Needle Valve Dealers in Goregaon East, Mumbai

We have gained complete customers satisfaction as we make maintain proper schedules for the delivery of the consignments Our product is available in nontoxic and industrial-grade packaging materials that ensure the products are safe from damage and reach buyers in brand new conditions. Features: Positive shut off Longer life Quick in action No lubrication

Body Materials: SS 316, SS 316L, SS 321, Duplex 2205, Titanium, Alloy 400, Alloy 625, Alloy C-276. Pressure Rating: 3000psig (203 bar), 6000psig (413 bar), 10000psig (690 bar) @ 38°C (100°F). Temperature Rating: -53°C (-65°F) to 232°C (450°F) with standard PTFE packing, up to 648°C (1200°F) with Grafoil packing. Size: 1/4″ to 1″, End Connection: NPTM/NPTF, Tube to Tube. Threads with smooth surface finish avoid galling and help to extend the fitting service life.

Applications   Needle Valves are used for flow control, isolation purpose, on /off applications. Suitable for pressure upto 400 kg/cm2 and higher.   Features   4 Material SS316 or SS304 4 1/4", 3/8”, ½” bsp or npt connection 4 Pressure Rated upto 400 kg/cm2 and higher

B.S.Hydro needle valves are in square forged body design manufactured for corrosive and hazardous environment. Needle valves are used in process control, instrumentation and flow control application. These needle valves are precision machined for durability and maximum efficiency.   Features : Square forged body design Precision machined stem with Vee tip T bar handle/ Knob type handle Metal to metal seating PTFE packings Specifications : Size: 1/8”,1/4”,3/8”,1/2”,3/4”,1” End connection: BSP/NPT Threads , Tube ends Pressure rating: 6000 PSI ( 400 BAR)< /li> Material: steel, Stainless Steel, Monel Applications: Process control Instrumentation Flow control applications Oil and gas applications General application for isolation and shut off.

FEATURES  Available in SS316, all wetted parts in accordance with NACE MR01-75•  Heat Code Traceable to certified material test report•  Low operating torque•  Bar Stock Body in Straight Pattern, Panel mountable•  Rolled and plated threads for greater strength and smoother operation.•  Packing below the threads prevents lubricant washout.•  Anti Blow-out stem provides positive back seal in full open position.•  Stem packing below the threads protect the flow stream from lubricant     contamination   on the threads or washout and also protect stem thread     from potential damaging   effect of the media.•  Viton®  O-Ring and back-up Ring seal.•  Variety of stem tips to provide greater flexibility•  Orifice size : 0.156" (4mm) and 0.250" (6.4mm) •  Flow coefficients (Cv) from 0.35 to 0.86•  Variety of stem tips to provide greater flexibility•  Variety of end configurations includes Male/Female NPT, BSP, BSPT pipe    connections. •  Every valve is factory tested. OPERATING PARAMETERS Pressure Rating           : Upto 10,000 psig (680 bar) at CWPTemperature Rating   :  Upto120ºC STEM TYPE SEALEXCEL Needle Valves are available with choice of optional stem to provide greater flexibility.NON-ROTATING (NR)         : It is Standard self centering non rotating stem tip typically used in high cycle application to extend                                                    the valve life. V-STEM (VS)                         : It is used for general purpose liquid and gases.REGULATING STEM (RS)   : It is used where some degree of flow control required. APPLICATIONS •  General Plant Service•  Hydraulic and Pneumatic•  Pressure measurement devices •   Venting

Used on general instruments, Air, Gas, Vaccum, Chemical Processing, Hydraulics, Refinaries, Petrochemicals, Fertilizers etc.   Special Features :- One piece design, having integral bonnet / Seat. Screwed bonnet type with Integral seat and renewable seat. End Connection, Screwed to NPT, BSP, BSPT, tube end connections, Male and Female combination. Material of construction - Brass, St.Steel, Steel Plated, Monel, alloy steel F 11 / F / 12, F22, Hostelloy etc. Max Working Pressure - Suitable for 3000# PSIG at 30C Max Working Temprature - Metal Seat 230C. Soft Seat 120C Valves can be offered with IBR Certificates.

Needle Valves Needle Valves are used for flow control, isolation purpose, on off applications. Suitable for pressure upto 400 kgcm2 and higher.Pressure Rated upto 400 kgcm2 and highe.

Our expertise lies in offering a wide range of needle valves including Stainless Steel Needle Valves, Screwed Bonnet Needle Valve, Forged Body Needle Valve, Union Bonnet Needle Valve, Female Needle Valves, Male Needle Valves, Female Male Needle Valves and Tube End Needle Valves. Backed by rich process knowledge, we can deliver these valves in both standard as well as customized specifications as demanded by our customers.

Needle valves are small valves used for flow control in liquid or gas services. The fine threading of the stem and the large seat area allow for precise resistance to flow.

