Sweep Frequency Response Analysis (SFRA) is a powerful and sensitive method to evaluate the mechanical integrity of core, windings and clamping structures within power transformers by measuring their electrical transfer functions over a wide frequency range. SFRA is a proven method for frequency measurements.

We manufacture, supply and export Oil Tan Delta & Resistivity Test System all over the world. We are based in Nashik, Maharashtra, India and are offering Oil Tan Delta & Resistivity Test Systems in varied grades and specifications. Besides, Oil Tan Delta & Resistivity Test System, offered by us, serves the purpose of testing electrical equipment in different industries. Minimum Order Quantity : 50 SpecificationsDetailsTan-Delta range0 to 19.99 with resolution of 0.01%Tan-Delta accuracy+/-1% of the reading +/-1 x 10Di-electric constant Range0.2 to 10Test Voltage0 to 600 VacIndication31/2 digit DPMPower Supply230 Vac +/-10% / 50hzWarm up tome5 minutesInsulation Resistance TesterTest Voltage500 VDCIndicationTaut band Panel MeterWarm up time1 MinutePower supply230 VAC +/-10% / 50HzMegohm Range2 M ohm to 10o M ohm in 7 rangesHeating ChamberTemperature Range0 to 150 Deg. C.Indication31/2 digit DPMHeating ElementInduction CellTemp. Sensing probePT 100Accuracy+/-1CThe Terminal Oil cellCell materialSS & Tetlon insulatiorsCell Capacitance55 pf = / -1pfCell Constant620 (Normal)Test ElectrodesHV, LV & gaurdDistance between electrode2 mm 85 pe IS - 335Oil Volume60 ml

Tan delta system Comparison of earlier reading with latest, Comparison of old data Vs new data for easy analysis of troubleshooting of test objects, Fully Automatic Capacitance &Tan -Oil Delta Test System, Comparison of earlier reading with latest.

Tan Delta Test System, Dielectric Analyzer, Abb Switchgear

Laboratory Testing Instrument, Cell Counter, HIV Test Ki

Tan Delta Test System, High Voltage Capacitor, Oil Test Syste

Tips, Carbide Die

Microstructure Specimen Se

TANDELTA SYSTEM EW-188 is specially designed for quality control of enameled wire. Tangent delta and the tangent data temperature Characteristic are the concepts often discussed in connection with enameled copper wire. The precise measurement of tangent delta is of higher importance for the characterization of hardening state of the enameled insulation. If an alternating voltage is applied to wire enamel, a small current passes through it which is phase shifted. A yard stick for this phase shift is tangent delta. In EW-188 a measuring frequency of 1 KHz sine voltage is applied to the sample. The result is phase shift between voltage and current which is proportional to tangent delta. This phase shift is detected with very precise phase detector circuit. EW-188 can be used for single point measurement as well as determinations of bending point. The temperature can be set anywhere upto 300 degree Celsius for single point measurement. Tan delta and temperature are displayed simultaneously. Further more the curve measurement can be automated on a Laptop PC through suitable windows based software. • DIGITAL READOUT FOR TEMPERATURE & TAN DELTA. • SOFTWARE BASED PID TEMPERATURE CONTROL. • WINDOWS BASED USER FRIENDLY SOFTWARE. • USB COMMUNICATION PORT FOR LAPTOP CONNECTION. • MULTIPLE GRAPH COMPARISON ON SCREEN. • SUITABLE FOR SINGLE POINT AS WELL AS BENDING POINT MEASUREMENT.
