Bipin Pharma Equipment Thane, Maharashtra

Brand Name : Bipin Pharma Equipment

Material : SS

Brand Name : Bipin Pharma Equipment

Country of Origin : Made in India

Brand Name : Bipin Pharma Equipment

Material : SS

Brand Name : Bipin Pharma Equipment

Material : SS 316 L / 316 / 304

Country of Origin : Made in India

Capacity : 50-1000kg

Material : ss

Brand Name : Bipin Pharma

Country of Origin : Made in India

Material : Stainless Steel

Batch Size : 5 KG TO 500 KG

Brand Name : Bipin Pharma Equipment

Country of Origin : Made in India

Capacity : 250 ltrs - 15000ltrs

Brand Name : Hexamode

Our Automatic Rotary Bottle Washing Machine reflect our intricate design of out trained professionals which breathe in quality, durability and flawlessness making these machines highly demanded in markets across the globe. Designed to clean vials, bottle and similar containers with utmost precision. Distinct processing operation are carried out by the machine. Machine works on AC current.Independent line connections for various systems is provided, along with an additional connection for washing & rinsing the outside of the container, The holders are fitted with spray nozzles with adjustable neck rings for wahing various sized of bottles.

Double Cone Blender is an ideal machine for mixing dry powder and granules homogenously. Our Double Cone Blender is fabricated from the best quality raw materials which are procured from reputed and certified vendors, hence our product has earned a reputation for its quality, durability and flawlessness in markets all across the globe, Available capacity is 20 Ltrs – 3000 Ltrs and the effective volume for optimum homogeneity is between 35-70% of gross volume. However the effective volume can be upgraded to 80% based on valid study of the product, The Slant shape of the blender means that there are conical shapes at both ends which enables uniform smixing and easy discharge along with eliminating dead sports which occasionally occur in conventional double cone mixers, For better mixing, cone paddle-type baffles can be provided on the shaft inside the cone, depending upon the product.

Vacuum Tray Dryer is the most commonly used batch dryer. The box-shaped machine has a door (two doors in case of larger models) for loading and unloading. The product is placed on trays which are placed on heating plates one upon another. Distance between the heating plates is calculated by the surface loading and foaming of the product. The bottoms of the trays and heating plates are kept as smooth as possible for optimum heat transfer between the plates and the product. Now comes the preheating stage in which the product is heated at atmospheric pressure till all trays reach the same temperature, after which the drying can start. 40-80 mbar abs is reached in the main drying phase while only a few mbar abs are reached in the final drying stage. Heating temperatures range normally between 80C and 110C. The drying process requires a few hours to time depending upon the product and its surface load. Automatically controlled vacuum and temperature profiles can be set to prevent going over the threshold of the critical product temperature. Dimensions of the vacuum system play a crucial role in the design of drying cabinets. If intense foaming of the product is desired, the transfer to operational vacuum level must take place very quickly so that the vapours produced are taken out directly or through the means of a steam jet compressor and the non-condensable vapours are extracted by the vacuum system.

The Liquid Manufacturing Plant is a set of equipments designed for the manufacture of syrups, liquid oral formulations and other water based pharmaceutical products for capacities ranging from 500 ltrs. to 10000 ltrs.

Our Automatic Rotary Bottle Washing Machine reflect our intricate design of out trained professionals which breathe in quality, durability and flawlessness making these machines highly demanded in markets across the globe. Designed to clean vials, bottle and similar containers with utmost precision. Distinct processing operation are carried out by the machine. Machine works on AC current. The holders are fitted with spray nozzles with adjustable neck rings for wahing various sized of bottles, The rotting plate is fitted with 16 manifolds which have 5 spraying tulips bottle holders each, The rotation speed is one round per minute with the capacity to wash 2000 to 9000 bottles an hour.

Vacuum tray dryer is the most commonly used batch dryer. The box-shaped machine has a door (two doors in case of larger models) for loading and unloading. The product is placed on trays which are placed on heating plates one upon another. Distance between the heating plates is calculated by the surface loading and foaming of the product. The bottoms of the trays and heating plates are kept as smooth as possible for optimum heat transfer between the plates and the product. Now comes the preheating stage in which the product is heated at atmospheric pressure till all trays reach the same temperature, after which the drying can start. 40-80 mbar abs is reached in the main drying phase while only a few mbar abs are reached in the final drying stage. Heating temperatures range normally between 80C and 110C. The drying process requires a few hours to time depending upon the product and its surface load. Automatically controlled vacuum and temperature profiles can be set to prevent going over the threshold of the critical product temperature. Dimensions of the vacuum system play a crucial role in the design of drying cabinets. If intense foaming of the product is desired, the transfer to operational vacuum level must take place very quickly so that the vapours produced are taken out directly or through the means of a steam jet compressor and the non-condensable vapours are extracted by the vacuum system.

Liquid oral manufacturing plant is a set of equipments designed for the manufacture of syrups, liquid oral formulations and other water based pharmaceutical products for capacities ranging from 500 ltrs. to 10000 ltrs.The Sugar Dissolving Vessel is a jacketed cylindrical tank with torrispherical dish ends. A propeller type stirrer is provided for agitating the liquid.

Key Features: * Product is fed to the operating area by a specially designed feeding device to a rotor of speed 2800 rpm. * The product is subjected to high shear, pressure and friction between the stator and motor. The product is then subjected to intensive vibration which exerts its force on the product by means of pressing and releasing movement. * The angular gap becomes narrower towards the discharge output because of the slightly tapering shape of the milling surfaces of stator and rotor. * The processed product then leaves the mill through the drain pipe continuously and it can be recalculated, if required. * Three oil seals are present between the motor and processing chamber to prevent the entry of liquid into the motor winding which can result in the burning of the motor. * For ease of operation, the grinding gap can be adjusted by a exterior screw by means of handle even during operation. For ease of maintenance, coupling is provided between rotor shaft and motor shaft & the contact parts can be easily dismantled for cleaning. * Latest semi-concave teeth technology in rotor and stator reduce the motor HP and offers exceptional performance by reducing the size of the product without damaging it. * The special design of the extended bearing housing enables fine adjustment of the bearing clearances or back lash to prevent metal to metal contact of rotor or stator. This exceptional design contributes towards smooth and consistent performance & long life of rotor & stator. * The machine comes equipped with leak proof neoprene sealing device. * Flame proof motor and flame proof rotary switch are offered as per client requirement at a nominal fee. * For draining and recirculation of liquids, standard three way cock system is provided. We also provide an extra discharge spout as standard for viscous products. * DOL Started with over-load relay is provided to prevent single phasing & low voltage.

Brand Name : BIPIN PHARMA EQUIPMENT
