Servo Voltage Stabilizer Dealers in Hyderabad (31 products available)

• Type: Single Phase Voltage Stabilizer
• Certification: ISO 9001:2008
• Color: Grey
• Voltage: I/P 170-270V O/P 230V
• Condition: New
• Output Type: AC Single Phase
• Automatic Grade: Automatic
• Cooling System: Air Cooling, Oil Cooling
• Brand Name: SERVOMAX INDIA

front panel controls (ps-model): 0-300 v voltmeter auto / manual select switch potentiometer for voltage adjustment in auto mode 72 sq. Mm analog meter to read input/ output volts increase / decrease switch to adjust the output voltage in manual mode selector switch to read input / output voltages

• Indications: Mains Input on 3 LED Indications, , 3ph output on indication,Phase Reversal indication, over Load indication
• Indications in LCD Display: Input High and Input low,Output on indication,Output high Cutoff and Output Low Cutoff
• Programmable Control Timings: Over load Cutoff Time,Auto Restart Time,On & Off Delay Time
• Input voltage range: 300 – 460v 340 – 480v 360 – 460v ac 3 ph
• Output voltage(3 ph): 415v
• Ac System: Unbalanced
• wire: r y b n
• Connections: Star
• Operating Frequency: 47 to 53 Hz
• Output Voltage Adjustable: 380 to 415v Ac in 3 Ph
• Output Voltage Regulation: + 1% (no Load)
• Output voltage regulation: + 1% (full load)
• Overload Capacity: 120%
• Correction Rate: 60 30 25v per Sec-3 Phase
• Waveform Distortion: Nil
• Output Waveform: True
• Reproduction of Input Insulation: Class F Short Circuit
• Period & Percentage: 300% for 250 Milli Sec. 0 0 Normal
• Operation Temperature: 0 C to 45 C 0
• Climate Conditions: 90% Rh Max.
• Non Condensing: 35 C
• Type of Cooling: Natural Air Cooled Up to 600 Kva
• Mode of System: Fully Automatic System
• Construction: As per is – 9815 1994

Servo Voltage Stabilizer that we offer is gaining high popularity due to its longer service life and durability. We are named among the renowned Manufacturers and Suppliers of Servo Voltage Stabilizer. It is manufactured under the strict vigilance of experts. Thus, buying it from us will be the safest option for the buyers. One can place retail as well as bulk orders for Servo Voltage Stabilizer with us.

• Automatic Grade: Automatic

Technical Specifications Fully Solid State Control Circuit ± 1.0% Regulation No Wave-form Distortion High Efficiency Auto Manual Operation Facility

• Operating Frequency: 47 to 53 Hz
• Correction Rate: 60 / 30 / 25V per Sec-3 Phase
• Input Voltage Range: 300 - 460V / 340 - 480V / 360 - 460V AC 3 Ph
• Output Voltage (3 Ph): 415V AC
• System: Unbalanced 4 wire: R Y B N
• Connections: Star
• Output Voltage Adjustable: 380 to 415V AC in 3 Ph
• Output Voltage Regulation: + 1% (No Load)
• Output Voltage Regulation: + 1% (Full Load)
• Overload Capacity: 120.00%
• Waveform Distortion: Nil
• Output Waveform: True Reproduction of Input
• Insulation: Class F
• Short Circuit period & Percentage: 300% for 250 Milli Sec.
• Normal Operation Temperature: 0° C to 45° C
• Climate Conditions: 90% Rh Max. Non Condensing at 350C
• Type of Cooling: Natural air cooled up to 600 KVA
• Mode of system: Fully Automatic
• System Construction: As per IS : 9815 – 1994

Servo Voltage Stabilizer uses an advance electronic controlled servo motor concept to govern a motorized variable transformer. Because of the motors involved, there is a small delay in voltage correction. However, output voltage accuracy is usually ±1% with input voltage changes of up to ±50%.

