Drawing Machine Dealers in Ghaziabad

Straight Line Wire Drawing Machines were developed for straight or deflection free drawing of wire to provide better drawability, lower frictional contact and lower operator interference. Theoretically there is no limit as far as the wire material or wire diameter is concerned to be drawn on these machines. ASSOMAC has pioneered to indigenously develop the Straight-Line Wire Drawing Machine Technology in India. Presently the range available is capstan diameter 900mm, 750mm, 600mm, 550mm, 500mm, 460mm, 400mm and 300mm for inlet wire diameter 16mm down to 0.5mm. Line speeds upto 25 Mtrs / Sec. These heavy Straight Line Wire Drawing Machines provide remarkable drawing performance for Low, Medium and High Carbon Steel Wire, Stainless Steel Wire and special Alloy Steel Wire and Non-Ferrous Alloy Steel Wire. This machine has a sensor roller between the drum and the next die such that the wire passes in contact with this roller. These rollers have sensors to detect the position of the arm and maintain tension on the wire by regulating speed of the drums. The drums of this machine are inclined to the vertical axis to effect fill on the drums. Principally this machine is best suited for thick wires. Features of Straight Line Wire Drawing Machine: Machines are built on modular structure, in combination of Blocks and do not require any special foundation. Better productivity due to higher drawing speeds, twist-free operation & better cooling. Easy operation and faster threading. High pressure Narrow gap, internal water cooling for high efficiency cooling of wire. High degree of reliability, low downtime due to lower no. of wear parts. Much better finish wire quality due to a gentler handling of the wire during the drawing process (less wire deviations, low torsion etc.) as well as an optimized wire cooling. Highly effective pneumatic braking system in case of emergency. Better environmental conditions due to increased dust protection. Greater flexibility and lower current consumption due to modern AC drive technology and efficient power transmission system. PLC based control with profibus digital communication and fault diagnostic system. Optional Fitment: Stripper Block Rotating Die Boxes Motorized Soap Applicator Die Boxes Die less drawing trough Rolling Cassette Laser wire diameter measurement system Dust Suction System Online Modem based PLC support

We are engaged in manufacture of a heavy duty Wire Drawing Machines that is known for its efficiency in the field of wire drawings. The casted parts of this machine are mounted over steel fabricated frame to bear maximum load and give high performance. Functioning : 610 mm made of fine close gain C.I. casting (grade –1 duly machined and grinded). Die box will be provided with die holder Suitable to adjust the cast and helix of the wire in both planes. Die are made of Tungsten Carbide made of WIDA. Propelled by : Mechanical/ Hydraulic/ CNC & as per client requirements Capacity : 500 Kg to 14 Ton Special Features : Wire drawing drum diameter 310 mm to 1050mm Applications : Wire Drawing Plant Technical Data : Capable to draw from 24 SWG to 14 mm

We are offering our valued clients the cutting-edge OTO Type Wire Drawing Machine at reasonable price. OTO Type Wire Drawing Machine is designed to cater to the demands of steel wire making activities. Designed to impeccability, OTO Type Wire Drawing Machine is true specimen of innovative thinking. Specifications of OTO Type Wire Drawing Machine : Operator Consol is provided on independent block or common floor standing type control desk Die Chamber with forced water cooling indirectly or directly Graded cast iron drums with chrome carbide hard matrix at drawing portion 1 forced water cooled drums for longer drum life and cooler drawn wire Additionally air cooled drums with specially designed uniform cooling air jackets wire unloading trough stripper blocks, dead block coiler or spooler Single/Multi Speed of 300/350/450/560/610/650/760mm Non-Slip, Block Type, Continuous Dry Wire Drawing Machines Heavy duty worm and worm wheel type fabricated gear boxes with standard greaves (RADICON) & NAW Gears OTO Type Wire Drawing Machine Accessories : Wire Pointing Machine Wire Rope Hoist Wire Butt Welders Wire Pull-in-Dog Straightening and Indenting Rollers Pay off Stand Coil Binders Wire Stripper

We compete effectively in today's global business environment by constantly delivering cost competitive and high quality Wire Drawing Machine. Extensively used to draw wires from different materials, this plant is highly demanded by various industries. At our premises, this plant is manufactured from the high quality components, devices and modish technology in compliance with industry set standards. Besides, this plant is available in numerous specifications and at nominal rates.

