Industrial Valve Dealers in Navi Mumbai

General design & manufacturing Valve face to face dimension Top flange drilling Valve Inspection & Testing Flange Standard : : : : : EN 593 / API 609 / IS 13095 Double flanged Short Pattern to EN593 / API 609 IS 13095 / ISO 5752 series-13 ISO 5211 EN 12266 Part 1 / API 598 DIN EN 1092-PN6 / PN10 / PN16 or BS 4504 / Class 150 AW AC 207 Class - B & D 1. Valve type : Centric Disc Rubber lined Flanged end Butterfly valve 2. Body type : Double Flanged Short 3. Seat (liner) type : Integrally Bonded with body ID 4. End connection : Flanged Ends (Double Flanged) 5. Size Range : *DN 50 to DN 600 - ASME Class 150 (max) 6. Pressure rating : * DN 650 to DN 1200-PN10 (max) 7. Operating temperature range : -250 C to 2000 C (depending on MOC) 8. Seat leakage : Tight shut off 9. Operation : Hand Lever for sizes upto DN200 or Worm Gear, Pneumatic or Electric Actuators 10. Standard Material of Construction (MOC) Valve Body : CI / SGI / WCB Disc : SGI / WCB / CF8 / CF8M Bonded Seat : Nitrile / EDPM / Neoprene / Hypalon Drive end & non drive end shaft : SS 410 / SS 17.4 PH / SS 316 Bearing Steel+PTFE or SS316+PTFE

SS304 - 1/2" npt mf SS316 - 1/2" npt mf MS - 1/2" npt mf *Other sizes also available *price is indicative and may vary based on specifications.

The company has emerged as a prominent Exporter and Supplier of Globe Valves in Navi Mumbai. The Class 150/300 Globe Valves from Valtech are as per the ASA 19.5/150/300 class with the flange ends being suitable for steam, oil, water, air and other corrosive and non-corrosive fluids as per material of construction. The company offers the best Globe Valves at the best prices on a timely basis. Technical Data : Manufacturing Std. : BS 1873 Testing Inspection Std. : API 598/Bs 5146 Face To Face : Planned as per B16.5rf/bs 1560 The company is offering another type of the Globe Valves in ND-40/16 flange ends. These Globe Valves are suitable for steam, oil, water, air and other corrosive and non-corrosive fluid as per material of construction. Technical Data : Manufacturing Std. : BS 1673 Testing & Inspection Std. : API 598/BS 5146 Face To Face : As per DIN ND-16/40 End Connections : Flanged as per DIN 2533/254382535/2545 Download

We are a professional manufacturer of plastic valves & fittings products, pvc valve, pvc valves, thermal insulations, seals, electrial sulation material, plastic, we can, therefore, guarantee to provide our customers with competitiveprices, prompt delivery and different products. Most of our products, pvc valve, pvc valves are widely distributed to more than countries &. Areas.

Due to cooling of compressed air, condensation of oil & water vapour takes place in Moisture Separators, Air Receivers, Filters, etc. Regular draining of these equipment is an essential maintenance function. By installing Auto Drain Valves, you can ensure that all equipment of the Compressed Air System get drained regularly without manual dependence, except for periodic checks. Low cost timer based ADVs are commonly used, but for larger Systems, zero air loss level based ADVs are used Draining of Compressed air equipment such as Air Receivers, Moisture Separators, Filters, etc. is commonly done by low cost, timer - operated Auto Drain Valves. While these are effective in their functioning, they will open at the set time whether there is any condensate to be drained or not. This will result in loss of compressed air (and hence loss of energy), when there is no condensate to be drained. The 'LEVEL SENSING Auto Drain Valve operation is level - based without any timer. The ADV has a Reservoir (in which condensate accumulates) connected to a drain valve which opens when condensate level reaches the top and closes when condensate level reaches the bottom. These operations are carried out by sensors placed at different levels of the reservoir. By this method only condensate is drained when the ADV opens and there is no loss of compressed air, resulting in saving of energy. The reservoir & valve sizes are matched with the size and type , equipment to be drained, so that the ADV does not operate too frequently. Isolation valve & strainer are provided along with the ADV, for easy cleaning & servicing.
