Needle Valve Dealers in Jogeshwari, Mumbai

We are offering needle valves. All our products are compatible with iso 9001:2008, ped 9723ec and atex 949ec and our in-house testing facility assures, verify and confirm high quality of products that are available to our customers at the most competitive prices and in the timeliest manner possible. Count on us for needle valves for safe, secure and leak-free connections, even in the harshest settings. We offer a range of low-cost, high quality instrument needle valve. These are some of the best in market today and come in a wide range of sizes in needle valves from needle valve 12" and 18" to 1"odt or pipe connection. Rugged construction and compact design is further tested when the ss needle valve is tested hydrostatically 1.5 x rated x rated pressure and with nitrogen at 1000 psi to prove its mettle. Visit our site today and send us an enquiry - we promise you will not be disappointed because we believe that our customers are our true partners and their satisfaction is ultimate goal.

We manufacture and supply top quality Needle Valves as per the industry standards & specifications. Our range of Needle Valves is produced from advanced technology and goes under strict testing at various stages of production. These valves are available at reasonable prices. Features : High durabilityCorrosion resistiveHigh performanceEasy to useHigh tensile strength Applications : Hydraulics & PneumaticsOil & GasWater SystemsPharmaceuticals Technical Data : Pressure rating up to 5000 psi (340 bar) at 380C (1000F).Temperature rating from -530C (-650F) to 2320C (4500F) with standard PTFE packing, up to 3150C (6000F) with Graf oil packing.Materials : Standard 316SS and Brass.Forged body with straight and angle pattern.Panel mounting without packing disruption.Wide choice of end connection : A Saluji Engineering Works Tube Fittings, Male & Female NPT or PT (ISO 7/1) thread, Socket Weld ANSI/ASME B16.11.Standard lubrication : Nickel anti-seize lubricant (Hydrocarbon carrierStandard seat : Metal to metal/body material.Optional sea : Metal to metal/satellite, hard coating, soft seat. Testing : Standard Factory Test: Every needle valve is 100% factory tested with air and nitrogen at 1000psi (69bar) for leakage at the seat and packing. Each test is performed to maximum allowable leak rate of 0.1sec/min.Optional Hydrostatic Test: This hydrostatic shell test is performed with pure water at 1-1/2 times of the working pressure. Other optional tests are available upon request.

Needle Valves are minutely designed to ensure leak tight shut-off and efficient control of fluids in power, process and instrumentation process. Manufactured using requisite metals, these valves are able to withstand pressure and perform under corrosive environment.  Our valued clients can avail valves in different specifications, sizes and types as per their requirement. We are a Manufacturer, Supplier and Exporter of High Pressure Needle Valves.

  •  Available in SS316, all wetted parts in accordance with NACE MR01-75•  Heat Code Traceable to certified material test report•  Low operating Torques•  Forged Body, straight and Angle patterns•  Panel mountable•  Variety of stem tips•  PTFE packing standard•  Flow coefficient (Cv) from 0.09 to 1.8•  Orifice size : 0.078" (2mm), 0.172" (4.4mm), 0.250" (6.4mm)                          0.375" (9.5mm)•  Variety of end configurations includes SEALEXCEL® Well-Lok™   Tube Fittings, Male/Female NPT, BSPT and BSPP pipe connections•  Every valve is factory tested. SEALEXCEL Needle Valves are available with choice of optional stem to provide greater flexibility.NON-ROTATING (NR)         : It is Standard self centering non rotating stem tip typically used in high cycle application to extend                                                   the valve life. V-STEM (VS)                         : It is used for general purpose liquid and gases.SOFT SEAT (SS)                   : A soft seat stem requires a lower sealing torque, It is replaceable and suitable for temperature                                                   upto 120ºC REGULATING STEM (RS)   : It is used where some degree of flow control required. Pressure Rating           : upto 5000 psig (340 bar) at CWPTemperature Rating   : -54ºC to 232ºC with PTFE Packing   APPLICATIONS •  General plant service•  Instrument Isolation•  Hydraulic and pneumatic•  Pressure measurement devices •   Venting

Above part nos are only for SS 316 material of construction. In case of any other material of construction kindly mention in the order details.   Features: One piece body, no weld joints. Stem tip 17-4ph for long life.   Testing : standard test: each valves is tested with nitrogen at 1,000 psi for seat & packing leakage, with  a max. Allowable leak rate of 0.1 std.cm3/min. Hydro test: performed with pure water at 1-1/2 times of the working pressure.   Lubrication : Dye molly sulphide   Notes : Optimal graphoil packing available for high temperature application panel nuts optional. End connections available in male or female bspp,bspt & npt threads Dimensions are for reference only. Dimensions are for reference only.Subject to change. Valve can be supplied to meet current revision of nace mr-01-75.(sourgas service)

