Transducers Dealers in Mumbai

We Offer Voltage Transducer. This transducer converts a sinusoidal AC Voltage signal into an output signal for Single Phase Single Output (STE-A-2T), Single Phase Dual Output (STE-A-2TD), Single Phase Triple Output (STE-A-2TT) & 3-Phase 4-Wire (STE-C-2TT), that can serves several receiving instruments such as indicators, recorders, alarm units etc. The input Voltage is scaled down using a Voltage transformer T. The output of the transformer is rectified and filtered in a precision absolute amplifier A, incorporating integrated circuits. The amplified filtered output is proportional to R.M.S value of the sine wave input. The output is fed to a current converter 'C' to provide a load independent D.C. Current. Feature � Available in accuracy class index -0.2, 0.3, 0.5 & 1.0 � Withstands wide temperature variations. � VA burden on PT very low. - < 0.5 VA � Wide range of Input / Output to meet National / International requirements. � Comply to revised IEC 60688 (1997-10) standards. � Flexibility in auxiliary power supply requirements - A.C. / D.C. � Rugged and vibration resistant. � Withstands seismic test as per IEC 344-1974 for Nuclear Power applications. � Available in dust proof sheet plastic enclosures suitable for Back panel / Din rail mounting. � Multiple outputs also available - up to 4. � High input / Output isolation - 4.0 KV.

Broad family of products Direct drop-in replacements for older models Field proven reliable design Models for any circuit type, input, output and power

Life-Care "Fast - Clean" Immersible Ultrasonic Transducers can be placed wherever you need them in your existing cleaning tanks. These units give you complete freedom to design specialized cleaning setups or to upgrade pre-soak tanks with ultrasonic.

We are offering frequency transducer ste-a_5t converts a frequency into an output signal that can serve several receiving instruments such as indicators recorders, alarm units etc. The input voltage signal is stepped down and galvanically isolated by a transformer t. The zero crossing of the signal is detected to triger a precision quartz controlled monostable circuit q. For each cycle of the input signal, the monostable switches a highly stabilized d.c.voltage to an amplifier a. The output of the amplifier, a constant voltage with fixed pulse width is filtered and averaged. The average signal is proportional to the frequency of the input signal. To suppress the initial range, for instance up to 45hz a fixed voltage is subtracted. The difference is fed to a current converter c to provide a load independent d.c. Current output, which can be either bipolar or unipolar

Terminal Protection Cover Reliable & Rugged Static Circuits Low Ripple in outputs Signal Flame Retardant Polycarbonate case Choice of Multiple Asymmetrical Outputs Wide Choice of Suppressed Ranges Open and Short Circuit Protection for Outputs Dual Outputs (Non Isolated Isolated) Self – Powered, AC, DC Auxiliary Supply Bi-directional Output Fast Response Time Din-Rail Mounting Bi-Directional Inputs for Import Export input

The Series 672 Low Pressure Transducer is a perfect solution to any application where a very accurate low pressure transducer is necessary. Using variable capacitance technology, the Series 672 is designed to measure pressures as low as 10" w.c. up to 400" w.c., very low ranges for a single connection pressure transducer. The 672 also features a 0.25% F.S. accuracy. Use the Series 672 in liquid level, flood warning, waste water, clean room, and open channel flow applications.

Available versions: Standard; ATEX; CSA; Schiff & Offshore; with front-flush diaphragm The The pressure transducer series HDA 4300 is equipped with a ceramic pressure measurement cell with thick-layer DMS, which was specially developed for relative pressure measurement in the low-pressure range. The 4 ... 20 mA or 0 ... 10V enable the connection to all measurement and control devices of HYDAC ELECTRONIC GmbH and the linkage to commercially available control and regulation units. The variant with the front-flush diaphragm was specially developed for applications in which the media used could lead to a blockage, gumming-up or freezing of a standard pressure connection. The main areas of application lie in the low-pressure ranges of hydraulics and pneumatics, particularly in refrigeration and air-conditioning, food and pharmaceutical industry applications. Further applications include processes where the medium changes frequently and any residues could cause mixing or contamination of the media.

