Horizontal Autoclave Dealers in Ambala

Our dry vertical autoclave are triple walled units. Outer body of our autoclave is constructed out of thick gauge stainless steel sheet of SS-304 grade. The inner chamber is also made of heavy gauge stainless steel sheet of SS-304 grade. The middle wall is also constructed from the strong and sturdy stainless steel sheet of ss-304 grade s stainless steel sheet. These are steam stocking models connected with a three way valve to control the sterilization cycle inside the autoclave. Our autoclaves are air insulated from inside, however we may incorporate mineral glass wool insulation if the customer desires so. The strong lid constructed out of thick stainless steel plate has a double safety radial locking arrangement , which ensures an easy and smooth opening and closing operation for all our autoclaves. Our deluxe vertical autoclaves are ideally suited for hospitals and research labs where safety is the first priority of the users, since it is equipped with a double safety steam release valve. At the same time we test all our autoclaves for up to 2.5 times the standard working pressure to ensure maximum safety and protection from any unfortunate incident. All our triple walled vertical autoclaves are supplied complete with pressure gauge, pressure release valve and stainless steel basket as a standard feature.   Salient Features: Steam Stock Provision Versatile usage Stainless steel construction Ergonomic Design Energy Efficient Double Safety Radial Locking Arrangement Double Safety Valve Protection Hydraulic Testing Upto 2.5 times the working pressure Calibration And Protocol Documentation

Our Rectangular Autoclave is highly famous and is highly demanded by all. We supply our premium quality horizontal rectangular autoclave at one of the most affordable prices for everyone to avail them easily. We have also gained the position one of the preferred rectangular autoclave suppliers in India. Construction The unit has inner Chamber, Boiler, Lid and Jacket - all made of 304 grade stainless Steel, outer chamber of thick gauge mild steel. For controlling sterilization cycle, a three way valve or a multiport valve - made of S.S. is provided. It is supplied complete with vacuum breaker, water level indicator, steam trap and automatic pressure control switch. The whole unit is mounted on a robust tubular stand. It is available in the following standard sizes. Operatable on 3 Phase, 440 Volts A.C. Supply. Mode of Heating Electrically heated by special flange type/immersion type heaters bearing ISI mark, to work on 440 volts three phase 50 cycles. Working Pressure The pressure inside the chamber is variable from 5 psi. to 20 psi. But the normal recommended pressure for sterilization process is 1.2 kgf/cm sq.g (15 psi - 17 psi) Working Temperature : 121° C Hydrotest Pressure :

We are offering All contact parts is made of S.S 316 with food grade joints silicon gasket load in trolley and with door safety locks. When door is in under pressure and jacket is provided for storage of steam and boiler is electric operated with heaters and digital temperature controlled and display pressure. Switch is provided for controlling of pressure and safety .Valve is provided for complete stainless steel. The sterilizer is based on the principle that microbiological action of saturated steam at elevated temp is rapid and thorough. All models work on downward displacement of air principle which is most economical method of obtaining for all types of bulk sterilization which are commonly needed in Medical, Agricultural and Pharmaceutical institute Suitable for sterilizing hospital dressings, linen, rubber plastic goods, surgical instruments, glassware’s and utensils etc. Construction Robust and rugged all weld construction which is leak proof unlike riveted construction. Inner chamber & Outer chamber is made of stainless steel of 304316 quality and jacket is made out of rolled steel. Sterilizers will have single door made out of rolled steel lined with S.S. sheet on both sides. All the sterilizers are hydraulically tested to withstand 2.5 times the working pressure. The steam jacket is lined on the outer side with asbestos sheet or glass wool which prevents heat losses due to radiation and is covered by strong rolled steel sheet duly painted.Boiler Made of thick stainless steel plate suitably located under the sterilizer. High grade flanged type heating elements are fitted from front side for easy replacementrepair. Fitted with water gauge glass for water level, safety valve, water inlet and drain valves. It is also provided with Low Water Level cut off device. This device protects the heater in the generator from burning out dry. The steam pressure in the boiler is indicated on an individual pressure Gauge. Safety Lock for Door Every horizontal rectangular sterilizer is fitted with SELF LOCKING SAFETY DOOR which cannot be opened when the chamber is under pressure. The Chamber Two separate valves provided for evacuating air and steam from inner chamber and jacket as and when desired. A steam trap is fitted in the chamber discharge line to eliminate the condensate automatically. Switch Box Houses the Pressure control switch, Main switch, Pilot lamps, relays etc. and mounted on the stand of the sterilizer for easy operation.Technical specification S.S. Load & carry Transfer trolly. Watering type vacuum pump with S.S. condenser and starter. Automatic recording cycle with printer Microprocessor controller with fully automatic. Fully automatic printer thru. PC with graphical display. PLC Provided HMI PLC, HMI, sensors RTD and pressure transmitter, Pressure gauge etc would be reputed make. Other Features Triple Safety : The sterilizer is provided with triple safety. By a pressure control switch which automatically limits the pressure to the required set valve. Two spring loaded safety valves one each at chamber and boiler level. A dead weight safety valve at chamber level. A Plug Screen : Prevents the discharge line from choking. The plug is easily removable for routing cleaning. A powerful Ejector (for drying sterilized linen) circulates air through the chamber. The circulating air passes through a corrosion resistant metal wool filter. A Dial thermometer is provided to show the chamber temperature. Automatic Vacuum Breaker : Automatic Vacuum Breaker is provided to break vacuum case of vacuum formation due to steam condensation. Operating. Temperature and pressure : Sterilizing Temp. : 121°C. Sterilizing Pressure : 1.2 to 1.5 kgCm2, (15 psi to 22 psi) Optional Accessories ChamberJacket of S.S. 316 Door of S.S. 304316 Additional TrayShelves Carriage & Trolley Direct steam supply from centralized boiler Temperature recorder High pressure High vacuum model Additional door (Double door)

