Microcontroller Based Tourniquet Electronic Unit
Brand Name : A.d's
Condition : New
External Body Size : 9.5 Inch (w) X 5 Inch (h) X 12 Inch
Electrical Input : 230 Vac/ 50 Hz, with Proper Earthing.
Memory : All Settings Used in Earlier Session is Stored & Displayed When Machine is Switched On Again
Cuffs : 5 Numbers Silicon Cuffs
Salient features:- 1) 1MMHg controlling (resolution) 2) Single & dual cuff tourniquets are available for all surgeries. 3) Very reliable controlling system is used for perfect pressure. 4) Rugged compressor. 5) User friendly interface. 6) Feathers touch keys. 7) Very bright indicators. 8) Highly stable & compact power supply, hence machine Can be used anywhere, where voltage fluctuations are more. 9) Inbuilt memory to store earlier settings. 10) Air leakage indicator to show air leakage in the cuffs & tubes. 11) Gradual pressure settings & gradual release system. 12) Online increase & decrease of pressure, timer, exhaust. 13) Beep after each 15minuts. 14) After presetted time is complete 1 minute extra time count is provided. 15) On completion of total sited time buzzer beeps continuously but pressure will be maintained at the same level, also it will not be released. 16) Cuff pressure will not be released on power failure. 17) Can be used with inverter power supply & generator. 18) Both hardware & software based exhaust available. 19) We provide 5 numbers of silicon cuffs (life time guarantee on joins) with machine. 20) Light weight machine, easy to carry anywhere. 21) Low power consumption. 22) Can be used for all types of patients (any physical condition) 23) Lowest risk to patient when compared with other machines. Technical specifications:- 1) Settable pressure range 50mmhg to 650mmhg in steps of 10mmhg. 2) On line setting allows online settings of cuff pressure, timer & exhaust. 3) Pressure resolution 1mmhg. 4) Timer safe mode 1 minute to 6 hours in 15 minutes steps. 5) Alarms beep after each 15 minutes, total time out, exhaust mode, & air leakage mode.Operating modes visual indications:- A:-air leakage in either cuffs or in the tubes. O:-operating mode (normal operating) T:-timer mode. S:-setting of cuff pressure mode. E:-exhaust mode. (Software or hardware)
control unit
1 Piece (MOQ)
Country of Origin : India
Certification : ISO 9001:2008
Weight : 1000-2000kg
Voltage : 110V
Condition : New
Power : 1-3kw
Driven Type : Electric
A control unit is comprised of the hand crank and gearbox, a pair of control housings, a teleflex drive cable and a safety connector assembly.
electronic control units
Electronic control unit in conjunction with level switches can be used for pump control, opening and closing of electrically operated valves, heaters and or high and low level indication. The electronic unit Model LC1 FL reduces the voltage and converts it to 5 VDC for operation of reedswitches enhancing their life, above all ensuring operational safety. The LED's in the front panel indicates Main Power Supply On, Pump Start and Stop conditions. The start/stop push buttons in the front panel enables testing of the control unit and also manual start and stop. The control unit has a Change over potential free relay output contact-hold on type. Contact change over takes place between High and Low level only. Relay contacts are rated 5 Amps at 230 VAC. Control action can be reversed at site by changing connections from NC to NO. For certain applications where high and low level indications are required, 2 separate relay output contacts are provided in the control unit-with LED indications for High, Low and Mains on Model LC2FL are used in boilers where High and Low Level Contacts are used for Pump start & stop while Very Low Level Contact is used for heater cut off.
control unit
Operating Voltage : 10-30V DC
Mounting Dimension : 8mm to 36mm (Box type available)
Sensing Range : 1mm to 25mm
Maximum load current : 300mA
Hysteresis : <-15% of sn
Operating temperature : -20 o C to +70 o C
Output contact : NO or NC
Switching frequency : 25Hz to 40Hz
Led Indication : Yes
Housing : Chrome plated brass
Cable : 3 core 2m long
Electronic Control Unit For Sequential System
