Liquid Level Indicator Dealers

SIGMA's Tank Level Indicators are float operated target type suitable for liquid level gauging of fixed roof, floating roof, open type vertical storage tanks and underground sumps for water, oil, solvents etc. The tank level indicators are of simple construction and are easy to install. They are very sturdy and require no maintenance. A float operated tank indicator comprises of a float that is located within guide cables. The guide cables whose ends are fastened on to an anchor bar are kept straight and wrinkle free by tension devices. The anchor bar is either grouted or welded to the tank bases. The float cable is wound over a set of pulleys, which are secured in the pulley housing. One end of the float cable bears the float and the other end carries a pointer assembly with a counter weight for balance. Tank level indicator float operated type is for fixed roof, floating roof, open top and under ground storage tanks.

The Tubular Glass Level Indicator is commonly used for visual liquid level observation. The Tubular Glass Level Indicator is a simple and reliable device used for direct reading in atmospheric or pressurized tank applications. The Tubular Glass Level Indicator is mounted parallel, at the side of the tank. As the process level fluctuates, the level in the transparent glass tube changes accordingly and gives local liquid indication. Technical Specification :  New Bolted Gland with teflon packing ensures positive leak tightness for full vacuum as well as 10kg/cm2 pressure service. Sturdy Protection : Glass tube is protected by box section made out of two M.S. channels Beam strength of the guard is so good that even if man stands on the indicator supported at two ends, the tube remains intact. Light Weight : 75% less in weight compared to Reflex and Transparent liquid level indicators Extraordinary strength but less bulky   Excellent Visibility : 16/19/25mm O.D Borosilicate glass gives excellent visibility Surface tension effects are eliminated   Test Pressure : Full vacuum and/or 10 kg/cm² compressed Air   Attributes : Liquid indicator Durable Excellent quality Reliable

* 3½ digits Display. * Resolution 0.1 dB. * MAXMIN Hold Function. * ACDC Signal output. * Time Weighting : Fast, Slow * RS-232 interface, 14000 Records Data logger (KM-929) * Low battery indication. * Applicable standards : IEC 651 Type II.

Model No.: JB/FBVSTLI/404 Suitable for measurement of liquid level in over ground/over head storage tanks.Utilise: Suitable for reacting liquids like HCL, HNO3, NH4OH and other liquid were absolute vapour tightness is required. Float C.S./S.S..304/S.S.316/PP/PVC/Teflon lined Housing Alluminium / PP etc.. Wire housing C.S./S.S..304/S.S.316/PP/PVC/Teflon Nylon Pulley Alluminium / PP/ Nylon/ S.S. 316

A full range of sound level meters and analyzers covering applications from point-and-shoot level checks to in-depth analyses of environmental noise, from broadband measurements to real-time analyses in 11- and 13-octave bands, Environmental Noise, Product Noise in production line or in-situ, Façade Insulation, Construction noise, Mines Blasts, Fire-cracker Noise, Occupational Noise, Neighbourhood Noise, Noise Dose Meter

  Tubular Liquid Level Indicator   It is a simple, low cost and reliable device for direct reading of liquid level MODEL NO. : FITZER / TLG / 130 Mounting : Side mounted C.C. Distance: upto 3500 mm Features : Adjustable Alarm switches, Isolating Auto Shut-off Valve, Steam Jacketing Arrangement.

The "Mayur Instruments" make Tubular Level Indicator (Side Mounted). It is a reliable device for direct reading the level of liquid. It is a simplest form of level indicator. These level indicators find wide application for level measurement in process tanks, batching tanks / storage / overhead etc.

Ambuja specialises in manufacturing floats for float and board type level indicator which are widely used for Oil tanks, fuel tanks, large water tanks. Due to the use of level measurement required in various levels in a factory most of the instrument manufacturer in india are purchasing float from us to manufacture float and board level indicators. This thali float has hinges welded on three sides the top hinge for main wire and side hinges for guide wire, tide wire assembly for guiding the float smoothly in tanks so that it does not hit the tank on constant filling and draining of tanks. This Thali Floats are made available to our clients in various MOC like 304 S.S / 316 S.S / PP & even PTFE.

Float & Board Type Tank Level gauge (indicator) suitable for large non – pressurized liquid storage tanks vessels. The Specific Gravity of the fluid should be more than 0.6. Float is available in different material S.S.304S.S.316P.P.Teflon etc. In this level gauge, the float is design as per the specific gravity of the liquid, floating on the liquid levels. This float connected to a pointer through Rope via a Sets of Pulleys, The pointer slides over a CM marked Board, Installed Parallel to the tank. For more than 3 metre height of the tank we provide two guide wires firmly anchored to the tank bottom. So that horizontal movement of the float is restricted.

Aircraft warning lights are high-intensity lighting devices that are attached to tall structures and are used as collision avoidance measures. Such devices make structures more visible to passing aircraft and are usually used at night, although they may be used during the day as well. These lights need to be of sufficient brightness in order to be visible for miles around the structure.Aircraft Lights comes as a stand-alone fixtures or as part of an integrated system. We can provide Low Intensity, Medium Intensity, and High Intensity lights and lighting solutions, which provides illumination for obstructions to aerial navigation as specified and in compliance to the authorities like FAA, FCC, ICAO, DGAC of Mexico and Transport Canada.Our solutions are highly reliable and efficient. Come with improved maintainability and a longer operational life.   Type of Lights   Aircraft Warning Lights Available with us is either stand-alone fixtures or as part of an integrated system. With support from our principal partners, we can provide low, medium, and high intensity lighting solutions. We can provide illumination for obstructions to aerial navigation as specified by the FAA, FCC, ICAO, DGAC of Mexico and Transport Canada, DGCA of India, and for Aircraft vehicles like Planes and Helicopters.
