Compression Testing Machine Dealers in Delhi

• Brand Name: ALE
• Finishing: Color Coated
• Condition: New
• Power Source: Electric
• Automation Grade: Fully Automatic
• Application: Industrial
• Feature: Fine Finished, Good Quality, Good Strength

  TECHNICAL SPECIFICATIONS   •      Large key catching display - 7” touch Screen operation •      Capacity 100 KN - 3000 Kn •      Load Least Count 0.1 kN •      Spherical seating arrangement on upper platen for self-centering to apply load in equal proportion on the sample •      Type of pumping: Reciprocating Pump servo motor controlled for precise load •      Automatic Release the load after performed the Test through Software. •      accuracy of ± 1%  •      Pace rate controlled through dedicated software from 0.5 kn/s to20 kn/s. •              Facility to access data through USB •               Load v/s Time graph generating automatic on Touch Display directly •               Automatic report generation after test, hue storage capacity of 10000 logs •               Facility to insert different shapes and area in the Touch screen  controller to calculate direct reading in KN •               Comes with Flexural & Aggregate testing mode •      4 Pillar Type Heavy Duty Load Frame. •      Platen with hardness is 55 HRC and flatness tolerance 0.03 mm, 305 mm Gap between Platens.    SAFETY FEATURES   •      Max. pressure valve to avoid machine overloading·  •      Piston  travel limit switch, Travel limit 50 mm·  •      Emergency stop button.  •      And Door Close Safety Switch       LOADING FRAME   4 Pillar Type Heavy Duty Load Frame having a top cross head, base  with precision ground hydraulic piston fixed to the base    Heavy duty spherical seating arrangement allowing initial free alignment at the initial contact with the specimen and automatic jamming up to the end of test.   Hardened, ground & polished platens. Heavy duty upper platen with oil filled ball seating arrangement for high stability.

• Power Supply: AC
• Motor Voltage: 440 V
• Automatic Grade: Automatic
• Phase Type: Three

• Type: Compression Testing Machine
• Certification: ISO 9001:2008
• Application: Testing Material
• Weight: 100-200kg
• Color: Grey
• Voltage: 110V, 220V, 380V
• Condition: New
• Automatic Grade: Automatic
• Power: 3-6kw, 6-9kw
• Driven Type: Electric
• Warranty: 1year

Product Code: EKE 305H-EKThe Digital Compression Testing Machine has been designed to meet the need for a simple, economic and reliable means to test concrete for its compressive strength. The design emphasizes simplicity, both of construction and operation, and makes the machine easy to use and maintain. The unit is compact, making it useful for site applications. The digital machines are provided with a pace rate indicator to indicate pace rate on a Bar Graph. With a little experience, the pace rate can be controlled manually while the test is in progress.The Complete unit comprises of Loading Unit :The loading unit is of fully welded construction having a cross head, base and solid side plates. The hydraulic jack is fixed to the base. The platens of the machine are hardened, ground and polished. The upper platen is provided with self-aligning action to facilitate testing of various size specimens, suitable size spacers are provided.Pumping Unit:The two speed pump facilitates rapid approach of the platens for daylight closure and also provides comprehensive control over the application of load. A control valve provides fine control over the loading rate for accuracy of pacing. The digital read-out unit, incorporates a 4-digit display, calibrated in kN and features integral load pacing in kN/Sec. Maximum load is held and retained for approx 15 min, unless cancelled, using the panel mounted reset switch. Pace rate set for running the test can be maintained manually with the help of a bar graph indicator. Logged data printing facility through a parallel port interface is provided in the machine. Readings upto 1000 complete runs/tests can be stored in the memory.

• Capacity: 2000 KN
• Brand Name: Steco
• Material: Mild Steel
• Application: Compression Testing
• Display Type: Digital
• Frequency: 50/60 Hz
• Power: 2 To 5 Kw

• Country of Origin: India
• Type: Compression Testing Machine
• Certification: CE Certified
• Application: Testing Material
• Weight: 500-600kg
• Color: Blue
• Voltage: 440V
• Condition: New
• Automatic Grade: Automatic, Fully Automatic, Manual, Semi Automatic
• Driven Type: Electric, Hydraulic, Mechanical
• Warranty: 1year
• Brand Name: NSLI INDIA

Compression Testing Machines have a wide range of applications. A number of materials & metals in different forms & shapes can be tested for a variety of tests like Tension, Compression, Transverse, Bend Re-bend, 180° Bend, Shear, Brinell, Pullout, etc. Special attachments are also available for testing of Flat belts, Chain links, Wire ropes, Nut-bolts.

We store the entire range of products in our capacious warehouse and we follow the automated warehousing system for the safe assembling as well as storage of the products. By using quality packing material, we make sure that the products are properly packed and there will be zero damage during transit. Moreover, our packaging experts stringently check the entire lot before making the final dispatch.