• Input voltage range: 300 – 460v 340 – 480v 360 – 460v ac 3 ph
• Output voltage(3 ph): 415v
• Ac system: unbalanced
• wire: r y b n
• Connections: star
• Operating frequency: 47 to 53 hz
• Output voltage adjustable: 380 to 415v ac in 3 ph
• Output voltage regulation: + 1% (no load)
• Output voltage regulation: + 1% (full load)
• Overload capacity: 120.00%
• Correction rate: 60 30 25v per sec-3 phase
• Waveform distortion: nil
• Output waveform: TRUE
• Reproduction of input insulation: class f short circuit
• Period & percentage: 300% for 250 milli sec. 0 0 normal
• Operation temperature: 0 c to 45 c 0
• Climate conditions: 90% rh max.
• Non condensing: 35 c
• Type of cooling: natural air cooled up to 600 kva
• Mode of system: fully automatic system
• Construction: as per is – 9815 1994

• Input Voltage: 220 to 240 V,380 V to 415 V
• Phase: Single Phase & Three Phase
• Frequency: 47 to 53 Hz
• Voltage: 1 kVA -1500 kVA
• Brand Name: Absolute Electric & Energies
• Operating Temperature: 0 to 55 Deg C
• Features: No Wave-form Distortion, High Efficiency, Auto Manual Operation Facility .
• Surge Protection: With Surge Protection
• Usage/Application: Industrial
• Control Type: Digital controller
• Mounting Type: Floor
• Response Time: Less Than 2 sec
• Body Material: Steel

A.C. Servo controlled voltage stabilizer to suit your need and budget -yet no compromise in performance and quality. Some models have the unique feature of measuring digitally both voltage and current on a single meter. Trouble free service and reliability makes our servo stabilizer most competitive and prominent in the indian market. Quality assurance by experienced engineers and dependable customer support service of our effective field staff are our plus points. FEATURES: Reliable READOUT, to read both voltage and current on the output side Complete IC version and electronic sensing Protective over voltage / under voltage trip facility and spike suppressor Precise electronic over load/ short circuit trip facility Suitably integrated to work even on non-sinusoidal waveform of generator etc. Audio annunciation on restoration of power to normality Multi socket output Very High Efficiency Distort free output wave form

• Phase: Three Phase
• Type: Automatic
• Application: Residential, Commercial
• Body Material: Steel
• Power: 5 KVA
• Cooling Type: Oil cooled
• Frequency (Hz): 50 Hz
• Portable: Yes
• Display Type: Analog
• Voltage (V): 110 to 220 V
• Over Volt Protection: Yes

• Phase: Three Phase
• Input Voltage: 360 - 460 / 320-480l / 250-520 VAC
• Efficiency: 98%
• Brand Name: Numax
• Output Voltage: 400/415/420 V,Settable
• Terminations: Bolted Terminals up to 100KVA,Bus Bar 125KVA and Above
• Stabilizer Bypass: Provided upto 50KVA 3 Phase
• Usage/Application: Industrial, Commercial
• Control Type: DSP based IGBT Technology
• Automation Grade: Semi Automatic
• Cooling Type: Air Cooled
• Display Type: 4 Line LCD panel,Programmable
• Body Material: Mild Steel
• Correction Speed: 60VAC/Sec
• Winding: Copper
• Surge Protection: With Surge Protection
• Correction Time: 50ms-5sec
• Stability: 5%
• Output Voltage Regulation: 1% nominal output voltage
• lnput Frequency Range: 47-53 Hz
• Short Circuit Protection: Electronic cut off/ MCCB

Servo Voltage Stabilizer uses an advance electronic controlled servo motor concept to govern a motorized variable transformer. Because of the motors involved, there is a small delay in voltage correction.

• Brand Name: POWERTEX
• Input Voltage: 295 - 480V AC
• Frequency: 50Hz +/- 3%
• Phase: 3
• Place of Origin: INDIA

We are offering We manufacture from 1KVA to 20KVA Single Phase and 3KVA to 1500KVA 3 Phase Servo Stabilizers with wide range of Input Voltages - both Oil Cooled and Air Cooled Variants.