Meets to DN-IEC 688. • Easy Installation & Space saving. • Simultaneous detect & display : - Individual Phase to neutral Voltage - Individual Phase Current - Individual Phase watt. - Frequency - Phase to Phase Voltages. - - Power Factor - - Total Watt - - Total Var - - Watt Hour (10 digit)

Nippen power line transducers give load independent and isolated dc outputs proportional to input parameters like current, voltage, frequency, power factor, active power, reactive power and dc isolation. a c voltage frequency pf active power reactive power d c isolation

We are known as the chief Ultrasonic Transducer Manufacturer and Supplier in India. Our Ultrasonic Transducer is available in different series that varies from 25 KHz to 50 MHZ. Moreover, the Ultrasonic Transducer can be acquired at affordable prices from us. Features Optimum acoustic Electrical parameterA novel dual damping concept Series Available W -Series : W Series represents white frequency: The transducer of this series generate a white frequency signal, and represents high signal to noise ratio, high resolution and narrow initialpulse. W-Series transducers are recommended for thickness gauging and close surface material inspection.K -Series : K Series stands for characteristic transducers. Transducers of this series have high sensitivity, moderate signal to noise ratio and high penetration. They are tuned to a particular frequency and are suggested for deep material penetration, bulk body defects resolution, shear waveapplication and investigation of attenuative media.P -Series : P Series represents Panacea Transducers. P series transducers have response falling between W and K series. They have sensitivity closer to K series and Resolution closer to W Series making them ideal for all general purpose NDT application.N-Series : This new series has features like low initialringing offering better near surface resolution, sharp echoesfor higher overall resolution, high signal to noise ratio incoarse material and high reserve gain.

Salient Features INTRODUCTION The concentration of Ions and gases in solution may be determined using ion selective electrodes. When a suitable sensing electrode is immersed in a solution containing ions or gases, an electrical potential may develop at the electrode surface due to a selective spontaneous reaction. The magnitude of this potential varies with the concentration of the selected ion or gas ISEs are responsive to concentration of particular ions in the test liquid and are variable-potential electrodes. When measurements are made using an ion meter, by calibrating with various standard solutions, direct readings of the concentration of the ion can be taken. Slope of the electrode depends on the temperature therfore measurements must be taken at a fixed temperature. SOLID STATE ELECTRODES are as combination electrodes complete with reference electrode. These electrodes incorporate a solid sensing surface made of compressed silver halides, or solid crystalline material. A solid state electrode develops a voltage due to ion-exchange occurring between the sample and the inorganic membrane. An equilibrium mechanism occurs due to the very limited solubility of the membrane material in the sample. GAS SENSORS are combination electrodes that detect dissolved gases in a solution. No external reference is required for these electrodes. The sensing element is separated from the sample solution by a gas permeable membrane A gas sensor works due to the partial pressure of the measured gas in solution. The dissolved gas in the sample diffuses into the membrane and changes the pH in a thin film of unbuffered electrolyte on the surface of the internal pH sensor. Diffusion continues until the partial pressure of the sample and the thin film is the same. The pH change is proportional to the dissolved gas in the sample STORAGE AND CLEANING It is sufficient to store the electrode in a standard solution during short measuring intervals. In order not to strain the membrane unnecessary, the electrode should be stored dry if it is not used for several days. After the dry storage put into standard solution for 3 - 4 hours for new measurements. Contaminations should be removed with a wet paper towel, don’t use organic solvents like acetone.   No Reference electrode needed Solid state sensors Refillable Type Our ISEs are compatible with other make Ion / pH meter Direct measurement of Ionic concentration Standard supply with ISAB & Calibration Solutions Refillable Type Virtually unbreakable Fast response no maintenance No membranes or replacement module

The PT460E Series transducer is a ±0.5% sensor ideal for melt pressure applications requiring simple installation, repeatability and reliability. The PT460E transducers provide the industry standard 3.33 mVV signal designed to work with most pressure indicators. The PT460E comes equipped with a six pin bendix connector. Optional thermocouple or RTD configurations are available to provide melt temperature. The PT460E features a 12-20 UNF thread for installation in standard transducer mounting holes and can be supplied with a variety of other electrical connections if desired.

