetic level indictors from india .

Backed by an efficient network and trustworthy resources, we have emerged as a dominant supplier of Level Gauge in the market. The complete assortment of raw material sourced undergoes stern examinations by the professionals to keep the quality standards high. Owing to this, we are capable of bringing forth exceptional quality products.

Magworld is a leading manufacturer, supplier and exporter of varied range of ndt products, having a wide national and global business network with the objective of providing ndt products & services with the level of quality, reliability and integrity demanded by various industries that rely on non destructive testing methods. We are located in hyderabad, telanagana.

Magnetic level gauge to measure the level of fluids. Fabricated using superior quality basic material by employing advanced machinery and sophisticated tools, these products compiled to the defined parameters of the industry in an efficient manner. These magnetic level indicators are mainly used in the hazardous pressurized vessels. Therefore, customers can avail these offered products from us in multifarious sizes and specifications as per their requirement.