Principal of operation: operation of the machines is by hydraulic transmission of load from the test specimen to separately housed load indicator. The hydraulic system is ideal since it replaces transmission of load through levers and knife edges, which are prone to wear and damage due to shock on rupture of test pieces. Load is applied by a hydro-statically lubricated ram. Main cylinder pressure is transmitted to the cylinder of the pendulum dynamo-meter system housed in the control panel. The cylinder of the dynamo-meter is also of self-lubricating design. The piston of the dynamo-meter is constantly rotated to eliminate friction. The load transmitted to the cylinder of the dynamo-meter is transferred through a lever system to a pendulum. Displacement of the pendulum actuates the rack and pinion mechanism which operates the load indicator pointer and the autographic recorder. application : fie compression testing machine is designed for test materials under compression bending, transverse and shear loads. Hardness test on metals can also be conducted. Salient Features FEATURES : The Compression Testing Machine Incorporates design features to enable high accuracy testing with economy, speed & versatility. Loading Accuracy as high as + 1% Straining at variable speeds to suit a wide range of materials. Continuous roll autographic recorder supplied as standard to enable study of the behavior of materials Motor driven geared shafts for quick effortless adjustment of cross-head-to facilitate rapid fixing of test specimen. High reading accuracy due to large size and design of dial. Wide range of standard and special accessories, including load stabilizer. Large effective clearance between columns enables testing of standards specimens as well as structures. Simple controls for easy of operation. Robust staining frame of an extremely rigid construction. Safe operation ensured be means of safety devices. Control Panel : The control Panel consists of a power pack complete with drive motor and an oil tank, control valves a pendulum dynamometer a load indicator system and an autographic recorder. Power Pack : The power pack generates the maximum pressure of 200 kgf/cm2 the hydraulic pump provides continuously non-pulsating oil flow. Hence the load application is very smooth. Hydraulic Controls : Hand operated wheels are used to control the flow to and from the hydraulic cylinder. The regulation of oil flow is infinitely variable incorporated in the hydraulic system is a regulating valve which maintains a practically constant rate of table movement. Load Indicator System : This system consists of a large dial and a pointer. A dummy pointer is provided to register the maximum load reached during the test. Different measuring ranges can be selected by operating the range selection knob. An overload trip switch is incorporated which automatically cuts out the pump motor when the load range in use is exceeded. Pendulum Dynamometer : This unit permits selection of favorable hydraulic ratios producing relatively small frictional forces. Pressurised oil in the loading cylinder pushes up the measuring piston proportionately and actuates the special dynamometer system. The piston is constantly rotated to eliminate friction. The dynamometer system is also provided with an integral damper and ensures high reliability of operation. The load transmitted to the dynamometer is transferred through a pendulum to the load indicator. Autographic Continuous Roll Load-Elongation Recorder : This unit is of the pen and drum type and is supplied as standard. The horizontal motion of the pen produces the load ordinate of the diagram and the drum rotation produces the extension ordinates in the ration of either 1:5 or 1:10. A continuous roll of graph paper is stored inside the drum and is easily replaced. Accuracy & Calibration : All FIE Compression Testing Machines are closely controlled for sensitivity, accuracy and calibration during every stage of manufacture. Every machine is then calibrated over each of its measuring ranges in accordance with the procedure laid down in BS : 1610 : Part 1 :1992 and IS 1828. An accuracy of + 1.0% is guaranteed from 20% from 20% of the load range selected to full load. Below 20% of the selected range, the maximum permissible error is 0.2% of the full load reading.

• Weight: 100-200kg
• Warranty: 1year
• Material: Metal
• Application: Industrial
• Surface Finshing: Polished
• Resistivity: Rust Resistant

We are offering Compression Testing Machine which operates by hydraulic transmission of load from the test specimen to separately housed load indicator. Our Compression Testing Machine is specifically designed to enable high accuracy testing with economy, speed and versatility. The machine features motor driven geared shafts, control panel, power pack, hydraulic controls, load indicator system and pendulum dynamometer. Its loading accuracy is as high as + 1%. Also, it facilitates straining at variable speeds to suit a wide range of materials.    Available in : 100/150/200 ton hand operated. 100/150/200 ton Electric operated. 100/150/200 ton Electric operated with digital display.

The Digital Compression Testing Machine has been designed to meet the need for a simple, economic and reliable means to test concrete for its compressive strength. The design emphasizes simplicity, both of construction and operation, and makes the machine easy to use and maintain. The unit is compact, making it useful for site applications. We bring for the clients Digital Compression Testing Machine of superior quality at affordable rates. Components LOADING UNIT : The loading unit is of fully welded construction having a cross head, base and solid plates/Two pillars for four pillars nut or welded type having a cross head, base model. PUMPING UNIT : The two speed pump facilitates rapid approach of the platens for daylight closure and also provides comprehensive control over the application of load. A control valve provides fine control over the loading rate for accuracy of pacing. The digital read-out unit, incorporates a 4-digit display, calibrated in KN and features integral load pacing in kN/sec. Maximum load is held and retained for approx 15 min, unless cancelled, using the panel mounted reset switch. Pace rate set for running the test can be maintained manually with the help of a bar graph indicator. Logged data printing facility through a parallel port interface is provided in the machine. Readings of runs/tests can be stored in the memory. Hydraulic jack is fixed to the base. The platens of the machine are hardened, ground and polished. The upper platen is provided with self-aligning action. To facilitate testing of various size specimens, suitable size spacers are provided complete with ball seating arrangement. Features Easy to controlCost-effectiveDurableResistance to rustSafeLow maintenance