Wet MachinesMulti hold sub – merged type Wet Drawing Machine designed for all ferrous & non – ferrous metals in the range of 9/11/13/15/19/17/21/25 dies or as per Customer requirements with variable drives & speed. Rod Breakdown MachinesOur range of rod break down machine is manufactured as per the latest International usages. We also have facility to customize our range according to the client's requirements. These are available in various specifications, some of them are designed 9/11/13 die for aluminium and copper wires along with spooling machine and dead block coiler.

Machine is designed to operate continuously. First block is provided OTO type for wire accumulation, allowing forth removal of any rod, snarl or changeover of coils at feeding end. VFN system on OTO block keeps uniform tension of wire passing over with on jerks. Each block is equipped with pressure regulating valves and gauges for accurate control of air pressure on sensor arm. Separate manifolds are provided for water to drums and dies with regulating valve on each block.BLOCK AND COOLING SYSTEM:  Drawing drums are forged alloy steel, fully hardened and ground. Surface hardness: 58-60 HRC. Drums are internally water cooled with narrow gap system. Complete wetting of wall by highly turbulent motion of water, higher cooling effect with increasing drawing speeds. Drums are externally cooled by air from a single common blower through duct forming part of machine frame.DIE BOXES: Dies are direct water cooled from a separate manifold. Dies are loaded from top for quick fixing. Motorized rotating die holders can be provided; extra long to adopt standard pressure dies. Die boxes are equipped with motorized lubricant stirrer. Rotating die holders have single motor for stirrer and holder. Die boxes are adjustable in horizontal and vertical plane for cast and helix adjustment of wire. Die boxes are suitable for dry lubricants, large enough to store sufficient quantity of lubricant.SPEED CONTROL: Speed regulation of each block is achieved through self cantering sensor arm on which the wire is guided.SAFETY GUARD: Well balanced sheet metal guards, with transparent sheet/wire mesh to see through condition of machine, are provided. Guards are electrically interlocked not to allow running of machine with open guards. Sound proof guard for low noise level with suction of burnt powder can be provided.TRANSMISSION: Motion transmission from motor to block shaft is achieved directly by V belt and pulleys or through helical gear arrangement.INTELLIGENT CONTROLS: Specially designed A.C. Three Phase Inverter Duty/Servo Motors L&T Supernova/Siemens 1ph7 constant torque up to base speed and constant power above base speed. Digital A.C. Three Phase Vector Flux Inverter Drives ABB ACS 800/Siemens Kinemics provide the system with fastest communication through provirus. All blocks are working with a range of encoder feedback, thermal protection, and flux vector controlled. The logic control is attained automatically by PLC system (Siemens) automatically calculating reduction rate and monitoring all related dates.Utmost control flexibility allows any drafting programme and drum skipping. HMI displays all function data making it easier for the operator to take control of the machine during production. Displays and memorizes the fault for easy diagnosis. Can be interfaced with remote computer to collect all information. Cubicles are sheet steel enclosures with IP54 protection, duly power coated and with exhaust. Electric control system provides a smooth acceleration from zero to pre-selected value. Normal stop is attained with ramp down control within 15 to 30 second. Emergency stop/quick stop is attained within 6 to 8 seconds. This can be achieved without a broken wire.

The precision engineered Wire Drawing Plants fabricated by us are used for drawing straight and deflection free wire. These machines are manufactured as per the technological advancements and are appreciated for robust construction, maximum output.

OTO Type Wire Drawing Machines , Wet and Dry Wire Drawing Machines, BB Block Wire Drawing Machines, MIG CO2 Wire Drawing Plants, Wire Galvanizing Plants, Binding Wire Plants.