Features   All AKI Instrument valve including those used with instrument Air Feed Headers are produced for working pressure 6000 PSI. Stem design with no turning action on closure thus preventing galling. Threads Protected from process media. Forzed or Bar Stock Construction in straight or angel pattern with panel mounting type. Screwed bonnet, union bonnet and integral body bonnet construction, Valves. Metal to metal or stellited and non rotating tip stem for high pressure, Teflon seal for positive repetitive shutt off for low density gases and non lubricating fluide. Special Telfon as grafail packing for leak proof joint at various temperature. The Sophisticated and costly instrument used in complex plants need to be installed according to certain carefully laid down safeguards using selected and reliable accessories. Most of the instrument valves produced without any adherence to the rigid codes of the instrumentation industry are unsafe to high pressure use. These Valves cheaply produced have common deficiencies:Their seal just an 'O' ring Spindle cannot take wear. Leakage due to galling at the tip Spindle Which rotates on closure is prone to galling Normally threads are in contact with process media. AKI Needle Valve are specially designed to eliminate all the above deficiencies and produced under rigid qually control from basic raw material stage. Valves are precises machining on mordern machinery to provid high quality and low cost, to meet the exacting standards of our valuable customers.

30,000 psi needle valves: max working pressure : 30,000 psi (2069 kgcm2) @ 25ºc (77ºf) max. Temperature : 210ºc (410ºf) testing pressure : hydrostatic body - 45,000 psi (3103 kgcm2) hydrostatic seat - 30,000 psi (2069 kgcm2) pneumatic seat - 569 psi (40 kgcm2) service medium : liquid gas or vapours service types of valves : needle valve - straight type, angle type (90º) two way & three way two piece, nonrotating stem tip two piece, nonrotating stem tip connection size : 14” , 38” , 916” orifice size : 2.4 mm (0.093”) gland seal (packing) : glass filled ptfe: temperature min. -73ºc (-99.4ºf) to max. 210º (410ºf) material : ss 304, ss 316, ss 304l, ss 316 l with nace mr-01-75 & nace mr-01-03 (for sour gas service) material certificate according to en 102043.1b body - cold worked stainless steel handle - stainless steel bar stock finish : ss natural mounting arrangement : needle valves - integral through-holes for bracket mounting panel mounting option is also available. Standard followed : ansi b 16.34 gland seal : ptfe(standard) : for temperature range -73ºc (-99.4ºf) to 210ºc (410ºf) graphoil : for temperature range 180ºc (356ºf) to 540ºc (1004ºf) material : carbon steel, ss 304, ss 316, ss 316 l, monel 400 nace mr-01-75 & nace mr-01-03 (for sour gas service) can also be provide material certificate according to en 102043.1b finish : carbon steel - zinc plated & dichromated, ss natural mounting arrangement : needle valves - panel mounting design standard : ansi b 16.34

Tiger" Brand Needle valves offers a comprehensive range of Needle Valves. Our range includes both Integral and Screwed Bonnet designs. These Needle Valves are available in a variety of end connections covering screwed male/female pipe ends and tube ends. They are designed as per applicable standards. It is widely used in gases, liquids and vacuum operations at high pressure and temperature. FEATURES Available in a variety of end connections. A swiveling, non-rotating plug which prevents body leakage and ensures positive aligned seating for repeat operations. Hydraulic Test Pressure: (BODY) up to 630 Kg/Cm². Hydraulic Test Pressure: (SEAT) up to 420 Kg/Cm². Pneumatic Test Pressure: up to 7 Kg/Cm². PMI (Positive Material Identification) Test available on request. Standards Followed: MSS-SP-99/ASME B16.5/B1.20.1/BS 4368 Part IV/BS 3799. Marking and Identification of Valves as per MSS-SP-25. Inlet arrow marked on the valve body.

Above part nos are only for SS 316 material of construction. In case of any other material of construction kindly mention in the order details.   Features: One piece body, no weld joints. Stem tip 17-4ph for long life.   Testing : standard test: each valves is tested with nitrogen at 1,000 psi for seat & packing leakage, with  a max. Allowable leak rate of 0.1 std.cm3/min. Hydro test: performed with pure water at 1-1/2 times of the working pressure.   Lubrication : Dye molly sulphide   Notes : Optimal graphoil packing available for high temperature application panel nuts optional. End connections available in male or female bspp,bspt & npt threads Dimensions are for reference only. Dimensions are for reference only.Subject to change. Valve can be supplied to meet current revision of nace mr-01-75.(sourgas service)

Needle Valves, Ball Valves, Three Way Ball Valve, Three Piece Ball Valv

Needle Valves, Ball Valves, Camlock Coupling, Manifold Valve

Needle Valve, Tube Pipe Fittings, Manifolds, Tubings, Gate Valve

Needle Valve

Needle Valves, JIC 37 Flare Fittings, Check Valve

Needle Valves, Gas Pipe Fitting, WALL, Wall Paper, Niddle Valv

Baldota-Needle Valves, Baldota-Instrument Pipe Fitting

Needle Valves, Diaphragm Seals, Manifold Valves, Pressure Gauge
