Single Point Load Cell
Material : Aluminum
Application : Platform Scale
Model : CZL-642
Capacity : 500 Kg
Ingress Protection : IP65
Features : Hermetically Sealed
Output Sensitivity(FS) : 2.0 +/- 0.1 mV/V
Creep Error (30 minutes) : +/-0.025% FS
Temperature Effect on Zero : +/-0.03% FS/DegC
Temperature Effect on Output : +/-0.03% FS/DegC
Zero balance : +/- 1% FS
Maximum Safe Overload : 120% FS
Recommended Excitation Voltage : 9 to 12V DC
Input Resistance : 400 +/- 10 Ohms
Output Resistance : 350 +/- 5 Ohms
Insulation resistance at 50V DC : >= 5000 M Ohm
Compensated Temperature Range : -10 to +40 Deg C
Operating Temperatue Range : -20 to +70 Deg C
stainless steel load cell
Our product series include : Metal Round Shell Connectors- 2 pin,3pin,4pin,5 pin,7 pin, 8 pin Berg Strip - 40*1,40*2 , 40*2 RA Frc Connectors Flat cable- 10p,14p,16p,20p,26pin. DB9 Connector terminal connector- 2pin 126 10 & 12mm Traingular domes key Seven Segment Display
Bending Beam Load Cell B 310
B-310 is bending beam load cell available up to 200 kg capacity with class c3 accuracy mainly used for platform scales, belt weigher, bag filling and small capacity of vessel weighing systems. This load cell is made from stainless steel and having hermetically sealed to ip 68 protection.
Ultrasonic Level Sensor UM0017
Load Cell
M.G.Group is one of the leading manufacturer,exporter & supplier of a wide range of load cells such as table top load celll,plat form load cell,weighbridge load cell,jwellery scale loadcell and more.
