Soil Testing Equipment Dealers in Jogeshwari, Mumbai

We are a chief Manufacturer, Exporter & Supplier of Ring and Ball Softening Point Apparatus. The Ring and Ball Softening Point Apparatus is manufactured by us as per IS: 1205-1978. The Ring and Ball Softening Point Apparatus is widely demanded for its sturdy make, efficient performance, dimensional accuracy and excellent efficiency. We supply Ring and Ball Softening Point Apparatus at competitive price all across the world. Description Unit consists of steel balls and brass rings as per IS specified dimensions, ball guide for ball centering, support for the ring, all mounted in a beaker which is provided with magnetic stirrer and a Immersion heater to heat the liquid inside Temperature is maintained with the help of a programmable digital temperature controller provided with PT100 sensor to achieve 5 degree C/min. temperature rise Use : Used for the determination of softening point of asphaltic bitumen and fluxed native asphalt, road tar, coal tar pitch and blown type bitumen

The unit consists of a Acrylic tube connected to a tank. At entrance of tube a bell mouth section is provided and at the other end a valve is provide to control the rate of flow. A capillary tube is introduced centrally to the bell mouth to inject die. By varying the rate of flow the Reynolds number changes. This also changes type of flow. Visual observation of die (thread) will indicate the type of flow which can be confirmed from the REYNOLDS number computed. FEATURES Steady flow arrangement Very clear flow visualization Fine control of die thread. Accurate flow measurement & control.   SPECIFICATIONS Acrylic tube (transparent) 25 mm OD / 20 mm ID of 1 meter length. Main Tank - 400X400X700 mm Constant Supply tank of 200x200x 200 Flow control valve. Dye tank and syringe Measuring Flask & stop watch for flow measurement.   RANGE OF EXPERIMENT To determine the Reynolds number & hence the type of flow either laminar or turbulent. To determine upper & lower Reynolds number & velocities.
