Orbital Shaking Incubator Dealers

backed by profound experience of our experts, we are an unparalleled name engaged in providing a high-quality assortment of orbital shaking incubator. product details: frequency 50 hz power 220v ac temperature range (degree celsius) 5 to 75 degree celsius with door lock yes display digital .

We are one of the leading supplier & trader of Orbital Shaking Incubator.Features: Digital Display Temperature Controller Automatic restart at preset speed in case of power failure Shaking amplitude 25 mm Variable speed from 20 RPM to 250 RPM Universal Platform to accommodate interchangeable clamps of assorted sizes for different capacity of flasks.

Use:- These units are designed for the growth of biological cultures & the shaking of the chemical solution Construction :- The unit comes with precise dynamically balanced shaking apparatus with microprocessor based PID temperature controller cum indicator with Pt- 100 sensor and digital timer with buzzer alarm for producing smooth rotating motion in 1” orbit. Heavy duty double wall incubation chamber with exterior made up of GI MS epoxy powder coat finish & interior of SS- 304. It is a vertical unit with magnetic gasket on the door to provide perfect sealing of the inside chamber. The door is fitted with a full-view polycarbonate acrylic sheet of 6 mm thickness for easy view of the inside chamber. The illumination of the chamber is by fluorescent lamp for easy viewing. The digital RPM indicator cum controller is provided with the speed range of 50 to 200 RPM with 25 mm orbit by PMDC motor. PUF insulation is provided between inner & outer walls. Interchangeable shaking platform can be given as option. Uniformity of temperature inside the camber is achieved through a flange mounted motorized blower from the back. The unit is also fitted with a special interlocking safety door switch for auto shut-off of shaking motor when the door is open. There is provision for two SS wire mesh trays at the top of incubator.

Having temperature range 50C to 60 0C +0.50C inside chamber made so stainless steel .Temperature controlled by electronic digital temperature indicator –cum controller with standard shaking plat form to accommodate 9 flasks of 500 ml capacity. Complete with 2 nos. of 600 mm fluorescent tubes on the back of inside chamber & timer. Size of shaking incubator 600mmx500mmx500mm 875mmx570mmx550mm 900mmx650mmx580mm Additional Shaker Platform to accommodate other capacity of flasks to cost extra.

We offer Orbital Shaking Incubator. Standard double wall construction outer chamber made out of mild steel finished in solving enamel paint inner chamber made of stainless steel the double door is provided with double glass full view window interchangeable platform has been ambient to 60 c +2 c is controlled by a soiled state electronics controller .variable speed control regulator controls the speed upto 200 rpm supplied complete to work on 220v ac 50hz single phase. Capacity 16x500ml conical flash. Same as above but temp range 10 c to 50 c with light arrangement.

• Stainless steel inner chamber, outer sheet steel powder coated with plexi glass inner door • Powerful and continuous air circulator for uniformity of temperature • Digital Display temperature controller • Shaking Speed 20 to 250-300 rpm variable • Step less speed regulator with digital display of speed • Universal platform to accommodate interchangeable clamps of assorted sizes for different capacity of flasks OR   • Any one of this following platform with clamps     100 ml x 40 flasks 150 ml x 34 flasks     250 ml x 23 flasks 500 ml x 34 flasks •   1000 ml x 9 flasks   • Maximum load it carries 15 kg • Built in timer 0-24 hrs continuous operation • Orbital stroke at 25 mm • Chamber illumination by CFL Bulb • This unit can be used simultaneously as incubator as well shaker

We provide tripled walled Orbital Shaking Incubator cum B.O.D. Our Orbital Shaking Incubator is designed to control incubation with orbital shaking arrangement. The Orbital Shaking Incubator is demanded by clients owing to its performance and long life. Moreover, the Orbital Shaking Incubator has a powerful geared motor for many laboratory procedures such as tissue culture, Fermentation studies, Enzyme reaction, growth studies etc. Construction Outer chamber made up of M.S. Sheet duly painted or powder coated & inner chamber is made of thick S.S. Sheet.The gap between walls is fitted with high grade glass wool to avoid thermal loss.The plexi glass window makes it possible to inspect the specimen without disturbing the inner temp.Incubator illuminated with one door operated or panel operated flurescent tube.The unit has a temp range from 50C to 600C. Temperature controlled by Dual Display Microprocessor PID Digital Temperature Indicator cum Controller with a accuracy of ±0.50C.Air circulation fan provided to maintain stability throughout.Speed of shaker variable from 30RPM to 250RPM.The tray of the shaker made of S.S. Sheet with Lotus type clamps to hold flasks.Unit fitted with Digital RPM meter 999min digital time. Optional (Extra Cost) Timer 0-24 hoursAutomatic Voltage stabilizer 3KVA(Most Rec.)

Temperature controlled by Digital Temp. Controller cum indicator 5° to 60°C, with an accuracy of +/-0.5°C or better. Temperature below ambient is maintained by a hermetically sealed compressor with complete unit placed beneath the chamber. Shaking speed can be controlled by steeples speed regulator and fitted with D.C. drive, shaking speed indicated by Digital RPM meter. A stainless steel perforated tray is also provided for the use of upper portion of the chamber as a simple bacteriological incubator. An illumination lamp is also provided inside the chamber, Illuminating system with 3nos. light with 0-24 Hrs timer is also provided to crate the day/night effect. suitable to work on 220/230 V, 50Hz. Single phase AC supply. CHAMBER SIZE: 625 X 550 X 550 MM (W x D x H) Optional Accessories for SHI -133 & SHI-134 Digital Programmable Timer Spare platform to accommodate other capacity of flask. Voltage stabilizer Shaking Platform can also be designed as per your specifications.
