Dry Type Transformers Dealers

Features   The Polycrete is Hydrophobic & thus ideal for Outdoor applications.   The construction of the product is evaluated & validated by state of art Electro Static Field Analysis Software.   Ensures distribution of electrical stresses.   Active parts are assembled inside FRP Moulds.   The CT & VT castings are finished to remove flashes & excessive material.   The castings are painted with PU Based Paint.   The Electrical Routine Tests are carried out in our High Voltage & High Current Laboratories.   The tests are carried out in accordance with the relevant IS / IEC standards specified by the contract.Advantages Of Polycrete Outdoor CtInsulation SystemPOLYCRETE is dry, non-hygroscopic No gas generation or absorption. Ages slowly with time Insulation Processing Since no hygroscopic material is used, moisture removal is quick and accurate.Components are firmly encapsulated. Cannot move Performance predictable over service life.Sealing SystemsNo seal necessary in the area of active component as POLYCRETE provides weather proof protection Improved reliability.Porcelain crackSince POLYCRETE is not brittle, it cannot crack a porcelain.Oil Quality & QuantitySince CTPTs are dry, no maintenance.Explosion & FireCTPTs does not contain inflammable material and hence cannot cause fire / explosion. POLYCRETE is a self extinguishable materialNoise during operationAs components are embedded no audible noise in operation.CompactnessCompact as the components are embedded & no requirement for a separate ground insulation.TransportationMechanically robust & can with stand shock & vibration while transportation.

Leveraging upon our experienced team of professionals, we are able to offer a gamut of Dry Type Transformer. The offered range of transformers offers high efficiency up to 200 KVA and is manufactured using premium quality lamination and electrolytic grade super enameled/DFGC copper wire. Additionally, we provide the entire range of products in various technical specifications, as per the ever-evolving requirement of our clients. Features: Excellent voltage regulation High performance Durable frequency

TECHNICAL SPECIFICATIONS Type Cast Resin Transformer Capacities: From 5 KVA to 1000 KVA Voltage Class: Up to 6.6 KV Phases: Three Phase & Single Phase Frequency: 50 Hz / 60 Hz. Typical Voltage Configurations in Three Phase: (Other Voltage configurations available as per customer requirements) 6.6 V / 433 V; 6.6 V / 415 V; 6.6 V / 230 V; 433 V / 6.6 V; 433 V / 433 V; 433 V / 415 V; 433 / 230 V; 415 V / 6.6 V ; 415 V / 415 V; 415 V / 230 V. Insulation: Class F / Class H Winding Material: Copper Magnetic Core: Prime Grade Virgin C.R.G.O FEATURES Service Designed for long life and trouble free performance Losses Designed for lower losses and greater efficiencies Test Standards Designed for IS 2026 / 11171 & I.E.C 60076. Value Designed for cost effectiveness and high reliability Installation Designed for installation closer to load Safety Designed for averting fire and protected against chemical spills and harsh environmental conditions.

Lamco Transformers Pvt. Ltd. is leading manufacturer and supplier of dry type transformers. The offered range of dry type transformers offers high efficiency up to 200 KVA and is manufactured using premium quality lamination and electrolytic grade super enameled/DFGC copper wire. Our range of dry type transformers are built in accordance with the international standards. These dry type transformers are strictly inspected on certain parameters of quality in order to rule out every possibility of defect. Clients can avail these dry type transformers at very reasonable rates.

With increasing importance of safety and environmental aspect in modernized and compact commercial applications, Dry type transformer demand is increasing. There is no oil used in the Dry type transformers. A special type of fire resistant insulation is used to reduce the fire risk considerably. Major application areas -- Mining, hotels, high rise buildings, hospitals, malls, shipping.     Mahati has following two types of dry type transformers to offer : cast resin vacuum impregnated Mahati make dry type transformers are now in use for over five years. Range:- KVA rating : 100KVA to 5000KVA (36KV class).

Distribution Transformer

Dry Type Transformers, Transformer Repair Services, Flameproof Lightin

Dry Type Transformers, Engineering Products, Energy Mete

Dry Type And Cast Resin Transformer

Dry Type 3ph Isolation Transformer, 3 PH Control Transforme

Dry Type Transformers, GI Octagonal Poles, GI Poles, HT Isolato

Cast Resin Dry Type Transformers, Ultra Isolation Transformer

Cast Resin Dry Type Transformers, Furnace Transformer

Vpi Dry Type Transformer, Cast Resin Dry Type Transforme