NIPPEN Power line Transducers give load independent and isolated DC outputs proportional to input parameters like current, voltage, frequency, power factor, active power, reactive power and dc isolation. Features A C VOLTAGE. FREQUENCY PF ACTIVE POWER REACTIVE POWER D C ISOLATION Features Linear aux. power supply of 230V AC. Conforms to IEC 60688 and IS 12784. Short circuit protected and open circuit proof. High input/output isolation 3kV/ 4kV. DIN RAIL/ Back panel mounting arrangement. Wide choice of outputs and suppressed ranges. Current or voltage output. Single or dual ISOLATION.

RAYS AC Isolation transducers accepts various AC Inputs depends on the model selected. We offer Different AC Input models ranging from 0-1 A AC, 0-2 A AC, and 0-5A AC models with different auxiliary supply. For any higher range use external CT to convert and use it for higher current applications.Models available on request with different Aux and Input range. Features: Output is ripple free , and user adjustable zero and span access control. Transducers are normally factory set for Zero and Span for the Input range ordered.   Other Details Isolated output (3.0 KV) Excellent linearity Enclosures suitable for DIN RAIL mounting /Flush mounting Ex-Stock delivery or within 2 weeks Models available on request with different Aux and Input range User adjustable Zero and Span control Enclosure size : 42 x 75 x 125mm Power ON LED Indication for all models 12 months warranty Operating temp : 0-60 deg C Accuracy +/- 0.25 % Output with 0-5/10 Volts options available ( optional) DUAL output (Optional)

The success of any Ultrasonic technique depends heavily upon the capability of a transducer to function in accordance with a particular application. RTUL is the leading manufacturer of reliable high performance transducers for all ultrasonic applications. RTUL offers one of the most comprehensive selections of ultrasonic transducers that encompass all non-destructive testing and process applications. Highlights of RTUL transducers: Design To cover all applications four distinct series are offered. Each series is characterized by its own unique set of optimum acoustic and electrical parameter. A novel dual damping concept is feature in each transducer type. Materials The selection and formulation of each transducer undergo strict laboratory criteria of testing and assembly. This has eliminated problems such as weak housing, weak bonding etc. RTUL transducers surpass all other commercially available units in wear and impact resistance and are not only long lasting but also are highly suitable inrugged applications. Fabrication For precise location of discontinuities special techniques have been developed that assure perfect alignment of geometric and acoustic centers. ULTRASONIC TRANSDUCER SERIES : Since a single transducer is not capable of performing a large number of applications, it is imperative that a number of ultrasonic transducers be designed in order to accomplish comprehensive material inspection. RTUL offers three distinct transducers series from 25 KHz to 50 MHZ. Each series is characteristically different from the other, thus suitable for a particular application. Some of the features of these series are given below. W -Series Probes W Series represents white frequency: The transducer of this series generate a white frequency signal, and represents high signal to noise ratio, high resolution and narrow initial pulse. W-Series transducers are recommended for thickness gauging and close surface material inspection. K -Series Probes K Series stands for characteristic transducers. Transducers of this series have high sensitivity, moderate signal to noise ratio and high penetration. They are tuned to a particular frequency and are suggested for deep material penetration, bulk body defects resolution, shear wave application and investigation of attenuative media. P -Series Probes P Series represents Panacea Transducers. P series transducers have response falling between W and K series. They have sensitivity closer to K series and Resolution closer to W Series making them ideal for all general purpose NDT application. N-SERIES Probes This new series has features like low initial ringing offering better near surface resolution, sharp echoes for higher overall resolution, high signal to noise ratio incoarse material and high reserve gain.
