SEKO BEC PRIVATE LIMITED Cherlapally, Hyderabad, Telangana

Condition : Nwe

Type : Drilling Machine

Material : Steel

Power Source : Diesel, Electric

Voltage : 220V, 380V

Weight : 500-2000 Kg

Application : Water Well Drilling, Geothermal Drilling

Features : Portable, Easy To Operate

Capacity RIG CARRIER Wheel Base ROTATION HEAD Max. Output Torque FEED Max. pull up force Max. Pull down force Max. Pull up speed Rope Multiplier AUXILARY WINCH Max. Lifting Capacity Max. Lifting speed MAST RAISING CYLINDER Number of Cylinders Max. Capacity of each Cylinder HYDRAULIC LEVELLING JACKS Cylinder Specification Number of Cylinders Max. Capacity of each Cylinder WATER PUMP Capacity HYDRAULIC OIL COOLER Heat Dissipation Capacity Maximum Flow Fan Speed ENGINE Capacity Model : : : : : : : : : : : : : : : : : : : : : 612” Dia DTH Holes upto 800' in Hard Formation ASHOK LEYLAND TUSKER SUPER 1616 4700 mm 341 kg. Mt. @ 100 RPM 8180 kg. 5613 kg. 30 Mtmin 1:3 300 kg 10 Mtmin 1no 12566 kg. @ 160 bar H175 Dia 100Dia 63 NCLM 610 4 Nos 12566 kg. @ 160 bar 50 LPM @ 400 PSI (28 bar) 40,000 K.Calhr 300 lpm 1500 rpm Truck Engine through Center Gear Box 160 HP @ 2600 RPM ASHOK LEYLAND AL 412

TECHNICAL SPECIFICATIONS CAPACITY : : 450mm dia holes upto 50 mtrs by DTH method in steps. MOUNTING : Skid - Carry on Truck TOP HEAD Driving System : Hydraulic Motor & Gear Box Max. Torque 450 kg.mtr Max. RPM : 0 to 80 RPM FEED SYSTEM Driving System : Hydraulic Cylinder with Chain Combination Max. Thrust force : 19000 kgs HYDRAULIC LEVELLING JACKS Number of Cylinders : 4 Nos. Max. Capacity of each Cylinder 19635 kgs. Cylinder Specification 125 dia x 70 dia x NCLM610 WELDING GENERATOR Capacity of Welding Gen. Set 400 Amps WATER PUMP Capacity 50 LPM @ 400 PSI HYDRAULIC OIL COOLER Heat dissipation capacity 50,000 K.cal hr Max. Flow 400 LPM DECK ENGINE Make CumminsEquivalent Capacity 260 HP @ 2600 RPM

Mounting Drilling Capacity TOP HEAD: Driving System Max. Torque Max. RPM FEED SYSTEM: Driving System Max. Pull down force HYDRAULIC LEVELLING JACKS: Max. capacity of each cylinder Cylinder Specification MUD PUMP: Model Capacity DECK ENGINE: Make Capacity WATER PUMP: Capacity WELDING GENERATOR: Capacity HYDRAULIC OIL COOLER: Heat dissipation capacity Max. Flow AUXILIARY HOIST: Capacity : : : : : : : : : : : : : : : : : : : : Ashok Leyland TaurusTATA Vehicle 6 12" dia holes upto 2000 ft. by DTH method. 14" dia holes upto 2000 ft. by Rotary method in steps. Hydraulic Motor & Gear Box 740 kg.mtr. 0 to 120 RPM Hydraulic Cylinder with Wire Rope Combination 30000 kgs 19000 kgs 4 19635 kgs 125 dia x 70 dia x NCLM 610 CBG 1405 LPM @ 20.01 kgcm2 driven by Hyd. Motor CumminsEquivalent 410 HP @ 1950 RPM 80 LPM @ 95 kgcm2 driven by Hyd.Motor 400 Amps driven by Hyd. Motor 50,000 k.calhr 400 LPM 2000 kgs driven by Hyd.Motor

Drilling Capacity ROTATION HEAD: Max. Output Torque FEED: Max. pull up force Max. Pull down force Max. Pull up speed 1 TON AUXILIARY WINCH: Max. Lifting Capacity Max.pull down force MAST RAISING CYLINDER: Number of Cylinders : : : : : : : : 115152 mm dia holes upto a depth of 45 mtrs by DTH and Odex method 200 kg. mtr. @ 60 RPM 5500 kg. 4500 kgs 15 mtr min. 1000 kg 10 mt min 1 No. Max. Capacity of cylinder : 11782 kg. @ 160 bar Cylinder Specification : 100 Dia x 50 Dia x NCCM 800 HYDRAULIC LEVELLING JACKS: Number of Cylinders : 4 Nos. Max. Capacity of each Cylinder : 11782 kg. @ 160 bar Cylinder Specification : 100 Dia x 63 Dia x NCLM 610 BREAKOUT CYLINDER: Max. Pull back Force : 9428 kg. WATER PUMP: Capacity : 36 LPM @ 400 PSI ( 28 bar) HYDRAULIC OIL COOLER: Heat dissipation capacity : 40,000 K.cal hr Max. Flow 200 LPM

CAPACITY : : 800mm dia pile by Auger Drilling. MOUNTING : Heavy Duty Crawler ROTATION: : Bent Axis Hydraualic Motors & Spur Gear Box Torque : 4000 kg.mtr. Speed : 10 to 90 RPM Feed Pull up : 30 Tons Pull down : 14.7 Tons Main Hoist : 12 Tons Auxiliary Hoist : 6 Tons Power Pack : Hydraulic Pumps Max Drilling depth : 25 mtrs.

Availability : 28 kg

Number Of Flower : Horizontal Single Cylinder

Drilling Capacity TOP HEAD Driving System RPM Max. Torque FEED SYSTEM Driving System Max. Pull down force Max. Pull up force TRACK DETAILS Track shoe width Track length Track width Max. Speed Gradability DECK ENGINE Make Capacity AUXILIARY HOIST: Capacity MAIN HOIST: Capacity HYDRAULIC LEVELLING JACKS Number of Cylinders Max. Capacity of each cylinder Cylinder specification MUD PUMP Make Model Capacity : : : : : : : : : : : : : : : : : : : : : : 254 to 610mm dia holes upto 30 ft. Hydraulic Motor & Gear Box. 0 – 60 RPM 500 kg.mtr @ 30 RPM Hydraulic Cylinder & Multiplier 2200 kgs 3800 kgs 260mm 3300mm 2000mm 1.6 kmhr 30 deg. Ashok LeylandEquivalent 128 HP @ 2400 RPM 1000 kgs driven by Hydraulic Motorangle hole drilling 4000 kgs driven by Hydraulic Motor. 4 Nos. 11782 kgs 100 dia x 60 dia x NCLM610 Kirloskar Centrifugal 2000 ltrsmin
