Neutral Grounding Resistors
25,000 - 500,000 / Piece
1 Piece (MOQ)
The Neutral Grounding Resistors are generally employed in the LV and MV distribution networks to protect power transformers and generators from damaging currents in the event of earth fault. This protection system represents the best choice in terms of fast response to localize the fault and consequently to reduce and prevent the overheating and mechanical stress on the conductors.
Alternative protection systems like insulated neutral or direct earthing neutral have several and significant disadvantages such as dangerous transient over-voltages and high difficulties to localize the ground fault in the insulated systems or damaging fault currents with possible arc blast in the earthing neutral systems.
By inserting the Neutral Grounding Resistors with appropriate characteristics between the neutral point of the transformer and the ground it is possible to limit the ground fault current for a short time to allow a quick localization of the fault but, at the same time, it does not damage the equipment.
Brand Name : PIONEER ELECTRICAL WORKS,PIONEER ELECTRICAL WORKS
Material : Stainless Steel
Finishing : Polished
Shape : Ractangle
Termination Style : Copper Flat
Max. Power Dissipation : Depends on rating/requirement
Usage : Transformer/DG
Certification : IEEE32
Country of Origin : up to 33kV
Operating Temperature : 250-750
Packaging Type : Wooden Box
Specialities : Simple To Use, Good Quality, Fine Finishing
IP Grade : IP 40
Number Of Flower : Variable Resistors
Frequency : 50/60hZ
Phase : Single Phase
Total Carbohydrate : 1 Year
Country of Origin : India
Degree of Protection : IP42
Max. Current Rating : 3000A