We are offering horizontal autoclave. Advanced technocracy inc. Is manufacturer, exporter & supplier of horizontal autoclave. Most ideal for any institute or laboratory doing bulk sterilizing and research work. This autoclave has double walled chamber and a boiler and these are mounted on a heavy duty mild steel stand. The inner made of thick stainless steel sheet and outer chamber is made of stainless steel mild steel sheet. Automatic self closing device to prevent opening of the door while the sterilize is in operation . Stainless steel steam generation unit fitted with easily replaceable heating element. Fitted with pressure control switch. Pressure setting range 10 t020 psi.

We offer to our clients Horizontal Autoclave (Round) This is a triple jacketed autoclave in Horizontal form. Our range is extensively used in hospitals, private clinics and nursing centers to clean the appliances from the bacterial, fungal and viral infections. Moreover, our range is also extensively used to clean contaminants from the laboratory appliances. This sterilizer disinfects the garbage sacks in buckets that are put in upward order. Internal and external walls of the autoclave are made of high grade stainless steel. Our autoclaves are appreciated for the features like corrosion resistant finish and sturdy construction.

Horizontal labware have always been appriciated in the industries because of the standards and high quality maintained while designing.Horizontal autoclaves are bigger in size than there counterpart vertical autoclaves. These also work on the same principal of sterilization by using heat and pressure. However these are designed for bigger workloads. The horizontal autoclave is tested by keeping in mind the ASME code. Accordingly the horizontal autoclave must be tested 130% of the rated pressure. There is not much need of designing small autoclaves with inside vacuum building phenomenon, but in the bigger horizontal autoclaves it must be kept in mind, when the steam colds down it tends to build a vacuum inside the chamber. However at acumen labware we engineer the horizontal autoclave for every possible flaw which might appear.

A versatile, electrically heated sterilizer under saturated steam of Adjustable pressure of 10 to 20 psi. double walled construction with boiler & steam jacket made of thick stainless steel and gap is filled with high grade glass wool to bring the temp. loss to a minimal level.The outer chamber is made out of thick mild steel.The lid is made of  thick stainless steel plate (joint less) or gunmetal plate and can be sealed by a  jointless neoprene rubber gasket by wing nuts through hinged bolts by engaging slotted lugs on rim of the cover. Provided with dial pressure gauge, air/ steam release cock, spring loaded safety valve adjustable to any required point from 10 psi to 20 psi with accuracy + 3 psi.   A drain cock has also been provided.  A double safety valve has also been  provided along with inlet. Supplied complete but without dressing bins. but presented in a horizontal position and without steam jacket.  The outer body made of mild steel, inner chamber made  of stainless steel.
