CNC VTL MACHINE OM
MAKE - OM MODEL- TM2 -10N CONTROL - Fanuc 21 T Specification : Table Diameter - 1000 mm Maximum Cutting Diameter - 1100 mm Maximum Cutting Height - 750 mm
CNC Turning Lathe Machine
CNC Turning Lathe Machine designed by us is very rigid and durable. Our models of the CNC Turning Lathe Machine fulfill all specifications of the buyers. CNC Turning Lathe Machine has features to enable proper shaping of metals and other substances. The CNC Turning Lathe Machine that we offer is very affordable. Features of CNC Turning Lathe Machine Most User Friendly Dual Programming System. Readily available Machining Cycles. Standard ISO Programming Using G & M Codes. Very High Levels of Torque Auto Speed Range Change with CSS. Fully Enclosed Guarding For Enhanced Safety. Standard Accessories CNC System Oi Mate TC, Spindle motor and Servo motors from Fanuc LCD Touch Screen 7.2" with Large Graphic icons RS 232 port and PCMCIA Card slot 4 Way automatic square tool post Fully enclosed guarding and chip collecting tray Coolant equipment Automatic lubrication of the slide ways Constant surface speed Electronic hand wheels for the X and Z axis Low voltage work light Main spindle reducing bush and fixed centers Instruction manual. Optional Accessories Steel universal 3-jaw chuck Independent 4-jaw chuck Face plate Fixed steady rest pad/roller type Follow rest pad type Rear tool post Turning Tool holder for Rear tool post Boring Tool Holder for Indexing Tool Post / Rear Tool Post Morse Taper Tool Holder for Indexing Tool Post / Rear Tool Post Revolving Centre Reducing Sleeves 8 station Automatic Turret Hydraulic Chuck Hydraulic Tailstock Hydraulic Powerpack Foot Pedal for Hydraulic Chuck 3 Modes of Operation Like a Conventional Lathe : 2 Electronic Hand Wheels are provided so operators can use the Lathe like a Conventional Lathe Smart Turn Programming Mode Operators using manual Lathes can use the SMART6 system without having CNC experience. Machining is carried out by using a comprehensive choice of automatic cycles selected through the touch screen. Complete range of automatic turning cycles. Capacity to save up to 40 different operations that can be linked in a single program makes the machining of complex components fully automatic. Tool offset for upto 16 Tools. Inch or Metric display. Possibility to program cutting parameters (feed, spindle speed, tool) differently for each cycle. ISO Programming Mode Using standard ISO codes like G / M codes, possibility to program all type of operations and automatic movements. Capacity up to 64 different offsets for tools. 240 KB memory capacity for programs.
CNC Lathe Machine
Maximum Swing Dia : 210 mm
Maximum Turning Length : 400 mm
e have been successfully satisfying the diverse needs of our esteemed customers by providing a flawless gamut of CNC Lathe Machine. This is widely renowned among customers for its high performance, efficiency, easy operation and rugged construction. Moreover, this can also be availed by customers in various customized options as per their varied requirements. In addition to this, the offered chucker can be availed by customers at the most reasonable prices. Slide Movement (X / Z Axis): 140 / 400 mm (Box Hard & Ground with Turcite) Chuck Dia Maximum: Dia 165 mm / Dia 200 mm System: CNC, Fanuc make (Siemens make Optional on Customer Demand) Tailstock: Hydraulic 8 Station Turret : Standar
Cnc Vertical Lathe
Swing Diameter : 350 475 575
Max Turning Diameter : 300 400
Machine is suitable for accurate & precision machining of medium and heavy weight work piece. CAD optimized High static and dynamic stable machine structure using Damping Concrete Polymer Composite Machine base ensures minimum vibrations. Heavy duty work spindle. Most effective use of plant space because of Compact foot print and clear side. High precision Preloaded Heavy duty Linear Roller guide-ways for high stiffness and rigidity. Higher tool life because of rigid and balanced structure. Easy setting changing of fixture.
Cnc Lathe Machines
