Dynamometer Dealers

Ron Crane Scales & Dynamometers are one of the leading brands in the global market for more than 30 years with repeat customers like NASA, Boeing, GE, Siemens and many others.

This is simple and easy to understand set up designed to study behavior of cutting forces during Milling Operation. This is based on octagonal ring method, which consist two pairs of octagonal rings with strain gauges mounted on it. These rings are sandwiched between two plates. A machine vice is mounted on top plate to hold job to be machined. A three channel digital force indicator is provided to measure three forces simultaneously. Specifications - Mechanical sensing unit with octagonal ring set and strain gauges. Digital force indicator - 3 channel to measure three forces simultaneously. Range - 0 to 500 Kg Resolution - 1 Kg Balancing pots for initial zero setting. Machine vice to hold job. The set up is calibrated at our works with the help of standard Proving Ring.

Schenck engine test systems are used whenever prime movers and special components are developed, tested and repaired. For example for running-in and endurance tests for engines, tests on carburettors, injection pumps, ignition equipment and governors, and also for testing fuels and lubricating oils. Schenck engine test systems form a closed unit, developed from the requirements of practical testing, tailormade for the power ranges of current engine sizes. The test systems consist of the absorption dynamometers manufactured with great Mechanical precision, and the modular electronic components for control, regulation and automation.

Ron 2000 Shackle Type is a small, lightweight and portable Dynamometer. It is therefore especially suitable for applications that require portability and minimum headroom loss (for example indoors applications). Ron 2000's long battery life (up to 2000 hours) is also an important feature for working long periods on site. Ron 2000 is a basic, easy-to-operate and very reliable dynamometer. It was first launched in 1988 and since then many thousands of Ron 2000 dynamometers have been sold worldwide. The load cell's unique perpendicular hole structure neutralizes external moments and thus improves safety and accuracy. The optional additional wireless display enables transmission of the measured values to a remote location.

Dynafor is highly accurate instrument for measuring tensile forces and suitable for wide variety of applications where an instant indication of the load applied is required.   Features Industrial dynamometry providing the highest degree of ergonomics, precision, flexibility It can be operated through cable and remote control Wide range of load measuring capacity, WLL-250 Kg to 250 tons   Approvals EMC and EEC, Confirms to EN: 12100-1 and EN 12100-2

The DYNA-4000 is an instrument for testing the resistance ability on PET bottle or cans.Designed for easy operation and maintenance, and fully conforms to tests requirements according to international standard. The pressure test of containers is made up to a predefined pressure point (trial test) or until destruction. CHARACTERISTIC PLC integrated User-defined test cycle (up to 4 step of force and holding time) satisfies test request Full stainless steel and aluminium machine Various safety design RS232C output Touch screen LCD Dynamic Display: satisfies/ hour/ date Display: product name/ operator/ batch N0/ sample N0 Can store 10 operators and 30 products User defines the batch number and sample number Reviews the real time testing graph

Versatile design• Line rider dynamometer is an assembly of 3 sheaves with bearings, load pin is located in the middle sheave.• All the 3 sheaves are manufactured in self lubricated material.• Load pin is IP – 65 graded.• Customize sheaves sizes on request. • Load pin is temperature compensated for increased accuracy• Can be installed easily • Load Pin is strain gage based sensor with full temperature compensation over 0º - 60º C.• Load Pin is constructed from SS 17-4 ph grade for corrosion and shock load resistance.• Analog signal converter - 0 - 10 VDC or 4 - 20 mA for PLC interface.• Used for both lattice boom crawler cranes and telescopic boom cranes

Dynamometers are used to measure HP and Torque of rotating Machines such as : electric-motors, engines, different types of pumps rotators etc. TECHNICAL ASPECTS of "MOTCO" make DYNAMOMETERS : DESIGN : Our Designs, parts & Dimensions are as per I.S.I Standards. Latest Innovations are  incorporated. Changes are made with times and also as per Customer demands. FRAME & ENCLOSURE : Our Steel made Frames ensure greater strength & standard type production. Ventilation is provided by strong fan. In case of excess heat due to low speeds, Blower Mounting arrangement are provided for necessary Cooling. WINDINGS : The Shunt Coils are wound in such a way with  Main Pole that, solid inter-pole & main-pole base would withstand any type of vibration. Coils made of copper conductors are insulated & then vaccum impregnated with high grade varnish ensuring resistance against acids, oil & moisture. COMMUTATORS : Manufactured Cylindrically, with hard-drawn copper and V-Groove segments of high conductivity, insulated by a mica sheet in between. Complete commutator is baked for high temperature testing. BRUSH BOX & BRUSHES : Brush Gear is made of strong, special design- but with simple construction- making it possible for shafts to rotate easily at low speeds with noise-free service. Provision for easy access to replace and adjust the brushes is provided. Brushes are of standard grades, ensuring sparkless commutation. ARMATURE : Armatures are built of high quality Standard Steel Laminations, Securely insulated from each other and clamped together under high pressure ensuring low heating losses. Coils and wire-winding is strictly as per insulation class 'B'. Armature is tested for Dynamic Balancing. Resin Binding means full protection of Armature in all respects. TESTING : Our all products are thoroughly  & vigorously tested on special Heavy Duty Test Bench and Dynamometer. All continuously rated Motors & Generators are tested on Full Load for more than Five Hours (HEAT RUN TEST) for temperature rises and the same are not permitted  to exceed values prescribed as per I.S. 4722. All windings are put to insulation test with lowest rate of 1.5 to 2 KV.

Dynamomete

Chassis Dynamometers, Shape Inspection Equipment, Transmission Tester

Dynamometer, Electronic Weigh Scale, Density Measurement Scale

Digital Hand Dynamometer, Shoulder and Elbow Joint CP

Hand Dynamometer, EMG Biofeedback, Intelect Mobile Laser, Paraffin Wax Bat