Meenakshi Wire Products offers wide range of high speed state of the art study. O.T.O./ B.B. Type Wire Drawing Machines. The construction of the machine is such that it can withstand rugged workshop conditions of Wire Drawing Plant and can guarantee the performance and accuracy with least maintenance. These O.T.O./B.B. Type Dry Wire Drawing Machine have wide field applications in Stainless Steel, High Carbon Steel, Alloy Steel, Mild Steel, Copper Wire Drawing. The wire is drawn through a die which is fitted in independant Die Box and is accumulated on the Block, and later being taken through the OTO Pulley to the next Die. BB Block is Twist Free Type Machine with Free Bobbin Block for accumulation and transfer to next block and is better for higher speed & better finish materials.   Salient features : 760/650/610/560/450/350/300mm Single / Multi Speed, Non-Slip, Block Type, Continuous Dry Wire Drawing Machines. Continues Type in Line Machine for Large Cross Sectional Reduction Inlet size up to 12mm. Wire Rods Combination with 'B.B.' Type Machines for High Speed Applications. AC fixed speed with Speed Change Gear Box or variable speed A C / D C Drive is offered Heavy Duty Worm and Worm Wheel type Fabricated Gear Boxes with Standard Greaves (RADICON) & NAW Gears. Combination of Heli-Worm or Bevel Helical Gear Reduction if required. Dry/Wet Lubricant Type Die Boxes with Optional Rotating Die and Motorized Soap Applicators Die Chamber with Forced Water Cooling Indirectly or Directly. Optional Pneumatic/Electro Magnetic, Brakes on Machines. Operator Consol provided on Independent Block or Common Floor Standing type Control Desk. Inching with Foot Operated Pedal Switch Reverse/Forward. Graded Cast Iron Drums with Chrome Carbide Hard Matrix at Drawing Portion. 1 Forced Water Cooled Drums for Longer Drum Life and Cooler Drawn Wire. Additionally Air Cooled Drums with specially Designed Uniform Cooling Air Jackets Wire Unloading Trough Stripper Blocks, Dead Block Coiler or Spooler.

We are one of the eminent Manufacturers and Suppliers of wire drawing machine from Uttar Pradesh, India. Facilitated by advanced production unit, our wire drawing machine is manufactured using quality approved components in accordance with set industry norms. In addition to this, a team of experienced quality inspectors thoroughly examine wire drawing machine upon numerous quality parameters to ensure its un-interrupted functionality. When it comes to delivering Wire Drawing Machine, we always supply it using fast shipment modes.

BLOCK AND COOLING SYSTEM : Drawing drums are forged alloy steel,fully hardened and ground.Surface hardness:58-60 HRC. Drums are internally water cooled with narrow gap system.Complete wetting of wall by highly tubulent motion of water,higher cooling effect with increasing drawing speeds. Drums are externally cooled by air from a single common blower through duct forming part of machine frame. DIES BOXES : Dies are direct water cooled from a separate manifold.Dies are loaded from top for quick fixing. Motorized rotating die holders can be provided; extra long to adopt standard pressure dies. Die boxes are equipped with motorized lubricant stirrer. Rotating die holders have single motor for stirrer and holder. Die boxes are adjustable in horizontal and vertical plane for cast and helix adjustment of wire. Die boxes are suitable for dry lubricants, large enough to store sufficient quantity of lubricant. SPEED CONTROL : Speed regulation of each block is achieved through self centering sensor arm on which the wire is guided. SAFETY GUARD : Well balanced sheet metal guards,with transparent shet/wire mesh to see through condition of machine,are provided. Guards are electrically interlocked not to allow running of machine with open guards. Sound proof guard for low noise level with suction of burnt powder can be provided. TRANSMISSION : Motion transmission from motor to block shaft is achieved directyl by V belt and pulleys or through helical gear arrangement. INTELLIGENT CONTROLS : Specially designed A.C. Three Phase Inverter Duty/Servo Motors L&T Supernova/Siemens 1ph7 constant torque upto base speed and constant power above base speed. Digital A.C. Three Phase Vector Flux Inverter Drives ABB ACS 800/Siemens Sinaemics provide the system with fastest communication through profibus. All blocks are working with a range of encoder feedback,thermal protection, flux vector controlled. The logic control is attained automatically by PLC system (siemens) automatically calculating reduction rate and mointoring all related dates. Utmost control flexibility allows any drafting programme and drum skipping. HMI displays all function data making it easier for the operator to take control of the machine during production. Displays and memorizes the fault for easy diagnosis. Can be interfaced with remote computer to collect all information. Cubicles are sheet steel enclosures with IP54 protection,duly power coated and with exhaust. Electric control system provides a smooth acceleration from zero to pre-selected value. Normal stop is attained with ramp down control within 15 to 30 secound. Emergency stop/quick stop is attained within 6 to 8 seconds. This can be achieved without a broken wire.
