Pug Cutting Machine Dealers in Mumbai

Gas Cutting Machine helps a Fabricator in cutting production costs and increases efficiency.It works on single phase supply and is operated by H.P. single phase motor. Power is fed through a Forward-Reverse toggle Switch Gas Cutting Machine helps a Fabricator in cutting production costs and increases efficiency.It works on single phase supply and is operated by H.P. single phase motor. Power is fed through a Forward-Reverse toggle Switch Specification Drive Single phase motor Speed Control Potentiometer Input Voltage 230 V single phase 50 HZ Speed 200mmmin to 1000mmmin Cutting Range 3mm to 100mm Gas type Oxygen & Acetylene Connections ¼ or 38 :LH for fuel and ¼” or 38 To be used with Aluminum Track 1.8 meters , supplied as optional extra Circle Cutting Can be done with the use of circle cutting attachments, supplied as optional extra. This can be easily attached to the machines

AMI-P-925Profile Gas Cutting Machine helps a Fabricator in cutting production costs and increases efficiency. It is designed for heavy duty jobs and also for precision jobs. It works on single phase supply and is operated by 1/12 H.P. single phase motor. Machine is designed to operate on magnetic effect in the roller shaft of gear box. Movement of gas cutting nozzle is directly linked with magnetic roller shaft which results in fine cutting of metal.

Profile Gas Cutting Machine helps a Fabricator in cutting production costs and increases efficiency. It is designed for heavy duty jobs and also for precision jobs. It works on single phase supply and is operated by 112 H.P. single phase motor. Machine is designed to operate on magnetic effect in the roller shaft of gear box. Movement of gas cutting nozzle is directly linked with magnetic roller shaft which results in fine cutting of metal.

Features: Straight line or circular cuts upto 90mm thickness. Counter balancing enables larger torch machine distance. Heavy duty and low mainteanace Bevel Cuts up to 45. Technical Specifications: Cutting capacity:5mm to 90mm. Straight cuts:1.8meters and multiples Circle Cutting:75mm dia to 1200mm dia Cutting Speed:80mm/min to 800mm/min(variable) Max.Torch Adjustment:Vertical 70mm, Horizontal 85mm Voltage:220/250VoltsAC/DC,50Hz. Weight:9 Kgs.

PUG Cutting Machines, Insulated Power Cables, CNC Gas Cutting Machine
