Rolling Machine Dealers in Ahmedabad

Features Asymmetrical Roll Bending Machine High Strength Steel Roll Fixed Top Roller, Adjustable Lower and Rear Roller Standard Series Wire Core Groove   Top Roll Swing out across Cam Lock Conical Bending Feature

Suitable for mounting wire on rollers upto 1600 mm Length Can be used to mount wire on Licker in, Feed Roller, Redirecting Roller, Stripping Fillet, Blow Room Beaters , etc Traversing assembly with bearing guiding unit & wire Tension Indicator Drive unit driven by A.C geared motor, Speed Control by Variable frequency Drive.

Roll Diameter - 150 mm Roll Width - 360 mm Working Width - 300 mm Material Construction: EN 8 hardened material & with high polish chrome plated enable to resist high temp. HMI touch screen with PLC controller. NIP gap measurement with 0.01 mm least count. Separate temperature controller & display for both the rolls. Temperature Range: Upto 300°C with PID controller (Electrically Heated Rolls) Motor Driven Power : 5 HP Doctor blade for removal of material on entire working width area of the material. A/C Frequency drive for speed control (2 to 22 RPM) (Controllable from HMI with speed display). Paint: Angle Stucture: Epoxy Paint Body Paint: Powder Coating Semens Grey Shade. Element covered by SS case for protection & long operation. SS rod for manual cutting of the processed polymer. (With SS tray fitted for handling). The motor driven system is equipped with the limit switch actuated for emergency stop. (Situated at knee level in front of the machine) Power Requirement : 415 V AC, 50 Hz Three Phase + Neutral + Proper earthing is required. Available in both fix and variable speed model. Note: Two roll mill also available for rubber application with water cooling arrangement.

  Very easy & comfortable machine operating function through digital control & display panel. The process is fully visual to the operator so the monitoring of the products during process leads lesser chances of rejection. Flexibility of different models to produce from 200Ltr. To 25000Ltrs vertical tanks. Efficient low pressure burner which are very simple to adjusted from outside. Faster return of investment due to lesser production cost. Rock N  Roll machines are widely used to economically produce the smaller to large size hollow products up to 25000Ltrs. Capacity.

We offer high grade rolling mill machinery that is widely demanded in different parts of the globe. The rolling mill machinery that we manufacture is precisely fabricated with the incorporation all the specifications of the customers in it. Also, we are one of the distinguished manufacturers, exporters, and suppliers of rolling mill machinery.

Our Calendar Rollers are manufactured using modern CNC machines at all manufacturing stages, maximum precision is guaranteed with respect to cylindricity, roundness, concentricity and surface quality. Besides cylindrical barrel grinding all types of crowns, as well as special roll profiles, are possible. Rolls can be furnished with a matt, engraved or corrugated finish.   We can offer rolls made from various materials: Chilled cast iron (single poured) Chilled cast iron with nodular cast iron core (compound casting) Grey cast iron High chrome-alloy special cast iron

Roll Size : Max up to Dia. 300 mm X Width 12 to 65 mm. Measuring : by electronic sensor. pre-set digital length counter. Ele. Motor : 0.75 kw AC with electromagnetic brake.

This machine has been developing for roll cutting purpose. It can cut up to 10inch roll of fabric, Nonwoven, adhesive masking tape, BOPP tape etc.. It’s very economical model compare to traditional slitting machine.

✔ Rock N Roll Machine main Frame complete with Rolling mechanism with suitable Gearbox & motor driven with AC variable drive for speed control. ✔ Main supporting tripod frame for fitting the main frame. ✔ Rocking mechanism with hydraulic cylinder. ✔ Complete heating system with burners having individual control System & main regulating valve. ✔ Powder coated Electrical panel with dust proof construction.

We are leading manufacturer Label Roll Dispensor Machine.    Overall Size : 2feet x 1.5 feet x 4 feet height MOC. M.S. Colour Coated strcture with adjustable height , M.S. base, with Suitable Label Wrap Around system.  Machine fitted with : Imported Stepper motor with suitable drive system for label dispensor with Imported label-gap sensor.

Top Roller Greasing Machine (Vertical) Top roller greasing machine is manually operated efficient greasing system for Top Roller. Well designed for convenient greasing of Ring Frame and Speed Frame top roller to grease single side at a time with calibration system. Greasing tank Capacity: 1.5 Kg.

Mechanical brake for set tention Reduction gearbox with motor drive for turn table roll assembly 1000mm rubber fillet covered roll with mechanical synchronizes drive Pre settable counter for rotation of stretch film,starter for ac motor Protection against moisture and dust Prevent telescoping of rolls Save packaging cost, Labour and time Better identifications of wrapped products Give stability to the product Economical way of packaging

Prime Machine tools is Manufacturer of Roll Grinding Machine With Prime's Spirit Of Precision, Perfection and Supeiority, Prime Roll Griding Machine Generally meant for Metalic & non-metalic Rolls of Steel Rolling mills, Foil mills, Rubber roll Industries Work-shop Industries For microns Accurancy. SALIENT FEATURES THE MACHINE BODY : The Machine Body is one piece close grained cast iron. Special type design, heavy, rigid & stable. MACHINETABLE : The Machine table is Special Designed and close Grained cast iron. Machine table complited machined & Ground. WHEEL HEAD : Special alloy Steel with heat treated, Ground and Lapped Spindlefor high accuracy and long Life. Special design white metal bush bearing for high accuracy and excellent surfece finishing. WORK HEAD : Special heat treated, Ground & Lapped Spindle runs on Antifriction Bearing. Give High Accuracy & true Running to Spindle. A.C. Drive Provided to get variable Speed of Work- head Spindle/ Work piece for achieving high Production, Good Accuracies & Optimum R.P.M Of work piece can be set. TAIL HEAD : Speacial Heat treated Ground, Lapped & heavy Duty ram for Achieving High Accuracies. HYDRAULIC/ELECTRICAL UNIT : Hydraulic power pack unit housed out side the machine for easy maintance. All electrical mounted in a concise panel Box centralized control for operators. LUBRICATION : Centralize lubrication system provide for efficient and positive accuracy and long life. lubrication of moving parts. AUTO CAMBRING SYSTEM ( OPTIONAL ) Prime machine tools is special designed auto cambering system Generally meant For Steel Rolling Mills, Foil mills, Rubber Industries and Others Industries Prime Machine tools Provide Auto Cambering System by mechanical For easy Operated & highly Accuracies. Cambering on Work-piece is conevex type and also concave type done on Machine. Cambering on Work-piece is Maximum +0.5 And minimum ±0.01 Achieve on Machine HYDRAULIC TABLE DRIVE ROLL GRINDING MACHINE WITH OR WITHOUT AUTO CAMBER SYSTEM
