Advanced Microwave Integrated Circuit Lab includes instruments and accessories for studying the characteristics of any MIC ( Integrated Circuits) component over the Frequency Range 2.2 to 3GHz. Characteristics and measurements like Transmission Loss and Reflection Loss of different MIC components can be studied with the help of instruments provided with Nvis 9008/Nvis 9008A. Directivity and Gain of Antennas can also be measured with the setup provided. The theoretical background on these components and experimental details are provided in the learning material CD. Nvis 9008/ Nvis 9008A, Advanced Microwave Integrated Circuit Lab is an ideal platform to enhance education, training, skills & development amongs our young minds. Product Features  Complete setup with Generator, MIC Components and Meter  Gold Plated Components and Connectors  Microwave Generator with internal AM and FM  PC to PC Data Communication  Antenna Radiation Pattern measurement  Directivity and Gain measurement  Learning material CD Scope of Learning PC to PC Data Communication using MIC components Measurement of Transmission Loss and Reflection Loss Measurement of substrate dielectric constant using Ring Resonator Measurement of power division, isolation and return loss characteristics Measurement of coupling, isolation and return loss characteristics Measurement of coupling and directivity Measurement of Low Pass Filter characteristics Measurement of Band Pass Filter characteristics Measurement of Band Stop Filter characteristics Measurement of characteristics of Patch Antennas Measurement of characteristics of an MIC Amplifier To study RF switch To study RF Mixer Measurement of Guide wavelength, Free Space Wavelength and SWR using Measuring Line Measurement of Directivity and Gain of Antennas : Yagi Antenna, Patch Antenna, Dipole Antenna To study the characteristics of Isolator To study the characteristics of Circulator

Advanced Microwave Integrated Circuit Lab includes instruments and accessories for studying the characteristics of any MIC ( MicrowaveIntegrated Circuits) component over the Frequency Range 2.2 to 3GHz. Characteristics and measurements like Transmission Loss and Reflection Loss of different MIC components can be studied with the help of instruments provided with Nvis 9008/Nvis 9008A. Directivity and Gain of Antennas can also be measured with the setup provided. The theoretical background on these components and experimental details are provided in the learning material CD.   Features:    Complete setup with Generator, MIC Components and Meter  Gold Plated Components and Connectors  Microwave Generator with internal AM and FM  PC to PC Data Communication  Antenna Radiation Pattern measurement  Directivity and Gain measurement  Learning material CD  2 Year Warranty This Training System Includes: Nvis 104 Microwave Generator (2.2 - 3GHz)2. Nvis 1103 VSWR Meter3. MIC Components4. Learning Material CD5. Transmitting and Receiving mast
