Right Angle Boot Dealers in Mumbai (5 products available)

This data sheet covers the requirements for heat shrink medium voltage boots whose dimensions will shrink to predetermined size upon the application of heat above 125 deg. C. Color of the MV boots is reddish brown. The MV boots are electrically insulating, anti-tracking, UV resistant, weather proof and flame retardant. Both ends of MV boots are internally coated with red mastic and covered with release paper.     Typical Applications The MV Right Angle Boots provide insulation and sealing for bushings in cable-end boxes integral with switch-gear and transformers. The mastic sealant provides a water-tight environmental seal to the bushing. The MV boots are also supplied as a part of heat shrink cable termination up to 36 kV for operation in air-filled cable-end boxes, designed with reduced clearances for compound filling. The boots are designed to withstand surges induced during the operational life of the termination. The following application table indicates the dimensions of Right Angle Boots.

• Tensile Strength: 12 N/mm2 (MPA)(min.)

Angleboots are Heat Shrink Right Angle Straight Boots provide insulation to the bushings in the cable termination box, where the clearance between phase to phase and phase to earth is less then the normal air clearance. These boots provide protection against flashover in the event of high humidity, rodent menace and surge impulse.The boots are mode from high quality cross linked non tracking polyolefin material. They are internally coated with water resistant red mastic.

• Voltage: 24 kV

Raychem elastomeric insulating boots are moulded parts, which fit over the connection between the cable lug and the inline or right angled equipment bushing to improve phase-to-phase and phase to- ground insulation. They are used in switchgear and transformer cable boxes where the air clearances are insufficient for normal operation, or to protect against flashover due to rodents or high humidity. R-CAB, SILCAB and E-CAB are different bushing boots available for maximum system voltage levels upto 24 kV. Raychem's SILCAB-T is designed to be "re-usable terminal protector" with facilities for on line testing.

In-Line and Right Angle Boots
