Half Screen Hammer Mill
Get Price Quote
Leveraging our rich experience, we make available to the clients Half Screen Hammer Mill. Half Screen Hammer Mill is highly beneficial for decreasing the particle size of various ingredients in the feed. Changing the screens of several hole sizes in the grinder allows excellent grinding result.
Components :
Round shaped highly balanced rotor with only minimum vibration and when motor works at a high speed strikes with the materials and break themNo leakage of material between screen and body of grinderSpecially designed hinges which do not loose throughout its lifeDetachable stripSpecially designed outlet which facilitates free flowing of ground ingredients into bag while baggingRenovated inlet hopper design, to let not the material fall down by sidesTo protect dust from entering the bearings, Bearing brackets are fitted at some distance from bodyProvided with a Belt safety cover
Benefits :
Enhance mixing characteristic of ingredients.Improves pellet quality and Pelleting efficiencyEnsures easy handling of ingredientsReduce particle size to assure easy digestion of ingredients by animal
Attributes :
Robust constructionEffectual functioningConsistent performanceLow maintenance costLonger service life
Technical Specifications
ModelCapacity / Hr. Maize GrindingCapacity / Hr. Mixed Feed GrindingCapacity / Hr. Millet GrindingPowerStarterGrowerFinisherStarterGrowerFinisherLG-1 150 kgs 300kgs 500kgs 250kgs 500kgs 650kgs 200kgs 3 H.P.LG-2 500 kgs 1000kgs 1300kgs 800kgs 1500kgs 2000kgs 500kgs 5 H.P.LG-3 1000 kgs 1500kgs 2500kgs 2000kgs 3000kgs 4000kgs 800kgs 10 H.P.LG-4 1500 kgs 2500kgs 4000kgs 2500kgs 3500kgs 6000kgs 2200kgs 20 H.P.