Applications   Needle Valves are used for flow control, isolation purpose, on /off applications. Suitable for pressure upto 400 kg/cm2 and higher.   Features   4 Material SS316 or SS304 4 1/4", 3/8”, ½” bsp or npt connection 4 Pressure Rated upto 400 kg/cm2 and higher

Purchasers can place wholesale or retail orders with any time of the year and expect timely arrival of deliveries. Installation of modern packaging facility assists us in meeting standard as well as tailored packaging requirements of the patrons. In addition, our professionals ensure safe packaging of the products. Features: Positive shut off Longer life Quick in action No lubrication

Body Materials: SS 316, SS 316L, SS 321, Duplex 2205, Titanium, Alloy 400, Alloy 625, Alloy C-276. Pressure Rating: 3000psig (203 bar), 6000psig (413 bar), 10000psig (690 bar) @ 38°C (100°F). Temperature Rating: -53°C (-65°F) to 232°C (450°F) with standard PTFE packing, up to 648°C (1200°F) with Grafoil packing. Size: 1/4″ to 1″, End Connection: NPTM/NPTF, Tube to Tube. Threads with smooth surface finish avoid galling and help to extend the fitting service life.

Needle Valves Needle Valves are used for flow control, isolation purpose, on off applications. Suitable for pressure upto 400 kgcm2 and higher.Pressure Rated upto 400 kgcm2 and highe.

30,000 psi needle valves: max working pressure : 30,000 psi (2069 kgcm2) @ 25ºc (77ºf) max. Temperature : 210ºc (410ºf) testing pressure : hydrostatic body - 45,000 psi (3103 kgcm2) hydrostatic seat - 30,000 psi (2069 kgcm2) pneumatic seat - 569 psi (40 kgcm2) service medium : liquid gas or vapours service types of valves : needle valve - straight type, angle type (90º) two way & three way two piece, nonrotating stem tip two piece, nonrotating stem tip connection size : 14” , 38” , 916” orifice size : 2.4 mm (0.093”) gland seal (packing) : glass filled ptfe: temperature min. -73ºc (-99.4ºf) to max. 210º (410ºf) material : ss 304, ss 316, ss 304l, ss 316 l with nace mr-01-75 & nace mr-01-03 (for sour gas service) material certificate according to en 102043.1b body - cold worked stainless steel handle - stainless steel bar stock finish : ss natural mounting arrangement : needle valves - integral through-holes for bracket mounting panel mounting option is also available. Standard followed : ansi b 16.34 gland seal : ptfe(standard) : for temperature range -73ºc (-99.4ºf) to 210ºc (410ºf) graphoil : for temperature range 180ºc (356ºf) to 540ºc (1004ºf) material : carbon steel, ss 304, ss 316, ss 316 l, monel 400 nace mr-01-75 & nace mr-01-03 (for sour gas service) can also be provide material certificate according to en 102043.1b finish : carbon steel - zinc plated & dichromated, ss natural mounting arrangement : needle valves - panel mounting design standard : ansi b 16.34

Needle Valve, Union Fittings, Elbow Fittings, Tee Fittings, Male Connecto

Needle Valve, Union Elbow Fittings, Instrumentation Valve

Needle Valve, Back Ferrule, Thermowell Thermocouple, Air Heade

Needle Valve, Elbow Fitting, Ferrule, Manifold Valve, Nut, Tee Fittin

Needle Valves, Ball Valves, Pipe Fitting, Nrv, Manifolds, Hose Fitting

Needle Valves, Ball Fittings, Vacuum Fittings, Tube Fitting

Needle Valves, Check Valves, Ball Valves, Flush Ball Valve

We are leading needle valves manufacturers providing our customers with products that are of international standard at the most cost-effective prices in the market.

Needle Valves, Ball Valves, Three Way Ball Valve, Three Piece Ball Valv

Miniature Needle Valves, Pressure Guage Snubbe

Needle Valve

Needle Valve, Tube Pipe Fittings, Manifolds, Tubings, Gate Valve

Needle Valves, Jute Bags, Hydraulic Tube, Corrugated SS Hos
