Temperature Scanner Dealers in Mumbai

ibratherm offers Microprocessor based Temperature Process Scanner Model MSI-16-H and MSI-16-V, which is most suitable for continuous and accurate monitoring of temperature or process values at maximum 16 different locations in the same or different system. Additional useful features of common and individual high or low alarms make these scanners versatile for control and alarm applications. MSI-16 accepts thermocouples or RTD (Pt-100) sensors, as inputs. The temperature is indicated within the accuracy of ± 1 o C or ± 0.1o C of the specified input range, in spite of non-linear behavior of the standard thermocouple and RTD (Pt-100) sensors. The Linearized indication is achieved by software linearization technique. The models are available for 4, 8, 12, 16, 20,24, 28 and 32 channels

Scanner (81216 channels) is available in Flameproof weatherproof housing, certified by CRMS, Dhanbad, suitable for gas groups I, IIA, IIB. Enclosure has clear glass for better readability. Hardware specification remains same for standard scanner.

emperature detector, temperature scanner, 16 channel temperature scanner in India. The rtd temperature scanners, resistance temperature detector, temperature scanner, 16 channel temperature scanner that Canopus manufactures are of top quality and highest standards. Get in touch with us to know the details of the products.Software algorithms are implemented to filter the signal noise and to COMPENSATE FOR THE NON-LINEARITY ARISING DUE TO RTD response characteristics. The instrument has the facility to periodically interrogate the sensor inputs to detect SENSOR FAULT conditions. This is extremely useful in monitoring abnormal conditions such as Wire Break or Burn-Out of RTD’s in a running process.

Libratherm offers Digital Temperature Scanners model MSI-8 for 8 channel, MODEL MSI-16 for 16 channel, Model LSI-16 for 16 channel with higher accuracy, Model MSI – 8000 is Microprocessor based 16 channel and Model DATALOG – 16 is microprocessor based DATA LOGGER. All these models are suitable for continuous monitoring of temperature or process variables at different locations. These instruments eliminates the need of number of individual temperature or process indicators and hence saves on cost and panel space. Each model offers different features and can be used as per the requirement in terms of number of inputs, accuracy and price. Model MSI-8 accepts 8 thermocouples or RTD (Pt-100) sensors. The temperature is displayed along with the respective channel number. The scan rate is adjustable from 2 to 20 seconds. The standard features include SCAN/HOLD facility and manual increment of the channel number using ADVANCE front panel membrane switch. MSI-8, can also be used to monitor other process parameters. MSI-16 offeres similar features but for more than 8 channels with larger display and enclosure. The Linearized models LSI-16 series are made available to monitor upto 16 channels, with +/1 oC or +/-0.1 oC indicating accuracy and larger display size. The above models accepts 1 to 16 inputs but of single type only and having same measuring range. To suit applications where monitoring of different process parameters having different measuring ranges are required, the microprocessor based models are more suitable. Microprocessor based Sixteen Channel Temperature Scanner /Data Logger model MSI-8000/DATALOG-16 are suitable for continuous monitoring of temperature/process variables at 16 different locations with the indicating accuracy of 1oC or 0.1 oC and for other process inputs the instruments offers absolute indicating accuracy. Each input has independent amplifier and hence each input can be of different type. For example, out of 16 channels, 8 can be thermocouples, 4 can be RTD (Pt-100) and rest 4 can be (4-20)mA.Wherever, in addition to only monitoring the process parameters, the data logging, memory storage, common or individual high and low alarm relay outputs, printer or pc interface is also desired, the model DATALOG-16 offers them all as per the requirement. For this facility the built in real time clock allows real time data logging, parallel printer port allows on line and off line printing of the data and RS-232/RS-485 port allows data logging on to the PC. Necessary data logging software operating on Windows is also offered for both graphical and tabular representation of the data of all the channels which are logged in.ApplicationHeat treatmentFurnace / Oven controlPower plant Food processingEnvironmental and Walkin chambersMotor , transformer plants..etc.Tunnel furnaceLaboratory equipment etc.

Series is PID Controller available in standard & profile PID Controllers Programmable : 8 Patterns 16 Step (128 Segment Programmable control curve) Standard & Profile Programmable, motorised valve (Position proportion type) with up to 3 Input signal & 2 control output 4 Alarm with optional communication : RS232 RS485 MODBUS

Temperature Scanner, Power Saver, Stepper Motor Controller, Data Scanne

Temperature Scanner, Averaging Pitot Tube, Flow Indicator Totalize

Made in india with 1 year warranty

Temperature Scanner & Data Logger, Automatic Voltage Regulating Relay-AV

Bwe present our technically superior digital temperature indicators and scanners for multiple uses in various industrial applications. Based on microprocessor controller technology, our digital temperature indicators and scanners are superior in performance and are provided with a variety of features to ensure.

Temperature Scanner, Flow Indicator Totalizer, Signal Isolator

Temperature Scanner, Process Scanner, Industrial Printer, Data Logger

Temperature Scanners, Electronic Process Control Instrumen

Digital Temperature Scanner, Data Acquisition Syste

Temperature Scanner, Resistance Temperature Detectors, Temperature Recorde

We are one of the renowned manufacturers and suppliers of a comprehensive assortment of Temperature Scanner that caters to wide applications of industries. Our range is manufactured as per advance micro-controller techniques.

Temperature Scanne

Temperature Scanners, Temperature Controllers, Temperature Indicator

The ASHE Series MAX range of microcontroller based multi-channel Temperature Scanners are compact, rugged and reliable instruments designed for accurate measurement and control applications. The Scanners are fully configurable instruments with options of 24816 channel inputs, which can accept Thermocouple (J,K,R,S,T,E) sensors and RTD Pt-100 (three-wire) sensors. Upto four Relay outputs are offered as assignable control outputs, each of which can switch a load of up to 10 Ampere rating. Separate displays are provided for channel number and it’s corresponding temperature. The instrument operates on 85 to 270 V, 5060 Hz Universal AC power supply and is offered in ¼ DIN standard panel-mount execution. Options include settings for Channel Skip and Scan Time, Analog Retransmission signals, weather-proofflame-proofpanel mount options, etc.
